i3 AX67R4 3MP Outdoor Vandal IR Dome IP Camera, 4mm Fixed Lens, White

SKU: AX67R4 i3 International

Special Order Item

This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.

i3 AX67R4 3 Megapixel Indoor/Outdoor Network Camera - Color, Monochrome
Product images for i3 AX67R4 3MP Outdoor Vandal IR Dome IP Camera, 4mm Fixed Lens, White. 1 image(s) available. Click on image to view full size.

Key Features

  • Continuous, reliable surveillance day and night with Smart IR and night vision up to 25 m (82 ft) for clear identification after dark
  • Durable outdoor protection (IP67, IK10) keeps the unit operational in harsh, exposed environments to reduce maintenance and downtime
  • Crisp 3MP imaging with a 4 mm fixed lens provides wide-area coverage and improved forensic detail for security monitoring
  • Simplified installation and lower cabling costs via PoE plus triple streaming (H.264/MJPEG) for efficient network performance and storage
  • Flexible mounting and intelligent features (corridor mode, D-WDR, tamper detection, privacy masking) adapt to retail, campus, and industrial deployments

Quick Specifications

Brand Name
i3 International
Manufacturer
i3 International Inc.
Product Name
Ax67R4 3MP IR Fixed Lens Dome
Product Type
Network Camera
View Full Technical Specifications

Product Information Tabs

Overview

For reliable perimeter and facility security, the i3 International AX67R4 3MP outdoor vandal IR dome camera delivers durable, high-quality surveillance where it matters most. This network dome camera pairs a 3MP sensor with a 4 mm fixed lens to capture sharp, wide-angle footage ideal for parking lots, entrances, and retail aisles. Smart IR illumination and day/night functionality extend effective monitoring to approximately 25 m (82 ft) in low light. Built to withstand tough conditions, the aluminum housing is IP67-rated and IK10-compliant for moisture, dust and impact resistance, minimizing service calls and protecting your investment. PoE support streamlines installation while triple streaming (H.264/MJPEG), D-WDR and 3D noise reduction improve image clarity across challenging scenes and simplify remote monitoring and recording. The AX67R4 is a practical, scalable choice for integrators and security managers seeking a robust, networked surveillance solution. Add this i3 International dome camera to your security system for dependable outdoor monitoring — ideal for retail, transportation, and campus applications.

Features

  • Continuous, reliable surveillance day and night with Smart IR and night vision up to 25 m (82 ft) for clear identification after dark
  • Durable outdoor protection (IP67, IK10) keeps the unit operational in harsh, exposed environments to reduce maintenance and downtime
  • Crisp 3MP imaging with a 4 mm fixed lens provides wide-area coverage and improved forensic detail for security monitoring
  • Simplified installation and lower cabling costs via PoE plus triple streaming (H.264/MJPEG) for efficient network performance and storage
  • Flexible mounting and intelligent features (corridor mode, D-WDR, tamper detection, privacy masking) adapt to retail, campus, and industrial deployments
General Information
Brand Name i3 International
Manufacturer i3 International Inc.
Product Name Ax67R4 3MP IR Fixed Lens Dome
Product Type Network Camera
Product Model AX67R4
Manufacturer Part Number AX67R4
Technical Information
Lens Type Fixed
Night Vision Yes
Field of View Horizontal, Vertical
Video Formats H.264, MJPEG
Maximum Aperture f/1.6
Maximum Frame Rate 30fps
Video Signal Format NTSC, PAL
Minimum Focal Length 4mm
Connectivity Technology Wired
Field of View (Vertical) 53°
Field of View (Horizontal) 72°
Effective Camera Resolution 3MP
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Night Vision Distance 82.02 ft
Certifications
Ingress Protection Rating IP67
Display & Graphics
Maximum Video Resolution 2048 x 1536
Environmental Conditions
Operating Humidity 0.9
Maximum Operating Temperature 122°F (50°C)
Minimum Operating Temperature -4°F (-20°C)
Exposure
Longest Shutter Speed 1/25 Second
Shortest Shutter Speed 1/10000 Second
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focal Length 4mm
Lens Included Yes
Maximum Focal Length 4mm
Network & Communication
Remote Management Yes
Physical Characteristics
Color White
Height 3.2"
Weight 1.01lb
Durability Dust Resistant, Impact Resistant, Moisture Resistant, Vandal Resistant, Waterproof
Form Factor Dome
Product Information
Diameter 4.4"
Mount Type Corner Mount, Flush Mount, Pendant Mount, Pole Mount, Surface Mount, Wall Mount
Storage
Storage Type Memory Card
Video
Maximum Resolution 1280 x 720
Warranty
Limited Warranty 3-Year
Miscellaneous
Features 3D Noise Reduction, Back Light Compensation (BLC), Built-in Card Reader, Day/Night, Digital Wide Dynamic Range (D-WDR), Privacy Masking, Tamper Detection
Indoor/Outdoor Indoor, Outdoor
Country of Origin TW
Environmentally Friendly Yes
Impact Protection Rating IK10
Environmental Certification RoHS
