Digital Watchdog DWC-B7553WTIRW Star-Light Plus 5MP UHDoC Bullet Camera with Fixed Lens and IR
Image of 1
Key Features
- Capture color detail in near-total darkness with Star-Light Plus technology for better identification and evidence quality
- High-resolution 5MP imaging for clearer footage and improved monitoring at key points
- 70 ft Smart IR and true day/night with IR cut filter extend reliable night coverage for 24/7 security
- UHDoC (Universal HD over Coax) compatibility lets you reuse existing coax infrastructure to lower installation costs
- IP66 weatherproof aluminum housing ensures dependable outdoor performance in harsh environments
Quick Specifications
- Product Model
- DWC-B7553WTIRW
- Brand Name
- Digital Watchdog
- Product Line
- Star-Light Plus
- Product Name
- Star-Light Plus 5MP UHDoC Bullet Camera with a fixed lens and IR
Frequently Bought Together
Digital Watchdog DWC-B7553WTIRW Star-Light Plus 5MP UHDoC Bullet Camera with Fixed Lens and IR
$217.60
6 items selected
Total: $1,403.93
Explore the details
Product information
DWC-B7553WTIRW
Overview
Built for dependable 24/7 security monitoring, the Digital Watchdog Star-Light Plus 5MP UHDoC Bullet Camera delivers usable color images in extremely low light so you can identify people and incidents when it matters most. This bullet camera combines a 5MP sensor with Star-Light Plus low-light performance and up to 70 ft of Smart IR, providing crisp daytime detail and extended nighttime coverage for continuous surveillance. UHDoC universal HD over Coax compatibility supports HD-TVI, HD-CVI and HD-Analog formats, enabling cost-effective upgrades using your existing coax wiring and minimizing installation downtime. Rated IP66 with an aluminum die-cast housing, the DWC-B7553WTIRW stands up to rain, dust and temperature extremes for reliable outdoor deployment. On-screen controls over coax (UTC) simplify setup and configuration for integrators and installers. Ideal for perimeter security, retail monitoring, parking lots and property surveillance, this Digital Watchdog bullet camera balances high-resolution imaging with practical installation benefits. Add the DWC-B7553WTIRW to your security system to improve detection, identification and evidence capture—order today to upgrade your monitoring infrastructure.
Features
- Capture color detail in near-total darkness with Star-Light Plus technology for better identification and evidence quality
- High-resolution 5MP imaging for clearer footage and improved monitoring at key points
- 70 ft Smart IR and true day/night with IR cut filter extend reliable night coverage for 24/7 security
- UHDoC (Universal HD over Coax) compatibility lets you reuse existing coax infrastructure to lower installation costs
- IP66 weatherproof aluminum housing ensures dependable outdoor performance in harsh environments
| General Information | |
|---|---|
| Brand Name | Digital Watchdog |
| Manufacturer | Digital Watchdog |
| Product Line | Star-Light Plus |
| Product Name | Star-Light Plus 5MP UHDoC Bullet Camera with a fixed lens and IR |
| Product Type | Surveillance Camera |
| Product Model | DWC-B7553WTIRW |
| Manufacturer Part Number | DWCB7553WTIRW |
| Technical Information | |
| Material | Aluminum Die-cast |
| Lens Type | Fixed |
| Night Vision | Yes |
| Programmable | Yes |
| Field of View | Horizontal, Vertical |
| Video Formats | H.264, MJPEG |
| Output Voltage | 12V DC |
| Motion Detection | Yes |
| Night Vision Type | Infrared |
| Maximum Frame Rate | 30fps |
| American Wire Gauge | 18AWG |
| Minimum Focal Length | 4mm |
| Illumination Distance | 70' |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 5MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 70 ft |
| Certifications | |
| Ingress Protection Rating | IP66 |
| Display & Graphics | |
| Image Sensor Size | 1/2.8" |
| Maximum Video Resolution | 2592 x 1944 |
| Environmental Conditions | |
| Operating Humidity | 10-90% (Non-condensing) |
| Operating Temperature (T-T) | -4-122°F |
| Maximum Operating Temperature | 122°F (50°C) |
| Minimum Operating Temperature | -4°F (-20°C) |
| Exposure | |
| Minimum Illumination | 0.0 lux (B/W), 0.16 lux (color) |
| Longest Shutter Speed | 1/30 Second |
| Shortest Shutter Speed | 1/30000 Second |
| Lens | |
| Focus Modes | Auto |
| Focal Length | 4.0mm |
| Lens Included | Yes |
| Maximum Focal Length | 4mm |
| Others | |
| Model Number Replaces | DWC-B7553WTIR, DWC-B7753TIR |
| Physical Characteristics | |
| Color | White |
| Height | 6.4" |
| Weight | 1.10lb |
| Durability | Dust Resistant, Waterproof, Weather Resistant |
| Form Factor | Bullet |
| Power Description | |
| Frequency | 50 Hz, 60 Hz |
| Input Voltage | 12V DC |
| TBD | |
| Amperage | 333mA |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Analog Video Signal Format | CVBS, HDCVI, HD-TVI |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Features | 3D Digital Noise Reduction, Auto Gain Control, Automatic White Balance, Back Light Compensation (BLC), Built-in Joystick, Built-in OSD Function, Day/Night, Defog, Mirror, Privacy Masking, Wide Dynamic Range |
| Certifications | CE, FCC, NDAA |
| Country of Origin | VN |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
