Comprehensive CHE-HDBTWP121K Intetrator Series HDBaseT 4K 18G Audio Wall Plate Extender Kit up to 230' for Single Gang HDMI and High Speed USB 2.0
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Image of 4
Key Features
- Simplify AV and security installs by extending 4K HDMI, analog audio and USB 2.0 up to 230' over a single Cat5e/6 cable
- Preserve crisp 18 Gbps HDMI 2.0 video and HDCP 2.2 compliance for reliable 4K content distribution and surveillance feeds
- Built-in USB 2.0 high-speed pass-through (up to 190 Mbps) enables touchscreens, KVM, capture devices and peripherals in remote rooms
- 24V Power-over-Cable (PoC) reduces local power requirements—power TX or RX from a single supply to streamline wall-plate deployments
- Analog 3.5mm audio and bidirectional RS-232 pass-through provide flexible control and audio options for monitoring, conferencing and control systems
- Low-profile single-gang wall-plate form factor fits classrooms, boardrooms, and security monitoring stations for a clean, professional installation
Quick Specifications
- Product Model
- CHE-HDBTWP121K
- Brand Name
- Comprehensive
- Product Name
- CHE-HDBTWP121K Video Extender Transmitter/Receiver
- Product Type
- Video Extender Transmitter/Receiver
Frequently Bought Together
Comprehensive CHE-HDBTWP121K Intetrator Series HDBaseT 4K 18G Audio Wall Plate Extender Kit up to 230' for Single Gang HDMI and High Speed USB 2.0
$521.92
2 items selected
Total: $546.87
Product Information Tabs
Overview
Deliver reliable 4K video, audio and USB connectivity to remote displays and control stations with the Comprehensive CHE-HDBTWP121K HDBaseT wall plate extender kit. Engineered for AV, IT and security integrators, this wall-plate solution extends HDMI 2.0 (18 Gbps) video, analog audio and high-speed USB 2.0 up to 230' over a single Cat5e/6 run—preserving HDCP 2.2 compliance and supporting HDR and CEC pass-through. The kit’s USB 2.0 channel supports touch panels, KVM and capture devices, while bidirectional RS-232 enables centralized control of displays, cameras and signal processors. 24V PoC capability simplifies installations by powering either the transmitter or receiver from one supply, reducing outlet needs at wall locations. Compact single-gang aesthetics keep conference rooms, classrooms and surveillance monitoring stations tidy while delivering enterprise-grade performance. Ideal for security monitoring, digital signage, distance learning and boardroom AV deployments, the CHE-HDBTWP121K streamlines long-distance connectivity without compromising image quality. Specify this Comprehensive HDBaseT wall-plate kit for cost-effective installs—order now for conference rooms, control centers and surveillance applications.
Features
- Simplify AV and security installs by extending 4K HDMI, analog audio and USB 2.0 up to 230' over a single Cat5e/6 cable
- Preserve crisp 18 Gbps HDMI 2.0 video and HDCP 2.2 compliance for reliable 4K content distribution and surveillance feeds
- Built-in USB 2.0 high-speed pass-through (up to 190 Mbps) enables touchscreens, KVM, capture devices and peripherals in remote rooms
- 24V Power-over-Cable (PoC) reduces local power requirements—power TX or RX from a single supply to streamline wall-plate deployments
- Analog 3.5mm audio and bidirectional RS-232 pass-through provide flexible control and audio options for monitoring, conferencing and control systems
- Low-profile single-gang wall-plate form factor fits classrooms, boardrooms, and security monitoring stations for a clean, professional installation
| General Information | |
|---|---|
| Brand Name | Comprehensive |
| Manufacturer | Comprehensive Connectivity Company |
| Product Name | CHE-HDBTWP121K Video Extender Transmitter/Receiver |
| Product Type | Video Extender Transmitter/Receiver |
| Product Model | CHE-HDBTWP121K |
| Manufacturer Part Number | CHEHDBTWP121K |
| Technical Information | |
| Cable Type | Category 7 |
| Application/Usage | Classroom, Conference Room, Meeting Room |
| Media Type Supported | Twisted Pair |
| Connectivity Technology | Wired |
| Maximum Operating Distance | 230' |
| Number of Input Devices Supported | 1 |
| Number of Output Devices Supported | 1 |
| Display & Graphics | |
| Maximum Video Resolution | 3840 x 2160 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Number of USB Ports | 3 |
| Number of HDMI Inputs | 1 |
| Number of HDMI Outputs | 1 |
| Number of Network (RJ-45) Ports | 2 |
| Physical Characteristics | |
| Color | Black, White |
| Depth | 1.2" |
| Width | 4" |
| Height | 1.8" |
| Form Factor | Wall Plate |
| Video | |
| Graphics Modes | 4K |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Country of Origin | CN |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
