IDIS AV20576RS ConteraIP Omni LX RS 20MP WDR Omni-Directional Dome IP Camera, 3.3-6.6mm Lens (Replaces AV20476RS and AV8476RS)

SKU: AV20576RS IDIS
Image of A8-AV20576RS
Product images for IDIS AV20576RS ConteraIP Omni LX RS 20MP WDR Omni-Directional Dome IP Camera, 3.3-6.6mm Lens (Replaces AV20476RS and AV8476RS). 1 image(s) available. Click on image to view full size.
NDAA Compliant TAA Compliant

Key Features

  • Deliver complete 360° situational awareness with four adjustable gimbals, reducing blind spots and simplifying coverage planning.
  • Capture critical evidence with 20MP resolution and wide dynamic range for clear identification in complex lighting.
  • Maintain reliable 24/7 monitoring with NightView™ infrared and weatherproof IP66 / IK10 durability for indoor and outdoor sites.
  • Optimize network resources using SNAPstream+™ to cut bandwidth and storage needs without sacrificing image quality.
  • Integrate quickly into enterprise security systems with PoE power options, remote management, and support for H.264/H.265 codecs.

Quick Specifications

Brand Name
IDIS
Manufacturer
IDIS Americas
Product Line
ConteraIP
Product Name
ConteraIP® Omni LX Remote Setup Megapixel Camera
View Full Technical Specifications

Frequently Bought Together

Product Information Tabs

Overview

Provide uninterrupted, all-angle security for high-traffic or wide-area environments with the IDIS ConteraIP Omni LX RS panoramic camera. Built as a professional network camera for security and surveillance, it combines a 20MP sensor with four adjustable gimbals to deliver true 360° coverage and ultra-detailed imagery for retail floors, transportation hubs, campuses, and critical infrastructure. NightView™ infrared and wide dynamic range ensure reliable monitoring in low-light and contrasty scenes, while SNAPstream+™ minimizes bandwidth and storage costs—making it ideal for multi-site deployments and limited-network environments. Rugged IP66 and IK10 ratings protect the unit from weather and impact, reducing maintenance and downtime for outdoor installations. Flexible varifocal optics (3.3–6.6mm) and support for H.264/H.265 codecs simplify integration with existing VMS and NVR solutions. Specify the IDIS ConteraIP Omni LX RS when you need scalable, high-resolution surveillance that balances image quality with operational efficiency—contact your security integrator to evaluate coverage or add this panoramic camera to your next project.

Features

  • Deliver complete 360° situational awareness with four adjustable gimbals, reducing blind spots and simplifying coverage planning.
  • Capture critical evidence with 20MP resolution and wide dynamic range for clear identification in complex lighting.
  • Maintain reliable 24/7 monitoring with NightView™ infrared and weatherproof IP66 / IK10 durability for indoor and outdoor sites.
  • Optimize network resources using SNAPstream+™ to cut bandwidth and storage needs without sacrificing image quality.
  • Integrate quickly into enterprise security systems with PoE power options, remote management, and support for H.264/H.265 codecs.
General Information
Brand Name IDIS
Manufacturer IDIS Americas
Product Line ConteraIP
Product Name ConteraIP® Omni LX Remote Setup Megapixel Camera
Product Type Network Camera
Product Model AV20576RS
Manufacturer Part Number AV20576RS
Technical Information
Lens Type Varifocal
Night Vision Yes
Optical Zoom 2x
Field of View H-FOV = 42°-96°
Video Formats H.264, H.265, MJPEG, MPEG-4
Maximum Aperture f/1.8
Night Vision Type Infrared
Number of IR LEDs 6
Maximum Frame Rate 30fps
Minimum Focal Length 3.3mm
Connectivity Technology Wired
Effective Camera Resolution 5MP
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Night Vision Distance 98.43 ft
Certifications
TAA Compliant Yes
NDAA Compliant Yes
Ingress Protection Rating IP66
Display & Graphics
Number of Sensors 4
Maximum Video Resolution 2592 x 1944
Environmental Conditions
Operating Humidity 0.9
Maximum Operating Temperature 122°F (50°C)
Minimum Operating Temperature -40°F (-40°C)
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focal Length 3.3-6.6mm
Lens Included Yes
Maximum Focal Length 6.6mm
Network & Communication
Remote Management Yes
Others
Model Number Replaces AV12375RS, AV12376RS, AV20476RS, AV20565DN, AV20585PM, AV8476RS
Physical Characteristics
Color White
Height 4.9"
Weight 5.20lb
Durability Dustproof, Impact Resistant, Waterproof, Weatherproof
Power Description
Input Voltage 24V AC, 24V DC, 48V DC
Product Information
Diameter 8.8"
Mount Type Ceiling Mount, Wall Mount
Storage
Storage Type Memory Card
Video
Maximum Resolution 1280 x 720
Miscellaneous
Features 3D Digital Noise Reduction, Alarm Detection, Built-in OSD Function, Cross Line Detection, Gain Control, Human Detection, Motion Detection, Noise Detection, Password Protection, Tamper Detection, Vehicle Detection, White Balance, Wide Dynamic Range
Indoor/Outdoor Indoor, Outdoor
Country of Origin TW
Environmentally Friendly Yes
Impact Protection Rating IK10
Environmental Certification REACH, RoHS, WEEE
