Fire-Lite ANN-80 80-Character Serial LCD Annunciator, Compact, Backlit, Red
Image of 1
Key Features
- Improves situational awareness with a backlit 80-character (20 x 4) LCD that mirrors the FACP display for faster, clearer decision-making
- Remote placement up to 6,000 ft via two-wire ANN-BUS keeps monitoring and control accessible across large sites
- Authorized control with keyswitch and dedicated acknowledge/silence/reset switches reduces response time and prevents unauthorized use
- Battery-conserving backlight that turns off during AC loss but reactivates on alarm, ensuring visibility when it matters most
- Tamper-supervised, surface or semi-flush mounting for simple installation and compliance with life-safety and security requirements
Quick Specifications
- Product Model
- ANN-80
- Brand Name
- Fire-Lite Alarms by Honeywell
- Product Name
- ANN-80 Fire Annunciator
- Product Type
- Annunciator Module
Frequently Bought Together
Fire-Lite ANN-80 80-Character Serial LCD Annunciator, Compact, Backlit, Red
$537.17
6 items selected
Total: $2,359.41
Explore the details
Product information
ANN-80
Overview
Improve fire-system situational awareness with the Fire-Lite Alarms by Honeywell ANN-80 annunciator. This compact, red, backlit 80-character (20 x 4) serial LCD annunciator duplicates the Fire Alarm Control Panel (FACP) display, delivering clear alarm, trouble, supervisory and AC power status at remote locations. Using the two-wire ANN-BUS serial interface, the ANN-80 communicates reliably with the host panel and can be installed up to 6,000 ft away for flexible building monitoring and security coverage. Powered by 18–28V DC from the FACP or a remote UL-listed supply, its backlight conserves battery power during AC loss but automatically turns on for alarm conditions, ensuring visibility during critical events. Built-in control switches and a keyswitch allow authorized personnel to acknowledge, silence, drill, and reset alarms while enclosure tamper supervision supports code compliance and asset protection. Surface or semi-flush mounting fits standard electrical boxes for straightforward retrofit or new installations. Ideal for fire monitoring, building security and surveillance integration, the ANN-80 streamlines event response—contact us to configure or order the ANN-80 for your facility.
Features
- Improves situational awareness with a backlit 80-character (20 x 4) LCD that mirrors the FACP display for faster, clearer decision-making
- Remote placement up to 6,000 ft via two-wire ANN-BUS keeps monitoring and control accessible across large sites
- Authorized control with keyswitch and dedicated acknowledge/silence/reset switches reduces response time and prevents unauthorized use
- Battery-conserving backlight that turns off during AC loss but reactivates on alarm, ensuring visibility when it matters most
- Tamper-supervised, surface or semi-flush mounting for simple installation and compliance with life-safety and security requirements
| General Information | |
|---|---|
| Brand Name | Fire-Lite Alarms by Honeywell |
| Manufacturer | Honeywell International, Inc |
| Product Name | ANN-80 Fire Annunciator |
| Product Type | Annunciator Module |
| Product Model | ANN-80 |
| Product Series | ANN |
| Country of Origin | US |
| Manufacturer Part Number | ANN-80 |
| Physical Characteristics | |
| Color | Red |
| Depth | 1.40" |
| Width | 6.90" |
| Height | 5.40" |
| Power Description | |
| Input Voltage | 18V DC, 28V DC |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Additional Information | Control switches for System Acknowledge, Signal Silence, Drill, and ResetControl switches can be independently enabled or disabled at the FACPKeyswitch enables/disables control switches and mechanically locks annunciator enclosureKeyswitch |
No matching specifications
Try a different term, such as a connector type or resolution.
Plan your purchase
Is this right for your project?
Confirm the model, required accessories and delivery needs before ordering.
- SKU:
- ANN-80
- Manufacturer part:
- ANN-80
How do I confirm compatibility?
Check the specifications and manufacturer documents for your existing system. Send us your model numbers and project requirements if you need help selecting equipment or accessories.
Ask a product specialistWhen will this item ship?
Availability is shown above. Special-order items and project quantities may need additional lead time. Contact us to confirm a delivery date before scheduling installation.
Shipping, freight and delivery detailsWhat should I know about returns?
Returns require an approved RMA. Consult the linked return policy for deadlines and eligibility. For standard non-defective returns, eligible factory-sealed items carry a 15% restocking fee and customer-paid return shipping; open-box and used items are refused. Defective and DOA claims follow the policy's separate terms. Special orders and other exclusions are final sale.
