Securitron B100 Secondary Voltage Module
Image of 1
Key Features
- Provide precise secondary voltages (fixed 12 VDC or jumper-selectable 5–18 VDC) so routers, modems and other IT/security devices run reliably without extra power bricks
- Deliver up to 4 A of protected output with overload, short-circuit and over-temperature safeguards to keep surveillance and access control systems online
- Compact, snap-in design and fast-on connectors simplify field installation and free up enclosure space for denser power distribution
- Compatible with Securitron AQL power supplies to add economical secondary 12 V outputs or custom voltage combinations across a site
- Visual input/output LEDs and fault reporting to the host supply speed troubleshooting and reduce maintenance time
Quick Specifications
- Product Model
- B100
- Sector
- Access Control
- Brand Name
- Securitron by ASSA ABLOY
- Product Name
- AQL B100 Secondary Voltage Module
Frequently Bought Together
Securitron B100 Secondary Voltage Module
$73.33
3 items selected
Total: $703.47
Explore the details
Product information
B100
Overview
Optimize power delivery for access control, security and surveillance systems with the Securitron by ASSA ABLOY B100 Secondary Voltage Module. This compact power distribution module steps down AQL primary voltage to a user-defined output—either a fixed 12 VDC or a jumper-selectable 5–18 VDC—providing up to 4 A of protected output for devices like routers, modems, readers and monitoring equipment. Built-in overload, short-circuit and over-temperature protection plus visual LED indicators and fault reporting to the host supply reduce downtime and simplify diagnostics for integrators and service teams. Small form-factor, snap-in mounting standoffs and fast-on connectors make field upgrades and retrofits fast and clean, eliminating the need for separate 12 V battery sets in dual-voltage systems. Backed by Securitron’s MagnaCare lifetime replacement, the B100 delivers reliable, low-heat performance to extend service life and lower total cost of ownership. Add flexible secondary power to your access control, surveillance or IT deployments—order the B100 for seamless integration with AQL-powered systems or contact us for installation support.
Features
- Provide precise secondary voltages (fixed 12 VDC or jumper-selectable 5–18 VDC) so routers, modems and other IT/security devices run reliably without extra power bricks
- Deliver up to 4 A of protected output with overload, short-circuit and over-temperature safeguards to keep surveillance and access control systems online
- Compact, snap-in design and fast-on connectors simplify field installation and free up enclosure space for denser power distribution
- Compatible with Securitron AQL power supplies to add economical secondary 12 V outputs or custom voltage combinations across a site
- Visual input/output LEDs and fault reporting to the host supply speed troubleshooting and reduce maintenance time
| General Information | |
|---|---|
| Sector | Access Control |
| Brand Name | Securitron by ASSA ABLOY |
| Manufacturer | ASSA ABLOY |
| Product Name | AQL B100 Secondary Voltage Module |
| Product Type | Secondary Voltage Module |
| Product Model | B100 |
| Country of Origin | US |
| Manufacturer Part Number | B100 |
| Technical Information | |
| Amperage | 4.00A |
| Physical Characteristics | |
| Color | Blue, Green |
| Depth | 1.50" |
| Width | 2.50" |
| Height | 4.00" |
| Power Description | |
| Output Current | 4.0000A |
| Voltage Rating | 12V, 24V |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
