Warehouse: United States

JBL Professional AW266-BK High Power 2-Way All Weather Loudspeaker with x 12" LF, Black

SKU: AW266 JBL Professional

Special Order Item

This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.

Image of JF-AW266
Product images for JBL Professional AW266-BK High Power 2-Way All Weather Loudspeaker with x 12" LF, Black. 2 image(s) available. Click on image to view full size.

Key Features

  • Delivers reliable, high-impact outdoor audio for security, perimeter monitoring and public-address applications
  • Powerful 500W RMS performance with a 400W 70/100V transformer for flexible distributed-audio installations
  • 12" Differential Drive low-frequency driver and Progressive Transition waveguide provide punchy bass and controlled 60° x 60° coverage for clear voice intelligibility
  • All-glass composite enclosure and 14-gauge stainless steel grille with foam and mesh protect components in harsh, corrosive environments
  • Included heavy-duty stainless steel U-bracket supports fast, secure vertical or horizontal mounting to speed installation and reduce labor
  • Weather-resistant design and high sensitivity (98 dB) keep SPL and clarity consistent in outdoor and industrial sites

Quick Specifications

Product Model
AW266
Brand Name
JBL Professional
Product Name
AW266 High Power 2-Way All Weather Loudspeaker with 1 x 12" LF
Product Type
Speaker
View Full Technical Specifications

Product Information Tabs

Overview

For secure outdoor venues and robust public-address systems, the JBL Professional AW266 High Power 2-Way All-Weather Loudspeaker delivers dependable, intelligible sound where it matters most. Engineered for perimeter monitoring, surveillance audio, stadium paging and outdoor retail or transportation hubs, the AW266 pairs a 12" Differential Drive low-frequency driver with a 1.5" compression driver and Progressive Transition waveguide to produce focused 60° x 60° coverage and clear speech reproduction. With 500W RMS capability, a 400W 70/100V transformer for distributed systems, and 98 dB sensitivity, this speaker balances high output with flexible installation options. The multilayer glass-composite enclosure, 14-gauge stainless steel grille and stainless mesh resist corrosion and impact, minimizing maintenance in harsh environments. Built-in mounting hardware enables quick vertical or horizontal deployment for PA, security and surveillance applications. Specify the AW266 when you need durable, high-output outdoor audio for monitoring, emergency notification or everyday announcements — contact us to discuss deployment or order for your next outdoor audio/security project.

Features

  • Delivers reliable, high-impact outdoor audio for security, perimeter monitoring and public-address applications
  • Powerful 500W RMS performance with a 400W 70/100V transformer for flexible distributed-audio installations
  • 12" Differential Drive low-frequency driver and Progressive Transition waveguide provide punchy bass and controlled 60° x 60° coverage for clear voice intelligibility
  • All-glass composite enclosure and 14-gauge stainless steel grille with foam and mesh protect components in harsh, corrosive environments
  • Included heavy-duty stainless steel U-bracket supports fast, secure vertical or horizontal mounting to speed installation and reduce labor
  • Weather-resistant design and high sensitivity (98 dB) keep SPL and clarity consistent in outdoor and industrial sites
General Information
Brand Name JBL Professional
Manufacturer Harman International Industries, Inc
Product Name AW266 High Power 2-Way All Weather Loudspeaker with 1 x 12" LF
Product Type Speaker
Product Model AW266
Product Series AE
Manufacturer Part Number AW266
Technical Information
Impedance 8 ohms
Sensitivity 98dB
Crossover Type 2-way
Audio
RMS Output Power 500W
Maximum Frequency Response 18 kHz
Minimum Frequency Response 51Hz
Physical Characteristics
Size 12"
Color White
Depth 17.8"
Width 28.8"
Height 16.1"
Weight 55.5lb
Durability Weather Resistant
Miscellaneous
Features 2262H Differential Driver® Low- Frequency Driver, 2432H High Frequency Compression Driver, 60° x 60° Coverage, All Fiberglass Enclosure, Large PT Progressive Transition waveguide for excellent pattern control and low distortion
Country of Origin MX
