Audio-Technica ATND1061DAN Beamforming Ceiling Array Microphone with Onboard DSP

SKU: ATND1061DAN Audio-Technica
Audio Technica ATND1061DAN Beamforming Ceiling Array Microphone with Onboard DSP
Product images for Audio-Technica ATND1061DAN Beamforming Ceiling Array Microphone with Onboard DSP. 8 image(s) available. Click on image to view full size.

Key Features

  • Capture every voice clearly with beamforming array and onboard DSP that reduces noise and cancels echo for more productive meetings
  • Flexible coverage with six output channels and up to 32 user-defined pickup zones to match any boardroom layout
  • Seamless Dante networking and RJ-45 connectivity for easy integration into AV, security, and monitoring systems
  • Discreet ceiling design with flush, surface, or drop-mount options to preserve room aesthetics and simplify installation
  • Enterprise reliability with a 5-year limited warranty and professional-grade components for long-term deployments

Quick Specifications

Product Model
ATND1061DAN
Brand Name
Audio-Technica
Product Name
Beamforming Ceiling Array Microphone ATND1061
Product Type
Beamforming Array, Dante Solutions, Network Mics
View Full Technical Specifications

Explore the details

Product information

ATND1061DAN

Overview

Bring consistent, intelligible audio to every meeting with the Audio-Technica ATND1061DAN beamforming ceiling array microphone. Designed for boardrooms, conference rooms and integrated security or surveillance applications, this network microphone uses beamforming pickup and onboard DSP to prioritize speech while minimizing background noise and echo. Configure up to 32 user-defined pickup zones and deliver audio over six output channels to tailor coverage to any room layout. With a frequency response from 60 Hz to 18 kHz and Dante-enabled RJ-45 networking, the ATND1061DAN integrates cleanly into AV, networking and monitoring systems—plus Euroblock connectivity for hybrid setups. Its low-profile white enclosure supports flush, surface or drop-ceiling mounting so installations remain unobtrusive. The unit’s voice activity detection and advanced noise reduction make remote collaboration, surveillance monitoring and meeting recording more reliable and clearer. Backed by a 5-year limited warranty, the ATND1061DAN is ideal for IT, AV integrators and security teams who need dependable, high-quality audio. Add it to your conferencing, monitoring, or security deployment today.

Features

  • Capture every voice clearly with beamforming array and onboard DSP that reduces noise and cancels echo for more productive meetings
  • Flexible coverage with six output channels and up to 32 user-defined pickup zones to match any boardroom layout
  • Seamless Dante networking and RJ-45 connectivity for easy integration into AV, security, and monitoring systems
  • Discreet ceiling design with flush, surface, or drop-mount options to preserve room aesthetics and simplify installation
  • Enterprise reliability with a 5-year limited warranty and professional-grade components for long-term deployments
23 of 23 specifications
Technical specifications for Audio-Technica ATND1061DAN Beamforming Ceiling Array Microphone with Onboard DSP
General Information
Brand Name Audio-Technica
Manufacturer Audio-Technica U.S., Inc
Product Name Beamforming Ceiling Array Microphone ATND1061
Product Type Beamforming Array, Dante Solutions, Network Mics
Product Model ATND1061DAN
Product Series ATND
Application/Usage Boardroom, Conference Room, Meeting Room, Voice
Manufacturer Part Number ATND1061DAN
Technical Information
Polar Pattern Multi-directional
Host Interface Euroblock, RJ-45
Connectivity Technology Wired, Wireless
Audio
Maximum Frequency Response 18kHz
Minimum Frequency Response 60Hz
Certifications
TAA Compliant No
Microphone
Microphone Type Dynamic
Microphone Technology Dynamic
Physical Characteristics
Color White
Width 9.00"
Height 1.20"
Weight 44.00oz
Form Factor Ceiling Mount, Flush Mount, Surface Mount
Product Information
Mount Type Ceiling Mount, Flush Mount, Surface Mount
Warranty
Limited Warranty 5-Year

No matching specifications

Try a different term, such as a connector type or resolution.

Plan your purchase

Is this right for your project?

Confirm the model, required accessories and delivery needs before ordering.

SKU:
ATND1061DAN
Manufacturer part:
ATND1061DAN
How do I confirm compatibility?

Check the specifications and manufacturer documents for your existing system. Send us your model numbers and project requirements if you need help selecting equipment or accessories.

Ask a product specialist
When will this item ship?

Availability is shown above. Special-order items and project quantities may need additional lead time. Contact us to confirm a delivery date before scheduling installation.

Shipping, freight and delivery details
What should I know about returns?

Returns require an approved RMA. Consult the linked return policy for deadlines and eligibility. For standard non-defective returns, eligible factory-sealed items carry a 15% restocking fee and customer-paid return shipping; open-box and used items are refused. Defective and DOA claims follow the policy's separate terms. Special orders and other exclusions are final sale.

Read return eligibility and exclusions

Audio-Technica ATND1061DAN Beamforming Ceiling Array Microphone with Onboard DSP

ATND1061DAN

Price & options
