SoundTube CM62-EZ-II-WH Coaxial In-Ceiling Speaker, 6.5", White
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Image of 5
Key Features
- Plug-and-play installation with an easy-access six-position tap switch for 25/70.7/100V and 16 ohm bypass, reducing onsite labor and simplifying stocking
- High efficiency (90 dB sensitivity) and 16-ohm option lower amplification costs while delivering clear audio across large spaces
- Exceptional voice intelligibility with a 10 kHz, 80° coverage pattern—ideal for paging, voice alarm and security announcements
- EN54-24, UL 1480 and CE certified for compliant voice alarm and commercial installations, supporting surveillance and monitoring systems
- Durable painted steel grille, plenum-rated wiring terminal and IPX3 moisture resistance for long-lasting performance in a variety of environments
- Tile-bridge and conduit accessories included for secure mounting and neat, code-compliant cable routing
Quick Specifications
- Product Model
- CM62-EZ-II-WH
- Brand Name
- SoundTube
- Manufacturer Part Number
- CM62-EZ-II-WH
Product Information Tabs
Overview
When clear, reliable audio is mission-critical, the SoundTube CM62-EZ-II-WH coaxial in-ceiling speaker delivers professional performance for paging, security and monitoring applications. This 6.5 in professional speaker combines a treated fiber woofer and silk dome tweeter to provide a wide frequency response (65 Hz–22 kHz) and 90 dB sensitivity, ensuring announcements and alarms are intelligible across lobbies, retail floors, and control rooms. The six-position tap switch supports 25/70.7/100V systems and a 16-ohm transformer bypass, streamlining system design and reducing amplification costs. Built for compliance, the CM62-EZ-II-WH is EN54-24 listed and UL-certified for voice alarm use, and its IPX3 rating and painted steel grille stand up to demanding commercial environments. Integrated features like a ceramic 10 AWG plenum terminal, thermal fuse and included tile bridge make installation faster and code-friendly. Ideal for integrators specifying audio for security, surveillance paging, and public-address systems—choose the CM62-EZ-II-WH for dependable, standards-compliant sound. Contact us to specify this speaker for your next project or add it to your security and monitoring deployments.
Features
- Plug-and-play installation with an easy-access six-position tap switch for 25/70.7/100V and 16 ohm bypass, reducing onsite labor and simplifying stocking
- High efficiency (90 dB sensitivity) and 16-ohm option lower amplification costs while delivering clear audio across large spaces
- Exceptional voice intelligibility with a 10 kHz, 80° coverage pattern—ideal for paging, voice alarm and security announcements
- EN54-24, UL 1480 and CE certified for compliant voice alarm and commercial installations, supporting surveillance and monitoring systems
- Durable painted steel grille, plenum-rated wiring terminal and IPX3 moisture resistance for long-lasting performance in a variety of environments
- Tile-bridge and conduit accessories included for secure mounting and neat, code-compliant cable routing
| General Information | |
|---|---|
| Brand Name | SoundTube |
| Manufacturer Part Number | CM62-EZ-II-WH |
| Audio | |
| Maximum Frequency Response | 22 kHz |
| Minimum Frequency Response | 65 Hz |
| Physical Characteristics | |
| Color | White |
| Miscellaneous | |
| Features | High-quality black or white painted finish Custom colors available, Included accessories tile bridge, UL-listed 0.5" flex conduit clamp, paint shield, and two wire nuts, Incorporates a painted steel grille for lasting durability, Optional accessories color-coded (green) preconstruction bracket (AC-CMEZ-6/8-PCB), junction box, Reduced amplification costs with maximum efficiency including 90 dB sensitivity and 16 ohms impedance |
| Package Contents | Conduit Plate, Euroblock, Grille, Paint Mask |
| Environmentally Friendly | Yes |
| Environmental Certification | CE, RoHS, UL |
