Digital Watchdog DWC-B7553WTIRW Star-Light Plus 5MP UHDoC Bullet Camera with Fixed Lens and IR

SKU: DWC-B7553WTIRW Digital Watchdog
NULL
Product images for Digital Watchdog DWC-B7553WTIRW Star-Light Plus 5MP UHDoC Bullet Camera with Fixed Lens and IR. 1 image(s) available. Click on image to view full size.

Key Features

  • Capture color detail in near-total darkness with Star-Light Plus technology for better identification and evidence quality
  • High-resolution 5MP imaging for clearer footage and improved monitoring at key points
  • 70 ft Smart IR and true day/night with IR cut filter extend reliable night coverage for 24/7 security
  • UHDoC (Universal HD over Coax) compatibility lets you reuse existing coax infrastructure to lower installation costs
  • IP66 weatherproof aluminum housing ensures dependable outdoor performance in harsh environments

Quick Specifications

Brand Name
Digital Watchdog
Manufacturer
Digital Watchdog
Product Line
Star-Light Plus
Product Name
Star-Light Plus 5MP UHDoC Bullet Camera with a fixed lens and IR
View Full Technical Specifications

Frequently Bought Together

This Item
Digital Watchdog DWC-B7553WTIRW Star-Light Plus 5MP UHDoC Bullet Camera with Fixed Lens and IR

Digital Watchdog DWC-B7553WTIRW Star-Light Plus 5MP UHDoC Bullet Camera with Fixed Lens and IR

$214.98

Frequently Bought Together (5 items)

6 items selected

Total: $1,399.71

Product Information Tabs

Overview

Built for dependable 24/7 security monitoring, the Digital Watchdog Star-Light Plus 5MP UHDoC Bullet Camera delivers usable color images in extremely low light so you can identify people and incidents when it matters most. This bullet camera combines a 5MP sensor with Star-Light Plus low-light performance and up to 70 ft of Smart IR, providing crisp daytime detail and extended nighttime coverage for continuous surveillance. UHDoC universal HD over Coax compatibility supports HD-TVI, HD-CVI and HD-Analog formats, enabling cost-effective upgrades using your existing coax wiring and minimizing installation downtime. Rated IP66 with an aluminum die-cast housing, the DWC-B7553WTIRW stands up to rain, dust and temperature extremes for reliable outdoor deployment. On-screen controls over coax (UTC) simplify setup and configuration for integrators and installers. Ideal for perimeter security, retail monitoring, parking lots and property surveillance, this Digital Watchdog bullet camera balances high-resolution imaging with practical installation benefits. Add the DWC-B7553WTIRW to your security system to improve detection, identification and evidence capture—order today to upgrade your monitoring infrastructure.

Features

  • Capture color detail in near-total darkness with Star-Light Plus technology for better identification and evidence quality
  • High-resolution 5MP imaging for clearer footage and improved monitoring at key points
  • 70 ft Smart IR and true day/night with IR cut filter extend reliable night coverage for 24/7 security
  • UHDoC (Universal HD over Coax) compatibility lets you reuse existing coax infrastructure to lower installation costs
  • IP66 weatherproof aluminum housing ensures dependable outdoor performance in harsh environments
General Information
Brand Name Digital Watchdog
Manufacturer Digital Watchdog
Product Line Star-Light Plus
Product Name Star-Light Plus 5MP UHDoC Bullet Camera with a fixed lens and IR
Product Type Surveillance Camera
Product Model DWC-B7553WTIRW
Manufacturer Part Number DWCB7553WTIRW
Technical Information
Material Aluminum Die-cast
Lens Type Fixed
Night Vision Yes
Programmable Yes
Field of View Horizontal, Vertical
Video Formats H.264, MJPEG
Output Voltage 12V DC
Motion Detection Yes
Night Vision Type Infrared
Maximum Frame Rate 30fps
American Wire Gauge 18AWG
Minimum Focal Length 4mm
Illumination Distance 70'
Connectivity Technology Wired
Effective Camera Resolution 5MP
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Night Vision Distance 70 ft
Certifications
Ingress Protection Rating IP66
Display & Graphics
Image Sensor Size 1/2.8"
Maximum Video Resolution 2592 x 1944
Environmental Conditions
Operating Humidity 10-90% (Non-condensing)
Operating Temperature (T-T) -4-122°F
Maximum Operating Temperature 122°F (50°C)
Minimum Operating Temperature -4°F (-20°C)
Exposure
Minimum Illumination 0.0 lux (B/W), 0.16 lux (color)
Longest Shutter Speed 1/30 Second
Shortest Shutter Speed 1/30000 Second
Lens
Focus Modes Auto
Focal Length 4.0mm
Lens Included Yes
Maximum Focal Length 4mm
Others
Model Number Replaces DWC-B7553WTIR, DWC-B7753TIR
Physical Characteristics
Color White
Height 6.4"
Weight 1.10lb
Durability Dust Resistant, Waterproof, Weather Resistant
Form Factor Bullet
Power Description
Frequency 50 Hz, 60 Hz
Input Voltage 12V DC
TBD
Amperage 333mA
Video
Maximum Resolution 1280 x 720
Analog Video Signal Format CVBS, HDCVI, HD-TVI
Warranty
Limited Warranty 5-Year
Miscellaneous
Features 3D Digital Noise Reduction, Auto Gain Control, Automatic White Balance, Back Light Compensation (BLC), Built-in Joystick, Built-in OSD Function, Day/Night, Defog, Mirror, Privacy Masking, Wide Dynamic Range
Certifications CE, FCC, NDAA
Country of Origin VN
Environmentally Friendly Yes
Environmental Certification RoHS
