AVYCON AVC-ELN41FT/2.8 Diversity Series 4MP H.265 Waterproof IR Turret IP Camera, 2.8mm Fixed Lens, White

SKU: AVC-ELN41FT28 MPN: AVC-ELN41FT/2.8 AVYCON

Special Order: typically 2–6 weeks

Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.

Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.

A member of our team will check with the manufacturer and personally reply by email.

Image of BX-ELN41FT28
Product images for AVYCON AVC-ELN41FT/2.8 Diversity Series 4MP H.265 Waterproof IR Turret IP Camera, 2.8mm Fixed Lens, White. 1 image(s) available. Click on image to view full size.

Key Features

  • 24/7 reliable surveillance with 4MP resolution and up to 100 ft infrared for clear day/night monitoring
  • Lower bandwidth and storage costs using H.265 compression plus onboard microSD for local recording
  • IP67 weatherproof turret design built for indoor or outdoor deployment, resisting dust and heavy rain
  • Flexible, fast installation with PoE (802.3af) or 12V DC power and standard RJ-45 network connectivity
  • Intelligent analytics including motion, cross-line detection, WDR and 3D DNR to reduce false alarms and improve event capture

Quick Specifications

Product Model
AVC-ELN41FT
Brand Name
AVYCON
Product Line
Diversity
Product Name
4MP H.265 IR Water-Proof Turrent Network Camera
View Full Technical Specifications

Explore the details

Product information

AVC-ELN41FT/2.8

Overview

Built for dependable security and round-the-clock monitoring, the AVYCON AVC-ELN41FT/2.8 Diversity Series turret camera delivers crisp 4MP images and reliable IR illumination up to 100 ft so you don’t miss critical details day or night. This H.265-enabled IP camera reduces network load and storage costs while supporting onboard microSD recording for standalone surveillance. The 2.8mm fixed lens provides a wide field of view ideal for perimeter, parking, retail or entrance monitoring.

Designed for real-world deployments, the AVC-ELN41FT/2.8 combines True WDR, 3D noise reduction and intelligent video analytics (motion and cross-line detection) to improve detection accuracy and minimize false alerts. The IP67-rated housing and turret form factor ensure durable outdoor performance, and flexible power options—PoE (802.3af) or 12V DC—simplify installation and integration with existing networked security systems.

Choose the AVYCON Diversity Series turret camera for scalable, cost-effective surveillance and remote monitoring. Contact sales to specify for retail, warehouse, parking or campus security applications.

Features

  • 24/7 reliable surveillance with 4MP resolution and up to 100 ft infrared for clear day/night monitoring
  • Lower bandwidth and storage costs using H.265 compression plus onboard microSD for local recording
  • IP67 weatherproof turret design built for indoor or outdoor deployment, resisting dust and heavy rain
  • Flexible, fast installation with PoE (802.3af) or 12V DC power and standard RJ-45 network connectivity
  • Intelligent analytics including motion, cross-line detection, WDR and 3D DNR to reduce false alarms and improve event capture
47 of 47 specifications
Technical specifications for AVYCON AVC-ELN41FT/2.8 Diversity Series 4MP H.265 Waterproof IR Turret IP Camera, 2.8mm Fixed Lens, White
General Information
Brand Name AVYCON
Manufacturer Avycon
Product Line Diversity
Product Name 4MP H.265 IR Water-Proof Turrent Network Camera
Product Type Network Camera
Product Model AVC-ELN41FT
Manufacturer Part Number AVCELN41FT28
Technical Information
Lens Type Fixed
Aspect Ratio 16:9
Night Vision Yes
Field of View Diagonal, Horizontal, Vertical
Video Formats H.264, H.265, MJPEG
Lens Mount Type M12
Maximum Aperture f/1.6
Night Vision Type Infrared (IR)
Maximum Frame Rate 30fps
Wide Dynamic Range Yes
Minimum Focal Length 2.80mm
Connectivity Technology Wired
Field of View (Vertical) 50.00°
Effective Camera Resolution 4MP
Camera
Image Sensor Type CMOS
Night Vision Distance 100.00'
Certifications
Ingress Protection Rating IP67
Display & Graphics
Maximum Video Resolution 2560 x 1440
Environmental Conditions
Operating Humidity 95%
Maximum Operating Temperature 140°F
Minimum Operating Temperature -22°F
Exposure
Longest Shutter Speed 1/2 Second
Shortest Shutter Speed 1/100000 Second
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focal Length 2.8mm
Lens Included Yes
Maximum Focal Length 2.80mm
Network & Communication
Remote Management Yes
Physical Characteristics
Color White
Weight 1.01lb
Durability Dustproof, Waterproof
Form Factor Turret
Power Description
Input Voltage 12V DC
Product Information
Diameter 3.80"
Mount Type Ceiling Mount, Junction Box Mount, Wall Mount
Storage
Storage Type Memory Card
Video
Maximum Resolution 1280 x 720
Miscellaneous
Features 3D Noise Reduction, Back Light Compensation (BLC), Built-in Microphone, Cross Line Detection, Day/Night, Highlight Compensation (HLC), Motion Detection, Region of Interest, SD Card Local Storage, Wide Dynamic Range
Environmentally Friendly Yes
Environmental Certification EU RoHS, EU WEEE, REACH
