RDL DB-SH1 Stereo Headphone Amplifier, Decora Panel with User Level Control
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 1
Key Features
- Compact Decora panel design for clean, wall-mounted installation in control rooms and public displays
- Long-life VCA front-panel level control for noise-free, repeatable headphone volume adjustments
- Drives high- and low-impedance headphones with over 50 mW output for reliable monitoring
- Balanced/unbalanced L/R inputs with wide sensitivity (-20 dBV to +20 dBu) for easy integration with pro or consumer sources
- Stereo/mono mode and durable 1/4" headphone jack for flexible use in surveillance, broadcast, and translation applications
Quick Specifications
- Product Model
- DB-SH1
- Brand Name
- Radio Design Labs
- Product Name
- Stereo Headphone Amplifier - Decora Panel with User Level Control
- Product Type
- Headphone Amplifier
Frequently Bought Together
RDL DB-SH1 Stereo Headphone Amplifier, Decora Panel with User Level Control
$199.25
9 items selected
Total: $475.06
Explore the details
Product information
DB-SH1
Overview
Get dependable, low-noise headphone monitoring in a compact Decora panel with the Radio Design Labs DB-SH1 stereo headphone amplifier. Purpose-built for pro audio and security environments, the DB-SH1 accepts balanced or unbalanced left/right inputs (–20 dBV to +20 dBu) and delivers more than 50 mW into both high- and low-impedance headphones for clear, consistent monitoring. The front-mounted long-life potentiometer controls matched VCAs so audio never passes through the control — ensuring years of noise-free level adjustment critical for surveillance, monitoring, and broadcasting tasks. Configure input sensitivity and stereo/mono operation via recessed side switches before installation, and rely on rugged 1/4" jacks and Decora-style mounting for a tidy, tamper-resistant panel fit. Powered from a 24 Vdc supply (operates on 12 Vdc with reduced headroom), the DB-SH1 integrates easily into translation booths, museum audio displays, interview studios, and security control rooms. Add the DB-SH1 to your AV or security setup for professional headphone monitoring — contact your supplier or order today.
Features
- Compact Decora panel design for clean, wall-mounted installation in control rooms and public displays
- Long-life VCA front-panel level control for noise-free, repeatable headphone volume adjustments
- Drives high- and low-impedance headphones with over 50 mW output for reliable monitoring
- Balanced/unbalanced L/R inputs with wide sensitivity (-20 dBV to +20 dBu) for easy integration with pro or consumer sources
- Stereo/mono mode and durable 1/4" headphone jack for flexible use in surveillance, broadcast, and translation applications
| General Information | |
|---|---|
| Brand Name | Radio Design Labs |
| Manufacturer | Radio Design Labs, Inc |
| Product Name | Stereo Headphone Amplifier - Decora Panel with User Level Control |
| Product Type | Headphone Amplifier |
| Product Model | DB-SH1 |
| Product Series | D |
| Application/Usage | Headphone, Studio |
| Country of Origin | US |
| Manufacturer Part Number | DB-SH1 |
| Certifications | |
| TAA Compliant | No |
| Physical Characteristics | |
| Color | Black |
| Depth | 1.80" |
| Width | 1.70" |
| Height | 4.10" |
| Form Factor | Wall Mount |
| Product Information | |
| Mount Type | Wall Mount |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Certification | WEEE |
