Digital Watchdog DWC-B6853WTIRW Bullet HDoC Camera with 2.8mm Lens and Infrared Coverage, 4K
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Key Features
- Upgrade existing coax systems to 4K surveillance with Universal HD over Coax for cost-effective retrofits
- Star‑Light Plus low-light color and 100' Smart IR deliver clear identification day or night for reliable security monitoring
- IP66-rated, die-cast aluminum housing withstands dust, rain and extreme temperatures for durable outdoor protection
- 2.8mm wide-angle lens and True WDR capture actionable detail across wide scenes and challenging lighting
- UTC control over coax simplifies setup and reduces installation time while Smart DNR improves image clarity
Quick Specifications
- Brand Name
- Digital Watchdog
- Manufacturer
- Digital Watchdog
- Product Line
- Star-Light Plus
- Product Name
- Digital Watchdog DWC-B6853WTIRW 4K Star-Light Plus UHDoC IR Bullet Camera with 2.8mm Lens
Frequently Bought Together
Digital Watchdog DWC-B6853WTIRW Bullet HDoC Camera with 2.8mm Lens and Infrared Coverage, 4K
$348.24
6 items selected
Total: $1,514.31
Product Information Tabs
Overview
Built for perimeter security and enterprise monitoring, the Digital Watchdog DWC-B6853WTIRW 4K Star‑Light Plus bullet camera delivers high-resolution surveillance without rewiring your site. This Digital Watchdog bullet camera supports Universal HD over Coax—so you can leverage existing coax infrastructure and VMAX A1 DVRs for a cost-effective 4K upgrade. The 2.8mm fixed lens provides a wide field of view ideal for covering entrances, parking lots and perimeters, while Star‑Light Plus technology preserves color detail in near‑darkness. When light levels drop, Smart IR extends coverage up to 100' to maintain clear night imaging. Built from die‑cast aluminum with an IP66 rating and an operating range from -4 to 122°F, the camera is engineered for rugged outdoor security deployments. True WDR, Smart DNR and UTC OSD control over coax ensure balanced, low-noise video and faster installation. NDAA-compliant and backed by a 5-year limited warranty, the DWC-B6853WTIRW is an ideal choice for retail, campus, warehouse and critical infrastructure monitoring—upgrade your surveillance today.
Features
- Upgrade existing coax systems to 4K surveillance with Universal HD over Coax for cost-effective retrofits
- Star‑Light Plus low-light color and 100' Smart IR deliver clear identification day or night for reliable security monitoring
- IP66-rated, die-cast aluminum housing withstands dust, rain and extreme temperatures for durable outdoor protection
- 2.8mm wide-angle lens and True WDR capture actionable detail across wide scenes and challenging lighting
- UTC control over coax simplifies setup and reduces installation time while Smart DNR improves image clarity
| General Information | |
|---|---|
| Brand Name | Digital Watchdog |
| Manufacturer | Digital Watchdog |
| Product Line | Star-Light Plus |
| Product Name | Digital Watchdog DWC-B6853WTIRW 4K Star-Light Plus UHDoC IR Bullet Camera with 2.8mm Lens |
| Product Type | Surveillance Camera |
| Product Model | DWC-B6853WTIRW |
| Manufacturer Part Number | DWC-B6853WTIRW |
| Technical Information | |
| Material | Aluminum Die-cast |
| Lens Type | Fixed |
| Night Vision | Yes |
| Programmable | Yes |
| Field of View | Horizontal, Vertical |
| Video Formats | H.264, MJPEG |
| Output Voltage | 12V DC |
| Motion Detection | Yes |
| Night Vision Type | Color, Infrared |
| Maximum Frame Rate | 30fps |
| American Wire Gauge | 18AWG |
| Illumination Distance | 100' |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 4MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 1200" |
| Certifications | |
| Ingress Protection Rating | IP66 |
| Display & Graphics | |
| Image Sensor Size | 1/1.8" |
| Maximum Illumination | 0.03 lux |
| Maximum Video Resolution | 3840 x 2160 |
| Environmental Conditions | |
| Operating Humidity | 10-90% (Non-condensing) |
| Operating Temperature (T-T) | -4-122°F |
| Maximum Operating Temperature | 122°F |
| Minimum Operating Temperature | -4°F |
| Exposure | |
| Minimum Illumination | 0.0 lux (B/W), 0.10 lux (color) |
| Longest Shutter Speed | 1/30000 s |
| Shortest Shutter Speed | 1/30 s |
| Lens | |
| Focus Modes | Auto, Manual |
| Focal Length | 2.8mm |
| Lens Included | Yes |
| Network & Communication | |
| Remote Management | No |
| Physical Characteristics | |
| Color | White |
| Depth | 8.83" |
| Weight | 1.65lb |
| Durability | Dustproof, Waterproof |
| Form Factor | Bullet |
| Power Description | |
| Frequency | 50 Hz, 60 Hz |
| Input Voltage | 12V DC |
| Product Information | |
| Diameter | 3.81" |
| Mount Type | Pole Mount |
| Storage | |
| Recording Formats | 4K |
| TBD | |
| Amperage | 352mA |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Certifications | CE, FCC, NDAA |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS, UL |
