Keyscan CA150 Single Access Control Panel, PoE Equipped
Image of 2
Key Features
- Simplified PoE installation reduces cabling and labor costs while powering the controller via IEEE 802.3af PoE
- Scalable single-door solution supporting up to 32,000 users to grow with your campus or multi-site deployment
- High reliability with dual processors and flash memory for fast credential validation and minimal downtime
- TCP/IP network module enables remote monitoring, management and integration with security and surveillance systems
- Robust metal enclosure with tamper switch, supervised inputs and heavy-duty relays for secure lock control and alarm integration
Quick Specifications
- Product Model
- CA150
- Brand Name
- Keyscan by dormakaba
- Product Name
- Single Door PoE Equipped Controller
- Product Type
- Door Access Control Panel
Explore the details
Product information
CA150
Overview
Built for installers and security managers who need a compact, reliable single-door solution, the Keyscan by dormakaba CA150 single access control panel delivers flexible, networked access control with reduced installation complexity. This PoE-equipped controller (IEEE 802.3af) supports up to 32,000 users and can run on 12VDC or Power over Ethernet, making it ideal for new installations or seamless expansion of existing Keyscan systems. Dual processors and flash memory provide fast credential processing and resilient performance, while the onboard TCP/IP module enables centralized monitoring, remote configuration and easy integration with surveillance and alarm systems. The CA150 includes two reader ports, four supervised inputs and two heavy-duty relays inside a tamper-resistant metal enclosure for reliable lock and sensor control. Choose the CA150 to simplify deployment, scale access for growing facilities, and maintain continuous security monitoring across offices, data centers or retail locations. Contact your representative to specify the CA150 for your next access control or security integration project.
Features
- Simplified PoE installation reduces cabling and labor costs while powering the controller via IEEE 802.3af PoE
- Scalable single-door solution supporting up to 32,000 users to grow with your campus or multi-site deployment
- High reliability with dual processors and flash memory for fast credential validation and minimal downtime
- TCP/IP network module enables remote monitoring, management and integration with security and surveillance systems
- Robust metal enclosure with tamper switch, supervised inputs and heavy-duty relays for secure lock control and alarm integration
| General Information | |
|---|---|
| Brand Name | Keyscan by dormakaba |
| Manufacturer | dormakaba Holding |
| Product Name | Single Door PoE Equipped Controller |
| Product Type | Door Access Control Panel |
| Product Model | CA150 |
| Product Series | CA |
| Application/Usage | Door |
| Manufacturer Part Number | CA150 |
| Technical Information | |
| Number of Doors | 1 |
| Number of Users | 32000 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Network & Communication | |
| Ethernet Technology | Ethernet |
| Physical Characteristics | |
| Color | Black |
| Power Description | |
| Input Voltage | 12V DC |
| Miscellaneous | |
| Package Contents | 1-black metal enclosure with lock and tamper switch, CA150B ACU board, PoE ready TCP/IP module |
