AtlasIED ASP-MG2240 Amplified Sound Masking System with Onboard
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 2
Key Features
- All-in-one, compact sound masking controller with onboard amplification to simplify installations and reduce rack space
- Delivers reliable speech privacy across up to 7,000 sq ft or two independent 3,500 sq ft zones for flexible zoning and compliance
- Built-in DSP, preconfigured Chanaud presets and PC control software speed setup and reduce commissioning time
- Supports paging, background audio and mic/line inputs with selectable EQ and limiters to consolidate audio and security systems
- Push Here Diagnostic (PHD) automatically verifies speaker wiring and tap settings, saving time and avoiding field errors
Quick Specifications
- Product Model
- ASP-MG2240
- Brand Name
- AtlasIED
- Product Line
- Masking Devices
- Product Name
- ASP-MG2240 Amplified Sound Masking System
Explore the details
Product information
ASP-MG2240
Overview
Improve speech privacy and streamline audio for offices, healthcare clinics and secure facilities with the AtlasIED ASP-MG2240 Amplified Sound Masking System. This Pro sound masking generator combines two onboard 20 W (70.7V) amplifier channels (40 W RMS total), dual analog masking generators and internal DSP to provide consistent masking coverage for up to 7,000 sq ft or two separate 3,500 sq ft zones. Preconfigured Chanaud masking filters and intuitive PC control allow fast tuning to room acoustics while EQ, hi/lo pass filters and adjustable limiters protect audio integrity for paging and background music. The ASP-MG2240’s Speech Privacy Enhancement mode helps meet privacy and compliance needs (HIPAA-friendly configurations), and its Push Here Diagnostic (PHD) test verifies speaker wiring and tap settings to reduce commissioning callbacks. Ideal for facilities integrating security, surveillance or monitoring systems, this compact controller delivers clear masking, reliable paging and simplified maintenance. Contact your AtlasIED dealer to configure the ASP-MG2240 for your site or request a quote today.
Features
- All-in-one, compact sound masking controller with onboard amplification to simplify installations and reduce rack space
- Delivers reliable speech privacy across up to 7,000 sq ft or two independent 3,500 sq ft zones for flexible zoning and compliance
- Built-in DSP, preconfigured Chanaud presets and PC control software speed setup and reduce commissioning time
- Supports paging, background audio and mic/line inputs with selectable EQ and limiters to consolidate audio and security systems
- Push Here Diagnostic (PHD) automatically verifies speaker wiring and tap settings, saving time and avoiding field errors
| General Information | |
|---|---|
| Brand Name | AtlasIED |
| Manufacturer | AtlasIED |
| Product Line | Masking Devices |
| Product Name | ASP-MG2240 Amplified Sound Masking System |
| Product Type | Amplifier |
| Product Model | ASP-MG2240 |
| Country of Origin | CN |
| Manufacturer Part Number | ASP-MG2240 |
| Technical Information | |
| Bluetooth | No |
| Audio Channels | 2 |
| Classification | D |
| Audio | |
| Maximum Frequency Response | 15kHz |
| Minimum Frequency Response | 50Hz |
| Certifications | |
| TAA Compliant | Yes |
| NDAA Compliant | Yes |
| Energy & Performance | |
| Operating Power Consumption | 67W |
| Network & Communication | |
| Ethernet | No |
| Physical Characteristics | |
| Color | Pink |
| Depth | 11.30" |
| Width | 10.50" |
| Height | 1.80" |
| Weight | 6.00lb |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS, WEEE |
