LEA Professional CONNECT 702 19" 2-Channel Amplifier, 700W per Channel
Image of 4
Key Features
- Reliable 700W-per-channel output in a lightweight 19" rack form lets you power medium-scale security, paging and AV systems with consistent headroom.
- Flexible LoZ and HiZ (70V/100V) selectable per channel simplifies integration with distributed speaker networks and ceiling paging.
- Three native network options (built-in Wi‑Fi AP, venue Wi‑Fi, or Ethernet) plus AWS IoT cloud access enable remote monitoring, configuration and centralized control.
- Built-in 96 kHz DSP with crossovers, parametric EQs and speaker limiters protects speakers, optimizes coverage and reduces on-site tuning time.
- Smart Power Bridge lets you double a channel’s output when needed, providing adaptable power distribution without sacrificing system control.
Quick Specifications
- Product Model
- CONNECT 702
- Brand Name
- LEA Professional
- Product Line
- CONNECT
- Product Name
- CONNECT 702 Amplifier
Explore the details
Product information
CONNECT 702
Overview
Deliver consistent, reliable audio for security, surveillance, paging and AV installations with the LEA Professional CONNECT 702 2-channel amplifier. Purpose-built for small to medium-scale deployments, the CONNECT 702 supplies 700 watts per channel and selectable LoZ or HiZ (70V/100V) outputs so integrators can wire distributed speaker arrays or direct low-impedance loads without added transformers. Network-first connectivity—built-in Wi‑Fi access point, venue Wi‑Fi or Cat5/6 Ethernet—plus AWS IoT and an intuitive WebUI provide secure remote monitoring, firmware management and real-time load reporting for easier system maintenance and faster troubleshooting. The high-resolution 96 kHz DSP includes multiple crossover filters, 8 parametric EQs and user-configurable speaker limiters to protect speakers and fine-tune coverage for sensitive areas like surveillance rooms and public safety paging. Lightweight and energy-efficient Class D amplification with universal switching power supply (100–240VAC) reduces rack space and power draw, while TAA/NDAA compliance and a 3-year warranty give peace of mind for commercial and government installs. Ideal for security, monitoring and commercial AV projects—contact us to specify the CONNECT 702 for your next deployment.
Features
- Reliable 700W-per-channel output in a lightweight 19" rack form lets you power medium-scale security, paging and AV systems with consistent headroom.
- Flexible LoZ and HiZ (70V/100V) selectable per channel simplifies integration with distributed speaker networks and ceiling paging.
- Three native network options (built-in Wi‑Fi AP, venue Wi‑Fi, or Ethernet) plus AWS IoT cloud access enable remote monitoring, configuration and centralized control.
- Built-in 96 kHz DSP with crossovers, parametric EQs and speaker limiters protects speakers, optimizes coverage and reduces on-site tuning time.
- Smart Power Bridge lets you double a channel’s output when needed, providing adaptable power distribution without sacrificing system control.
| General Information | |
|---|---|
| Brand Name | LEA Professional |
| Manufacturer | LEA Professional |
| Product Line | CONNECT |
| Product Name | CONNECT 702 Amplifier |
| Product Type | Amplifier |
| Product Model | CONNECT 702 |
| Manufacturer Part Number | CONNECT 702 |
| Technical Information | |
| Impedance | 8.00O |
| Audio Channels | 2 |
| Classification | D |
| Audio | |
| RMS Output Power | 700.0000W |
| Maximum Frequency Response | 20.0kHz |
| Minimum Frequency Response | 20.0000Hz |
| Total Harmonic Distortion (THD) | 0.1% – 0.5% |
| Certifications | |
| Energy Star | No |
| TAA Compliant | Yes |
| NDAA Compliant | Yes |
| Network & Communication | |
| Ethernet | Yes |
| Physical Characteristics | |
| Width | 19.00" |
| Weight | 7.50lb |
| Power Description | |
| Input Voltage | 100V AC, 240V AC |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Indoor/Outdoor | Indoor |
| Environmental Certification | RoHS |
