Audio-Technica ATDM-1012 10-Channel Digital Smart Mixer
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 4
Key Features
- Streamlined, professional mixing for conferencing and monitoring: automatic smart-mixing and 4 gain-sharing/gating groups reduce noise and ensure clear speech for security, courtroom, and hospitality applications.
- Flexible I/O and expansion: 10 mic/line inputs plus USB audio I/O and up to 12 buses with Dante or Audio-Technica LINK expansion for larger AV and surveillance systems.
- Built-in voice enhancement: ten assignable AEC processors, compressors/de-essers and eight feedback suppressors deliver intelligible, echo-free audio in live monitoring and remote conferencing.
- Full-featured routing in a 1U rack: assign any input to any of 12 busses and control levels locally or via Web Remote Manager for easy system integration and remote administration.
- Reliable installation-grade design: balanced outputs, Euroblock connectors, and 100–240V compatibility simplify installation in AV, security, and networking environments.
Quick Specifications
- Product Model
- ATDM-1012
- Brand Name
- Audio-Technica
- Product Line
- SmartMixer
- Product Name
- ATDM-1012 Digital SmartMixer
Explore the details
Product information
ATDM-1012
Overview
Bring crystal-clear, installation-grade audio to conferencing, AV monitoring and security systems with the Audio-Technica ATDM-1012 Digital SmartMixer. This pro audio mixer combines a 14-input/12-bus matrix architecture — including 10 high-quality mic/line inputs and USB audio I/O — with smart mixing, ten assignable Acoustic Echo Cancellation processors and onboard feedback suppression to keep speech intelligible in demanding environments such as courtrooms, corporate boardrooms, hospitality venues and surveillance monitoring rooms. The unit’s flexible routing matrix and eight balanced outputs let you deliver isolated mix-minus feeds or zone-specific pickup to recording, PA and monitoring devices, while Dante-enabled expansion (ATDM-1012DAN) or Audio-Technica LINK lets you scale the system across networked installations. Front-panel controls and full Web Remote Manager access mean installers and operators can configure levels, EQ and routing on-site or over IP. Rack-mountable in a 1U chassis with Euroblock connectors and global power compatibility, the ATDM-1012 is built for reliable, long-term use in AV, security and monitoring deployments. Add the ATDM-1012 to your AV or security system today or contact us to configure it for your next installation.
Features
- Streamlined, professional mixing for conferencing and monitoring: automatic smart-mixing and 4 gain-sharing/gating groups reduce noise and ensure clear speech for security, courtroom, and hospitality applications.
- Flexible I/O and expansion: 10 mic/line inputs plus USB audio I/O and up to 12 buses with Dante or Audio-Technica LINK expansion for larger AV and surveillance systems.
- Built-in voice enhancement: ten assignable AEC processors, compressors/de-essers and eight feedback suppressors deliver intelligible, echo-free audio in live monitoring and remote conferencing.
- Full-featured routing in a 1U rack: assign any input to any of 12 busses and control levels locally or via Web Remote Manager for easy system integration and remote administration.
- Reliable installation-grade design: balanced outputs, Euroblock connectors, and 100–240V compatibility simplify installation in AV, security, and networking environments.
| General Information | |
|---|---|
| Brand Name | Audio-Technica |
| Product Line | SmartMixer |
| Product Name | ATDM-1012 Digital SmartMixer |
| Product Type | Audio Mixer |
| Product Model | ATDM-1012 |
| Manufacturer Part Number | ATDM1012 |
| Technical Information | |
| Operation Type | Digital |
| Audio | |
| Maximum Frequency Response | 60Hz |
| Interfaces/Ports | |
| Microphone | Yes |
| Number of Inputs | 14 |
| Number of Outputs | 12 |
| Physical Characteristics | |
| Depth | 12.77" |
| Width | 19.00" |
| Height | 1.73" |
| Power Description | |
| Input Voltage | 100-240V AC |
| Product Information | |
| Mount Type | Rack Mount |
| Miscellaneous | |
| Package Contents | ATDM-1012 unit, Euroblock connectors x22, Power Cable, Quick start guide |
