AtlasIED DPA804 800W Networkable 4-Channel Power Amplifier with Optional Dante Network Audio
Image of 2
Key Features
- Versatile installation modes: operate as 70.7V/100V commercial amp or 4Ω/8Ω low‑impedance stereo to simplify inventory and support mixed paging, background music and foreground audio requirements.
- Networked DSP control: web GUI and PC/iOS/Android control with configurable EQ, limiters, filters and delay for precise tuning, remote monitoring and system optimization.
- Expandable I/O and Dante option: four balanced inputs plus an accessory slot for a DPA‑DAC4 Dante card or mic/aux card, enabling flexible routing and network audio integration.
- User-friendly operation: front-panel or GUI assignable level control, assignable mute and GPIO triggers, and audio-sense auto power down to reduce energy use and simplify day-to-day operation.
- Enterprise-ready reliability: 800W RMS across four channels in a compact 1U rack, NDAA compliance and RoHS certification for secure, long-term deployments.
Quick Specifications
- Product Model
- DPA804
- Brand Name
- AtlasIED
- Product Line
- Amps/Attenuator
- Product Name
- DPA804 Multi-Channel Network Amplifier
Explore the details
Product information
DPA804
Overview
Deploy reliable, customizable audio amplification across security, AV and paging systems with the AtlasIED DPA804 networkable pro amplifier. This DSP-controlled 4-channel amplifier delivers up to 800W RMS total power and supports flexible operating modes—70.7V/100V constant-voltage or 4Ω/8Ω low-impedance—so integrators can serve paging, background music, and foreground stereo with a single unit. Networked control via Ethernet and a browser-based GUI (also PC/iOS/Android compatible) provides remote monitoring, EQ, delay, limiters and schedule-based activation to simplify system management and monitoring for surveillance and security installations. An accessory slot accepts an optional DPA-DAC4 Dante receiver or mic/aux card, enabling easy integration of network audio and microphone inputs for emergency paging or live announcements. Front-panel controls, assignable mute/GPIO triggers and audio-sense auto power down make daily operation straightforward for end users. Compact 1U design and robust DSP make the DPA804 ideal for schools, retail, corporate AV, and security monitoring rooms. Specify the AtlasIED DPA804 to streamline installs and improve onsite audio control—contact us for quotes or application guidance.
Features
- Versatile installation modes: operate as 70.7V/100V commercial amp or 4Ω/8Ω low‑impedance stereo to simplify inventory and support mixed paging, background music and foreground audio requirements.
- Networked DSP control: web GUI and PC/iOS/Android control with configurable EQ, limiters, filters and delay for precise tuning, remote monitoring and system optimization.
- Expandable I/O and Dante option: four balanced inputs plus an accessory slot for a DPA‑DAC4 Dante card or mic/aux card, enabling flexible routing and network audio integration.
- User-friendly operation: front-panel or GUI assignable level control, assignable mute and GPIO triggers, and audio-sense auto power down to reduce energy use and simplify day-to-day operation.
- Enterprise-ready reliability: 800W RMS across four channels in a compact 1U rack, NDAA compliance and RoHS certification for secure, long-term deployments.
| General Information | |
|---|---|
| Brand Name | AtlasIED |
| Manufacturer | AtlasIED |
| Product Line | Amps/Attenuator |
| Product Name | DPA804 Multi-Channel Network Amplifier |
| Product Type | Amplifier |
| Product Model | DPA804 |
| Product Series | DPA |
| Manufacturer Part Number | DPA804 |
| Technical Information | |
| Bluetooth | No |
| Impedance | 4Ohm |
| Audio Channels | 4 |
| Classification | AB |
| Audio | |
| Maximum Frequency Response | 20kHz |
| Minimum Frequency Response | 20Hz |
| Total Harmonic Distortion (THD) | 0.5% – 1% |
| Certifications | |
| TAA Compliant | No |
| NDAA Compliant | Yes |
| Energy & Performance | |
| Operating Power Consumption | 794W |
| Network & Communication | |
| Ethernet | Yes |
| Physical Characteristics | |
| Depth | 15.50" |
| Width | 19.00" |
| Height | 1.80" |
| Weight | 13.00lb |
| Power Description | |
| Input Voltage | 120V AC, 230V AC |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
