IDIS AV10956DN-28 10MP Omni-Directional Multi-Sensor Dome IP Camera with SNAPstream+, x 2.8mm Lenses

SKU: AV10956DN-28 IDIS

Special Order Item

This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.

Image of A8-AV10956DN
Product images for IDIS AV10956DN-28 10MP Omni-Directional Multi-Sensor Dome IP Camera with SNAPstream+, x 2.8mm Lenses. 1 image(s) available. Click on image to view full size.
NDAA Compliant TAA Compliant

Key Features

  • Capture more area with one device: dual 5MP sensors in a compact housing reduce the number of cameras needed and lower installation costs.
  • Preserve critical detail while minimizing bandwidth: H.265 with SNAPstream+ delivers over 50% data savings for efficient network monitoring.
  • Reliable 24/7 performance in tough environments: IP66 weatherproof and IK10 vandal-resistant housing for indoor/outdoor security.
  • Low-light color imaging: NightView and true day/night ICR preserve clear detail in challenging lighting for consistent surveillance.
  • Installer-friendly connectivity: PoE and remote management simplify deployment and ongoing maintenance across distributed sites.

Quick Specifications

Product Model
AV10956DN-28
Brand Name
IDIS
Product Line
ConteraIP
Product Name
ConteraIP MicroDome Duo LX Megapixel Camera
View Full Technical Specifications

Frequently Bought Together

Product Information Tabs

Overview

Designed for streamlined wide-area security and monitoring, the IDIS AV10956DN-28 omni-directional multi-sensor dome puts two 5MP sensors into one compact Panoramic Camera to cut equipment and labor costs. This ConteraIP device delivers crisp coverage with two 2.8mm lenses for broad fields of view while preserving critical detail at the edge of the scene. SNAPstream+ H.265 compression reduces bandwidth and storage requirements without sacrificing image quality, making it ideal for networked surveillance systems and centralized monitoring. Built for demanding installations, the camera features NightView for improved low-light color, true day/night mechanical IR cut, IP66 weatherproofing and IK10 vandal resistance to ensure continuous operation in indoor or outdoor environments. Remote focus, PoE support and an adjustable 3-axis gimbal speed deployment and simplify fine tuning. For security integrators and facility managers seeking a cost-effective panoramic solution that balances image clarity, resilience and network efficiency, the IDIS AV10956DN-28 is ready to protect your site—contact us to specify or add to your surveillance system today.

Features

  • Capture more area with one device: dual 5MP sensors in a compact housing reduce the number of cameras needed and lower installation costs.
  • Preserve critical detail while minimizing bandwidth: H.265 with SNAPstream+ delivers over 50% data savings for efficient network monitoring.
  • Reliable 24/7 performance in tough environments: IP66 weatherproof and IK10 vandal-resistant housing for indoor/outdoor security.
  • Low-light color imaging: NightView and true day/night ICR preserve clear detail in challenging lighting for consistent surveillance.
  • Installer-friendly connectivity: PoE and remote management simplify deployment and ongoing maintenance across distributed sites.
General Information
Brand Name IDIS
Manufacturer IDIS Americas
Product Line ConteraIP
Product Name ConteraIP MicroDome Duo LX Megapixel Camera
Product Model AV10956DN-28
Manufacturer Part Number AV10956DN-28
Technical Information
Lens Type Fixed
Night Vision Yes
Field of View H-FOV = 98°
Video Formats H.264, H.265, MJPEG
Lens Mount Type M12
Maximum Aperture f/2
Maximum Frame Rate 15fps
Minimum Focal Length 2.8mm
Connectivity Technology Wired
Effective Camera Resolution 5MP
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Certifications
TAA Compliant Yes
NDAA Compliant Yes
Ingress Protection Rating IP66
Display & Graphics
Number of Sensors 2
Maximum Video Resolution 2592 x 1944
Environmental Conditions
Operating Humidity 0.9
Maximum Operating Temperature 122°F (50°C)
Minimum Operating Temperature -40°F (-40°C)
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focal Length 2.8mm
Lens Included Yes
Maximum Focal Length 2.8mm
Network & Communication
Remote Management Yes
Others
Model Number Replaces AV10655DN-28, AV10856DN-28, AV6656DN-28
Physical Characteristics
Color White
Width 4.1"
Height 2.8"
Weight 2.20lb
Durability Dustproof, Impact Resistant, Vandalproof, Waterproof, Weatherproof
Form Factor Micro Dome
Power Description
Input Voltage 12V DC, 24V AC, 48V DC
Product Information
Length 6.4"
Storage
Storage Type Memory Card
Video
Maximum Resolution 1280 x 720
Miscellaneous
Features Back Light Compensation (BLC), Built-in Mechanical ICR, Day/Night, Gain Control, Highlight Compensation (HLC), Motion Detection, Noise Detection, Password Protection, Privacy Masking, White Balance, Wide Dynamic Range
Indoor/Outdoor Indoor, Outdoor
Country of Origin TW
Environmentally Friendly Yes
Impact Protection Rating IK10
Environmental Certification REACH, RoHS, WEEE
