Bosch B465 Universal Dual Path Communication Module
Image of 1
Key Features
- Simplifies migration from PSTN to IP/cellular with no control-panel reprogramming, reducing installation time and service calls
- Dual-path reporting via built-in Ethernet plus optional Conettix plug-in cellular modules for continuous central-station monitoring
- UL 864 10th Edition (per NFPA 72) approval for commercial fire and burglary applications, allowing use as primary or secondary path
- Auto-detects Contact ID, SIA and legacy pulse formats for seamless integration with existing intrusion and fire panels
- Four configurable inputs and three configurable outputs for flexible integration with alarm, supervisory and building systems
- NDAA and CSFM compliant with a 3-year limited warranty for long-term reliability and procurement confidence
Quick Specifications
- Product Model
- B465MP
- Brand Name
- Bosch
- Product Name
- Universal Dual Path Communicator
- Product Type
- Communication Module
Frequently Bought Together
Bosch B465 Universal Dual Path Communication Module
$310.87
6 items selected
Total: $1,725.47
Product Information Tabs
Overview
Modernize legacy alarm systems and ensure uninterrupted central-station reporting with the Bosch B465 Universal Dual Path Communicator. This Bosch communication module converts PSTN digital dialer or dry contact outputs into secure IP signals and supports optional Conettix plug-in cellular modules (B440–B444) to create a redundant dual-path reporting solution. UL 864 10th Edition approval (per NFPA 72) permits use in commercial fire and burglary applications, while auto-detection of Contact ID, SIA and pulse formats eliminates control-panel reprogramming—saving time on installations and reducing field service visits.
The B465 accepts 24 VDC (or 16.5 VAC) power, supports four configurable inputs and three outputs, and integrates easily with surveillance, security and building automation systems. NDAA and CSFM compliance make it suitable for public and private sector deployments that require proven interoperability and code compliance. Use the B465 to transition sites from PSTN to IP/cellular monitoring without disrupting existing panel programming. Contact our sales team or order the Bosch B465 today to upgrade your alarm monitoring and maintain reliable, centralized security reporting.
Features
- Simplifies migration from PSTN to IP/cellular with no control-panel reprogramming, reducing installation time and service calls
- Dual-path reporting via built-in Ethernet plus optional Conettix plug-in cellular modules for continuous central-station monitoring
- UL 864 10th Edition (per NFPA 72) approval for commercial fire and burglary applications, allowing use as primary or secondary path
- Auto-detects Contact ID, SIA and legacy pulse formats for seamless integration with existing intrusion and fire panels
- Four configurable inputs and three configurable outputs for flexible integration with alarm, supervisory and building systems
- NDAA and CSFM compliant with a 3-year limited warranty for long-term reliability and procurement confidence
| General Information | |
|---|---|
| Brand Name | Bosch |
| Manufacturer | Bosch |
| Product Name | Universal Dual Path Communicator |
| Product Type | Communication Module |
| Product Model | B465MP |
| Manufacturer Part Number | B465 |
| Technical Information | |
| Device Supported | Control Panel |
| Certifications | |
| NDAA Compliant | Yes |
| Environmental Conditions | |
| Maximum Operating Temperature | 120.2°F (49°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Physical Characteristics | |
| Depth | 1.5" |
| Width | 5" |
| Height | 3.1" |
| Power Description | |
| Input Voltage | 24V DC |
| Product Information | |
| Installation Type | Hybrid |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | Approved for Commercial Fire/Burglary applications as sole, primary, or secondary communication path, Compatible with control panels using Contact ID, SIA, Pulse3MP/1MPor Pulse4MP/2MPcommunication formats, Modem II, Modem IIe, and Modem IIIa2MP(auto detecting), No control panel reprogramming required to install, Supports Ethernet directly and optional plug-in cellular communication technologies in single, or multi-path configurations, Supports four configurable inputs and three configurable outputs |
| Country of Origin | CN |
| Environmental Certification | CSFM |
