APC AP7599 Rack PDU, Basic, Zero U, 14.4 kW, 208V, (24) C13, (4) C19, (2) L6-30R, 10' Cord
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 4
Key Features
- Zero U vertical design frees valuable rack U-space, enabling higher equipment density for servers, networking and surveillance systems
- High-capacity 14.4 kW, 208V / 50A distribution supports dense IT loads and critical security/monitoring infrastructure
- Mixed outlet set (24x C13, 4x C19, 2x L6-30R) provides flexible connections for servers, switches, NVRs and cameras
- Toolless mounting and cord retention brackets speed installation and keep power cabling neat and secure in racks and enclosures
- Resettable circuit breakers deliver fast recovery from overloads and protect attached equipment, minimizing downtime
- UL/CSA/METI certified components and a 2-year limited warranty give peace of mind for critical installations
Quick Specifications
- Product Model
- AP7599
- Brand Name
- APC by Schneider Electric
- Product Line
- Basic Rack
- Product Name
- Basic Rack 14.4kW PDU
Explore the details
Product information
AP7599
Overview
Optimize rack power for high-density IT, security and surveillance deployments with the APC by Schneider Electric AP7599 Basic Rack PDU. This Zero U rack PDU delivers 14.4 kW of reliable power at 208V (50A) while occupying no front-facing U space, so you can maximize server, switch and NVR density in network closets and data centers. With a versatile mix of 24 IEC C13, 4 IEC C19 and 2 NEMA L6-30R receptacles and a 10-foot Hubbell CS8365 plug, the AP7599 supports a broad range of equipment without additional adapters. Installation is fast and secure thanks to toolless vertical mounting and cord retention brackets, and resettable circuit breakers provide simple recovery from overload events — reducing service calls and downtime for security monitoring and critical networking gear. Built to meet UL, cUL and METI standards, this Basic Rack PDU is ideal for surveillance systems, access control, IT racks and remote monitoring deployments. Add dependable, space-saving power distribution to your rack — contact sales or order the AP7599 for your next deployment.
Features
- Zero U vertical design frees valuable rack U-space, enabling higher equipment density for servers, networking and surveillance systems
- High-capacity 14.4 kW, 208V / 50A distribution supports dense IT loads and critical security/monitoring infrastructure
- Mixed outlet set (24x C13, 4x C19, 2x L6-30R) provides flexible connections for servers, switches, NVRs and cameras
- Toolless mounting and cord retention brackets speed installation and keep power cabling neat and secure in racks and enclosures
- Resettable circuit breakers deliver fast recovery from overloads and protect attached equipment, minimizing downtime
- UL/CSA/METI certified components and a 2-year limited warranty give peace of mind for critical installations
| General Information | |
|---|---|
| Brand Name | APC by Schneider Electric |
| Manufacturer | Schneider Electric SA |
| Product Line | Basic Rack |
| Product Name | Basic Rack 14.4kW PDU |
| Product Type | PDU |
| Manufacturer Part Number | AP7599 |
| Technical Information | |
| PDU Type | Basic |
| Output Voltage | 208V |
| Receptacle Type | IEC 60320 C13, IEC 60320 C19, NEMA L6-30R |
| Receptacle Detail | 2 x NEMA L6-30R, 24 x IEC 60320 C13, 4 x IEC 60320 C19 |
| Physical Characteristics | |
| Color | Black |
| Depth | 3.74" |
| Height | 70.00" |
| Rack Height | 0U |
| Power Description | |
| Input Voltage | 208V |
| Plug/Connector Type | Hubbell CS8365C |
| Product Information | |
| Mount Type | Rack Mount |
| Protection Type | Overload Protection |
| Warranty | |
| Limited Warranty | 2-Year |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Certification | CSA, cUL Listed, METI Denan, UL Listed |
