IDIS AV20576DN-28 ConteraIP Omni LX 20MP WDR Omni-Directional Dome IP Camera, x 2.8mm Lens (Replaces AV12585DN)

SKU: AV20576DN-28 IDIS

Special Order: typically 2–6 weeks

Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.

Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.

A member of our team will check with the manufacturer and personally reply by email.

Image of A8-AV2057628
Product images for IDIS AV20576DN-28 ConteraIP Omni LX 20MP WDR Omni-Directional Dome IP Camera, x 2.8mm Lens (Replaces AV12585DN). 1 image(s) available. Click on image to view full size.
NDAA Compliant TAA Compliant

Key Features

  • Future-proof, modular multi-sensor design lets you reposition four sensors on a 360° Omni track for fully tailored coverage and fewer cameras on-site.
  • Ultra-detailed 20MP imaging with WDR and NightView ensures clear identification in mixed lighting and low-light environments.
  • SNAPstream+ compression reduces bandwidth and storage costs without compromising image quality for efficient networked surveillance.
  • Rugged IP66 / IK10 rating and wide operating temperature range protect outdoor and indoor deployments against weather and impact.
  • Remote-focus interchangeable lenses and 3-axis gimbals speed installation and enable precise field-of-view tuning as requirements change.

Quick Specifications

Product Model
AV20576DN-28
Brand Name
IDIS
Product Line
ConteraIP
Product Name
ConteraIP® Omni LX Megapixel Camera
View Full Technical Specifications

Explore the details

Product information

AV20576DN-28

Overview

Deliver continuous, high-resolution surveillance across large or complex sites with the IDIS ConteraIP Omni LX 20MP WDR Omni-Directional Dome IP Camera. Built for flexible, long-term deployments, this multi-sensor panoramic camera gives security teams the ability to configure four independently placed 2.8mm sensors around a 360° magnetic Omni track and fine-tune views with 3-axis gimbals and remote-focus lenses. The result is fewer devices to manage, seamless coverage with Wide Dynamic Range (WDR) and NightView for low-light clarity, and support for SNAPstream+ compression to reduce bandwidth and storage costs. Rated IP66 and IK10 and compliant with TAA/NDAA, the ConteraIP Omni LX is suitable for demanding indoor and outdoor applications—retail, transportation hubs, campuses and critical infrastructure. Easy to mount (ceiling, wall, corner or flush), it simplifies installation and future upgrades while maintaining enterprise-grade video quality. For scalable, resilient monitoring that adapts as your needs evolve, choose the IDIS ConteraIP Omni LX—contact sales to configure your surveillance solution or add it to your system design.

Features

  • Future-proof, modular multi-sensor design lets you reposition four sensors on a 360° Omni track for fully tailored coverage and fewer cameras on-site.
  • Ultra-detailed 20MP imaging with WDR and NightView ensures clear identification in mixed lighting and low-light environments.
  • SNAPstream+ compression reduces bandwidth and storage costs without compromising image quality for efficient networked surveillance.
  • Rugged IP66 / IK10 rating and wide operating temperature range protect outdoor and indoor deployments against weather and impact.
  • Remote-focus interchangeable lenses and 3-axis gimbals speed installation and enable precise field-of-view tuning as requirements change.
45 of 45 specifications
Technical specifications for IDIS AV20576DN-28 ConteraIP Omni LX 20MP WDR Omni-Directional Dome IP Camera, x 2.8mm Lens (Replaces AV12585DN)
General Information
Brand Name IDIS
Manufacturer IDIS Americas
Product Line ConteraIP
Product Name ConteraIP® Omni LX Megapixel Camera
Product Type Network Camera
Product Model AV20576DN-28
Country of Origin TW
Manufacturer Part Number AV20576DN-28
Technical Information
Field of View Horizontal
Video Formats H.264 / AVC, H.265 / HEVC, MJPEG, MPEG-4 Visual
Lens Mount Type M12
Maximum Aperture f/1.6
Maximum Frame Rate 15fps
Wide Dynamic Range Yes
Minimum Focal Length 2.80mm
Connectivity Technology Wired
Effective Camera Resolution 5MP
Camera
Image Sensor Type CMOS
Certifications
TAA Compliant Yes
NDAA Compliant Yes
Ingress Protection Rating IP66
Display & Graphics
Number of Sensors 4
Environmental Conditions
Operating Humidity 90%
Maximum Operating Temperature 122°F
Minimum Operating Temperature -40°F
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focal Length 2.8mm
Lens Included Yes
Maximum Focal Length 2.80mm
Network & Communication
Remote Management Yes
Physical Characteristics
Color White
Height 3.10"
Durability Dustproof, Impact Resistant, Waterproof, Weatherproof
Form Factor Dome
Power Description
Input Voltage 12V DC, 24V AC, 48V DC
Product Information
Diameter 7.70"
Mount Type Ceiling Mount, Corner Mount, Flush Mount, Wall Mount
Product Replacements & Other Alternatives
Model Number Replaces AV12176DN-08, AV12176DN-28, AV12176DN-NL, AV12275DN-08, AV12275DN-28, AV12275DN-NL, AV12276DN-08, AV12276DN-28, AV12276DN-NL, AV12565DN, AV12585DN, AV12586DN, AV12586PM, AV12975DN-08, AV12975DN-NL, AV12976DN-08, AV12976DN-28, AV12976DN-NL,
Storage
Storage Type SD Card
Video
Maximum Resolution 1280 x 720
Miscellaneous
Features 3D Digital Noise Reduction, Back Light Compensation (BLC), Cross Line Detection, Gain Control, Highlight Compensation (HLC), Human Detection, Motion Detection, Multi-view Stream, Password Protection, Vehicle Detection, White Balance, Wide Dynamic Range
Indoor/Outdoor Indoor, Outdoor
Environmentally Friendly Yes
Impact Protection Rating IK10
Environmental Certification REACH, RoHS, WEEE
