Chief AS3A100 Camera Shelf for Tempo Flat Panel Wall Mount System
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Image of 9
Key Features
- Securely positions conferencing and surveillance cameras above or below displays for polished AV and security installations
- Toolless 6.27" height adjustment and lateral shift for fast, precise camera alignment without extra tools
- Universal 1/4-20 tripod mount compatibility and 6-inch shelf to fit most PTZ and fixed cameras
- Integrated cable management with window opening and side slots keeps wiring tidy for monitoring and security systems
- Quick rail-mounted installation on Tempo Flat Panel Wall Mounts, supporting up to 15 lb to handle professional cameras and accessories
Quick Specifications
- Product Model
- AS3A100
- Brand Name
- Chief by Legrand
- Manufacturer Part Number
- AS3A100
Product Information Tabs
Overview
Securely position conferencing and surveillance cameras with the Chief by Legrand AS3A100 camera shelf designed for the Tempo Flat Panel Wall Mount System. Built for integrators and AV professionals, this camera shelf provides a clean, dependable platform for video conferencing, security monitoring, and surveillance cameras. The 6-inch shelf and 15 lb weight capacity accommodate most PTZ and fixed cameras with a standard 1/4-20 tripod mount, while a 3.28-inch depth adjustment slot lets you fine-tune camera placement.
Toolless height-adjust knobs deliver 6.27 inches of travel so you can quickly align the camera vertically without interrupting installation flow. Lateral shift capability lets you slide and lock the shelf anywhere along the Tempo wall-plate rail for optimal framing. Built-in cable management windows and side slots keep power and data cables organized for a professional finish in security and monitoring deployments. The AS3A100 installs rapidly using strut-channel nuts with captive screws, minimizing onsite labor.
Ideal for boardrooms, huddle spaces, and security control rooms — add the AS3A100 to your next AV or security installation to improve camera placement and system reliability.
Features
- Securely positions conferencing and surveillance cameras above or below displays for polished AV and security installations
- Toolless 6.27" height adjustment and lateral shift for fast, precise camera alignment without extra tools
- Universal 1/4-20 tripod mount compatibility and 6-inch shelf to fit most PTZ and fixed cameras
- Integrated cable management with window opening and side slots keeps wiring tidy for monitoring and security systems
- Quick rail-mounted installation on Tempo Flat Panel Wall Mounts, supporting up to 15 lb to handle professional cameras and accessories
| General Information | |
|---|---|
| Brand Name | Chief by Legrand |
| Manufacturer Part Number | AS3A100 |
| Physical Characteristics | |
| Color | Black |
| Height | 20" |
| Dimensions | 13.25 x 8 x 2.5" |
| Maximum Weight Capacity | 15lb |
| Miscellaneous | |
| Features | Camera shelf can be installed between 12.7" (323 mm) to 28.26" (718 mm) of Tempo FP Wall Mount System center line, Camera shelf is 6"(152 mm) and has a 3.28" (83 mm) depth adjustment slot to facilitate placement of the camera using ¼"-20 screw, Fits most cameras with 0.25"-20 tripod mounting hole, Lateral shift allows you to position the camera shelf wherever you need it along the wall plate mounting rail, Quick and easy installation. The camera shelf glides and locks into place on the top or bottom rail of the Tempo Flat Panel Wall Mount System using strut channel nuts with captive screws, Toolless height-adjust knobs allow 6.27" (159 mm) of travel to easily position the camera shelf at the right height above or below the display, Weight capacity of 15 lb (6.8 kg), Window opening and slots along both sides of the vertical bracket facilitate cable management |
