Digital Watchdog DWC-MF5WI4TWDMP MEGApix 4MP Ultra-Low-Profile IR Vandal Dome IP Camera with DMP Integration, 4mm Fixed Lens, White

SKU: DWC-MF5WI4TWDMP Digital Watchdog
Digital Watchdog MEGAPIX DWC-MF5WI4TWDMP 4 Megapixel Network Camera - Dome - TAA Compliant
Product images for Digital Watchdog DWC-MF5WI4TWDMP MEGApix 4MP Ultra-Low-Profile IR Vandal Dome IP Camera with DMP Integration, 4mm Fixed Lens, White. 1 image(s) available. Click on image to view full size.
NDAA Compliant TAA Compliant

Key Features

  • Seamless DMP alarm integration via cloud for instant visual verification and faster incident response
  • 4MP image clarity with a 4.0mm fixed lens for reliable identification and wide-area coverage
  • 50' Smart IR and Star-Light Plus low-light performance to maintain color and detail in near-total darkness
  • Ultra low-profile, vandal-resistant housing (IK10) and IP66 weatherproofing for secure outdoor deployment
  • TAA/NDAA compliant and durable aluminum die-cast design—ideal for government and enterprise procurement
  • 5-year limited warranty and remote management support for long-term reliability and easier system maintenance

Quick Specifications

Product Model
DWC-MF5WI4TWDMP
Brand Name
Digital Watchdog
Product Line
MEGApix
Product Name
Megapix DWC-MF5WI4TWDMP Network Camera
View Full Technical Specifications

Frequently Bought Together

Product Information Tabs

Overview

Designed to deliver fast, reliable alarm verification and continuous surveillance, the Digital Watchdog MEGApix DMP vandal dome camera simplifies security monitoring for commercial, retail and government sites. This purpose-built DMP series network camera pairs directly with DMP alarm panels via cloud integration so you get synchronized video on alarm events—reducing false responses and speeding investigations. Capture clear evidence-grade imagery with a 4MP sensor and 4.0mm fixed lens, while Smart IR (up to 50') and Star-Light Plus low-light technology preserve detail and color in challenging lighting. Built for demanding environments, the ultra low-profile dome uses IK10-impact-resistant construction and IP66 weather sealing for reliable outdoor operation. The camera supports H.264 streaming, 3D DNR noise reduction, and remote management to simplify deployment and ongoing monitoring. Note: this model is specially programmed for DMP integration and is not compatible with DW Spectrum VMS. For integrated alarm-video solutions that improve situational awareness and reduce response time, choose the Digital Watchdog DWC-MF5WI4TWDMP—contact us for procurement pricing or to schedule a demo.

Features

  • Seamless DMP alarm integration via cloud for instant visual verification and faster incident response
  • 4MP image clarity with a 4.0mm fixed lens for reliable identification and wide-area coverage
  • 50' Smart IR and Star-Light Plus low-light performance to maintain color and detail in near-total darkness
  • Ultra low-profile, vandal-resistant housing (IK10) and IP66 weatherproofing for secure outdoor deployment
  • TAA/NDAA compliant and durable aluminum die-cast design—ideal for government and enterprise procurement
  • 5-year limited warranty and remote management support for long-term reliability and easier system maintenance
General Information
Brand Name Digital Watchdog
Manufacturer Digital Watchdog
Product Line MEGApix
Product Name Megapix DWC-MF5WI4TWDMP Network Camera
Product Type Network Camera
Product Model DWC-MF5WI4TWDMP
Product Series DMP
Manufacturer Part Number DWC-MF5WI4TWDMP
Technical Information
Material Aluminum Die-cast
Lens Type Fixed
Night Vision Yes
Field of View Horizontal, Vertical
Video Formats H.264, MJPEG
Maximum Aperture f/2
Motion Detection Yes
Maximum Frame Rate 10fps
American Wire Gauge 18AWG
Minimum Focal Length 4mm
Illumination Distance 50'
Connectivity Technology Wired
Effective Camera Resolution 4MP
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Night Vision Distance 50 ft
Certifications
TAA Compliant Yes
NDAA Compliant Yes
Ingress Protection Rating IP66
Display & Graphics
Image Sensor Size 1/2.8"
Maximum Video Resolution 2560 x 1440
Environmental Conditions
Operating Humidity 0.9
Operating Temperature (T-T) -4-122°F
Maximum Operating Temperature 122°F (50°C)
Minimum Operating Temperature -4°F (-20°C)
Exposure
Minimum Illumination 0.0 lux (B/W), 0.16 lux (color)
Longest Shutter Speed 1/15 Second
Shortest Shutter Speed 1/32000 Second
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focal Length 4.0mm
Lens Included Yes
Maximum Focal Length 4mm
Network & Communication
Remote Management Yes
Physical Characteristics
Color White
Weight 14.72oz
Durability Dust Resistant, Impact Resistant, Waterproof
Form Factor Dome
Product Information
Mount Type Ceiling Mount, Corner Mount, Junction Box Mount, Pole Mount, Wall Mount
Storage
Recording Formats HD
Video
Maximum Resolution 1280 x 720
Warranty
Limited Warranty 5-Year
Miscellaneous
Features 3D Digital Noise Reduction, Auto Gain Control, Automatic White Balance, Day/Night, Motion Detection
Certifications CE, FCC, ONVIF, UL Listing
Indoor/Outdoor Outdoor
Country of Origin VN
Environmentally Friendly Yes
Impact Protection Rating IK10
Environmental Certification RoHS
