LEA Professional CONNECT 64D Connect Series Half-Rack Smart Amp, 4-Channel, 60W per Channel
Image of 2
Key Features
- Half-rack (1/2U) design saves rack space while delivering full pro-audio performance for small-to-medium installations
- Four channels at 60W per channel provide reliable coverage for paging, background music and security audio zones
- Per-channel Hi-Z (70V/100V) or Lo-Z switching simplifies speaker wiring and reduces the need for external transformers
- Dante network audio plus built-in Wi‑Fi AP, venue Wi‑Fi and FAST Ethernet offer flexible, secure networking and remote monitoring
- Web browser UI, cloud control and 96kHz DSP enable fast system tuning and centralized management to minimize site visits
- Highly efficient Class-D topology with Smart Power Bridge and a 5-year warranty for dependable, low-maintenance operation
Quick Specifications
- Product Model
- CONNECT 64D
- Brand Name
- LEA Professional
- Product Name
- Connect 64D A/V Receivers and Amplifiers
- Product Type
- A/V Receiver and Amplifier
Explore the details
Product information
CONNECT 64D
Overview
Optimize audio distribution and centralized control in small-to-medium facilities with the LEA Professional CONNECT 64D pro amplifier. This half-rack smart amp delivers four channels of clear, dependable amplification at 60W per channel, making it ideal for paging, background music, and security audio tied into surveillance and monitoring systems. Installers benefit from per-channel Hi-Z (70V/100V) or Lo-Z switching to wire mixed speaker loads without extra equipment, while integrators will appreciate Dante network audio plus three connectivity modes—built-in Wi‑Fi access point, venue Wi‑Fi, or FAST Ethernet over CAT5/CAT6—for secure, low-latency audio over IP. Onboard 96kHz DSP, Web UI and cloud control let technicians tune, monitor and update systems remotely, reducing maintenance trips and downtime. Efficient Class-D outputs with Smart Power Bridge keep operating costs low and performance high. Backed by a 5-year limited warranty, the CONNECT 64D is a compact, network-ready pro amplifier tailored for security, surveillance and monitoring applications. Specify the CONNECT 64D for your next paging, BGM or integrated security installation, or contact us to discuss system design.
Features
- Half-rack (1/2U) design saves rack space while delivering full pro-audio performance for small-to-medium installations
- Four channels at 60W per channel provide reliable coverage for paging, background music and security audio zones
- Per-channel Hi-Z (70V/100V) or Lo-Z switching simplifies speaker wiring and reduces the need for external transformers
- Dante network audio plus built-in Wi‑Fi AP, venue Wi‑Fi and FAST Ethernet offer flexible, secure networking and remote monitoring
- Web browser UI, cloud control and 96kHz DSP enable fast system tuning and centralized management to minimize site visits
- Highly efficient Class-D topology with Smart Power Bridge and a 5-year warranty for dependable, low-maintenance operation
| General Information | |
|---|---|
| Brand Name | LEA Professional |
| Product Name | Connect 64D A/V Receivers and Amplifiers |
| Product Type | A/V Receiver and Amplifier |
| Manufacturer Part Number | CONNECT 64D |
| Audio | |
| Maximum Frequency Response | 20 kHz |
| Minimum Frequency Response | 20Hz |
| Physical Characteristics | |
| Width | 8.58" |
| Height | 1.71" |
| Weight | 7lb |
| Power Description | |
| Input Voltage | 100-240V AC |
| Product Information | |
| Length | 11.82" |
| Tuner | |
| Frequency Band | 20-20000Hz |
| Warranty | |
| Limited Warranty | 5-Year |
