RCI DE8310S Delayed Egress Electromagnetic Lock with Built-In Sounder
Image of 1
Key Features
- Secure delayed egress that protects perimeter doors and meets life-safety and loss-prevention needs without replacing existing hardware
- Built-in sounder and visible red/green status panel for clear local notification and reduced wiring complexity
- Field-selectable 15 or 30 second release delay with nuisance delay options to balance safety and security
- 1200 lb holding force for reliable physical security while supporting access control and surveillance integrations
- Remote and local monitoring via SPDT/DPDT relays for easy connection to security systems and building management
- Plug-in wiring harnesses, keyhole mounting and easy-access wiring cavity for fast retrofit installation and lower labor costs
Quick Specifications
- Product Model
- DE8310S8
- Brand Name
- RCI by dormakaba
- Product Name
- DE8310S8 Electromagnetic Lock
- Product Type
- Magnetic Lock
Frequently Bought Together
RCI DE8310S Delayed Egress Electromagnetic Lock with Built-In Sounder
$1,101.63
13 items selected
Total: $1,765.69
Explore the details
Product information
DE8310S8
Overview
Protect perimeter doors and maintain code-compliant egress control with the RCI by dormakaba DE8310S delayed egress electromagnetic lock. This all-in-one magnetic lock with built-in sounder delivers 1200 lb holding force and a field-selectable 15 or 30 second release delay, giving facility managers a dependable balance of security and life-safety. Because the DE8310S installs without replacing existing door hardware, it’s an economical retrofit solution for retail loss prevention, healthcare, education and commercial facilities.
Designed for straightforward integration with access control and surveillance systems, the DE8310S offers SPDT/DPDT relay outputs for local and remote monitoring, a visible red/green status indicator, nuisance-delay settings, and surge protection. The internal sounder and keyswitch simplify on-site notification and override procedures while reducing external wiring. With anodized finish and robust mounting features, this magnetic lock supports high-traffic single outswing doors and provides consistent performance under daily use.
Specify the RCI DE8310S for projects where reliable security, monitoring and code-compliant delayed egress are critical — contact your rep or add to cart to secure perimeter entry points today.
Features
- Secure delayed egress that protects perimeter doors and meets life-safety and loss-prevention needs without replacing existing hardware
- Built-in sounder and visible red/green status panel for clear local notification and reduced wiring complexity
- Field-selectable 15 or 30 second release delay with nuisance delay options to balance safety and security
- 1200 lb holding force for reliable physical security while supporting access control and surveillance integrations
- Remote and local monitoring via SPDT/DPDT relays for easy connection to security systems and building management
- Plug-in wiring harnesses, keyhole mounting and easy-access wiring cavity for fast retrofit installation and lower labor costs
| General Information | |
|---|---|
| Brand Name | RCI by dormakaba |
| Manufacturer | dormakaba Holding |
| Product Name | DE8310S8 Electromagnetic Lock |
| Product Type | Magnetic Lock |
| Product Model | DE8310S8 |
| Product Series | DE8310 |
| Manufacturer Part Number | DE8310S8 |
| Technical Information | |
| Door Supported | Single Door |
| Others | |
| Model Number Replaces | DE8310KAS8, DE8310SX28F |
| Physical Characteristics | |
| Color | Silver |
| Depth | 2.12" |
| Width | 11.75" |
| Height | 2.87" |
| Product Information | |
| Finishing | Anodized |
| Holding Force | 1200 lb |
| Miscellaneous | |
| Features | No Residual Magnetism, Surge Protection |
| Country of Origin | CA |
| Additional Information | With internal sound |
