QSC AP-5152 AcousticPerformance Series 2-Way Loudspeaker, 625W RMS, Black
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Key Features
- High-impact 625W RMS output delivers clear, high-SPL sound so large venues and control rooms need fewer cabinets and less amplification.
- DMT and axisymmetric waveguide provide uniform coverage and consistent intelligibility across audience areas—perfect for houses of worship, arenas, and monitoring rooms.
- Passive or bi-amplified operation lets integrators optimize channel count and system control, with QSC Intrinsic Correction tunings available for precise voicing.
- 15-inch woofer and 3-inch compression driver reproduce full bandwidth (44 Hz–18 kHz) with 96 dB sensitivity for accurate low end and detailed highs.
- Rugged enclosure with M10 suspension points and acoustically transparent grille simplifies discreet installation in security, surveillance, and themed-entertainment environments.
Quick Specifications
- Product Model
- AP-5152
- Brand Name
- QSC
- Product Line
- AcousticPerformance
- Product Name
- High-Power, 15" 2-Way, 75? Conical DMT
Product Information Tabs
Overview
When reliable, high-output sound is required across large or demanding spaces, the QSC AP-5152 loudspeaker delivers professional-grade performance and predictable coverage. This AcousticPerformance 2-way pro speaker combines a high-capacity 3-inch (76 mm) compression driver with a 15-inch woofer and a 625W RMS power rating to produce clear, full-bandwidth audio from 44 Hz to 18 kHz. The Directivity Matched Transition (DMT) and axisymmetric waveguide maintain uniform on- and off-axis response, improving voice intelligibility for paging, monitoring and AV presentations in venues, control rooms, and security/surveillance hubs. With 96 dB sensitivity and the option to run passive or bi-amplified, the AP-5152 gives system integrators flexibility to reduce channel counts or fine-tune performance with QSC Intrinsic Correction. Built for installed sound, the cabinet features M10 suspension points and a discreet, acoustically transparent grille that fits professional aesthetics. Environmentally friendly packaging and durable construction help lower lifecycle costs. Specify the QSC AP-5152 for installations that demand high SPL, accurate coverage, and reliable long-term operation—contact sales to configure this loudspeaker for your next project.
Features
- High-impact 625W RMS output delivers clear, high-SPL sound so large venues and control rooms need fewer cabinets and less amplification.
- DMT and axisymmetric waveguide provide uniform coverage and consistent intelligibility across audience areas—perfect for houses of worship, arenas, and monitoring rooms.
- Passive or bi-amplified operation lets integrators optimize channel count and system control, with QSC Intrinsic Correction tunings available for precise voicing.
- 15-inch woofer and 3-inch compression driver reproduce full bandwidth (44 Hz–18 kHz) with 96 dB sensitivity for accurate low end and detailed highs.
- Rugged enclosure with M10 suspension points and acoustically transparent grille simplifies discreet installation in security, surveillance, and themed-entertainment environments.
| General Information | |
|---|---|
| Brand Name | QSC |
| Manufacturer | QSC Audio |
| Product Line | AcousticPerformance |
| Product Name | High-Power, 15" 2-Way, 75? Conical DMT |
| Product Type | Speaker |
| Product Model | AP-5152 |
| Packaged Quantity | 1 |
| Manufacturer Part Number | AP-5152-BK |
| Technical Information | |
| Impedance | 8 ohms |
| Sensitivity | 96dB |
| Speaker Size | 15" |
| Crossover Type | 2-way |
| Audio | |
| RMS Output Power | 625W |
| Speaker Configuration | 2 |
| Maximum Frequency Response | 18 kHz |
| Minimum Frequency Response | 44Hz |
| Physical Characteristics | |
| Size | 15" |
| Color | Black |
| Depth | 15" |
| Width | 18" |
| Weight | 80lb |
| Product Information | |
| Diameter | 15" |
| Miscellaneous | |
| Features | 15" Woofer, 3" Compression Driver, Designed for Cinema Applications, Full-Bandwidth Reproduction |
| Environmentally Friendly | Yes |
| Environmental Certification | WEEE |
