APC BX1000M Back-UPS 1000, 1000VA, 120V, Compact Tower, AVR, LCD, NEMA Outlets, 4-Surge

APC BX1000M Back UPS 1000, 1000VA, 120V, Compact Tower, AVR, LCD, Eight NEMA Outlets (4 Surge)
Product images for APC BX1000M Back-UPS 1000, 1000VA, 120V, Compact Tower, AVR, LCD, NEMA Outlets, 4-Surge. 4 image(s) available. Click on image to view full size.

Key Features

  • Reliable 1000VA backup power keeps critical servers, routers, surveillance DVRs and workstations running through outages
  • Automatic Voltage Regulation (AVR) stabilizes brownouts without draining the battery, extending runtime and component life
  • Eight battery‑backup & surge outlets plus four surge‑only outlets protect and power a mix of equipment (PCs, switches, storage, cameras)
  • Clear LCD and audible alarms give instant system status and fault alerts for fast troubleshooting and monitoring
  • Hot‑swappable, maintenance‑free VRLA battery reduces downtime and simplifies on‑site service
  • Compact tower design fits network closets and rack shelves, delivering enterprise protection in small footprints

Quick Specifications

Product Model
BX1000M
Sector
Data Comm & Networking
Brand Name
APC by Schneider Electric
Product Line
Back-UPS Pro
View Full Technical Specifications

Frequently Bought Together

This Item
APC BX1000M Back-UPS 1000, 1000VA, 120V, Compact Tower, AVR, LCD, NEMA Outlets, 4-Surge

APC BX1000M Back-UPS 1000, 1000VA, 120V, Compact Tower, AVR, LCD, NEMA Outlets, 4-Surge

$248.81

Frequently Bought Together (1 items)

2 items selected

Total: $321.45

Explore the details

Product information

BX1000M

Overview

Keep critical IT and security systems online with the APC by Schneider Electric Back-UPS Pro BX1000M UPS. Designed for small offices, network closets and surveillance installations, this line-interactive UPS delivers 1000VA of protected power and built-in AVR to stabilize voltage swings without unnecessary battery use. The BX1000M supports up to eight battery-backed outlets and four surge‑only outlets, protecting a mix of servers, routers, modems, NVRs/DVRs and monitoring workstations. An intuitive LCD panel and audible alarms provide real-time status and fault notifications to reduce mean time to repair, while a hot‑swappable VRLA battery lets you replace batteries quickly with minimal disruption. With a fast 10 ms transfer time and sine wave output, the UPS preserves sensitive electronics and ensures clean power for storage devices and security cameras. Energy Star certified and compact enough for constrained spaces, the BX1000M is ideal for businesses that require dependable power for networking, surveillance and monitoring systems. Protect your infrastructure and maintain uptime—deploy the BX1000M to safeguard your equipment today.

Features

  • Reliable 1000VA backup power keeps critical servers, routers, surveillance DVRs and workstations running through outages
  • Automatic Voltage Regulation (AVR) stabilizes brownouts without draining the battery, extending runtime and component life
  • Eight battery‑backup & surge outlets plus four surge‑only outlets protect and power a mix of equipment (PCs, switches, storage, cameras)
  • Clear LCD and audible alarms give instant system status and fault alerts for fast troubleshooting and monitoring
  • Hot‑swappable, maintenance‑free VRLA battery reduces downtime and simplifies on‑site service
  • Compact tower design fits network closets and rack shelves, delivering enterprise protection in small footprints
49 of 49 specifications
Technical specifications for APC BX1000M Back-UPS 1000, 1000VA, 120V, Compact Tower, AVR, LCD, NEMA Outlets, 4-Surge
General Information
Sector Data Comm & Networking
Brand Name APC by Schneider Electric
Manufacturer Schneider Electric SA
Product Line Back-UPS Pro
Product Name Back UPS Pro BX1000M, Compact Tower, 1000VA, AVR, LCD, 120V
Product Type Line-interactive UPS
Application/Usage Business, Computer, Electronic Equipment, Gaming Console, Home, Modem, Router, Storage Device
Country of Origin PH
Manufacturer Part Number BX1000M
Technical Information
AVR Yes
Energy Saving Yes
Hot Swappable Yes
Transfer Time 10ms
Output Voltage 120V
Receptacle Type NEMA 5-15R
Receptacle Detail 8 x NEMA 5-15R
Dataline Protection Coaxial, RJ-45
Number of Batteries 1
Input Receptacle Type NEMA 5-15P
Backup/Run Time (Full Load) 4.3min
Backup/Run Time (Half Load) 13.5min
Number of Surge-only Outlets 4
Number of Battery & Surge Outlets 8
Battery Information
Battery Chemistry Sealed Lead Acid (VRLA)
Replaceable Battery Yes
Battery Recharge Time 12.00hr
Battery Characteristics Leak-proof, Maintenance-free, Sealed
Maximum Storage Relative Humidity 0.95
Certifications
Energy Star Yes
Controls/Indicators
Status Indicators Yes
Environmental Conditions
Sound Emission 45dB
Operating Humidity 0-95%
Maximum Storage Elevation 50000'
Maximum Operating Elevation 10000'
Maximum Operating Temperature 104°F
Management
Alarm Low Battery, On Battery, Overload
Physical Characteristics
Color Black
Depth 12.20"
Width 3.58"
Height 7.48"
Weight 15.87lb
Form Factor Tower
Power Description
Input Voltage 88-139V AC
Waveform Type Pure Sine Wave
Plug/Connector Type NEMA 5-15P
Warranty
Limited Warranty 3-Year
Additional Warranty Information 3 years repair or replace
Miscellaneous
Environmentally Friendly Yes
Environmental Certification California (CEC) Battery Charger, California Proposition 65, ENERGY STAR V2.0 (USA), TUV C-US certified
