Digital Watchdog DWC-MV75WI28TW MEGApix IVA 5MP Ultra Low-Profile IR Vandal Dome IP Camera, 2.8mm Lens, White

SKU: DWC-MV75WI28TW Digital Watchdog
Digital Watchdog MEGApix DWC-MV75WI28TW 5 Megapixel Network Camera - Dome
Product images for Digital Watchdog DWC-MV75WI28TW MEGApix IVA 5MP Ultra Low-Profile IR Vandal Dome IP Camera, 2.8mm Lens, White. 2 image(s) available. Click on image to view full size.
NDAA Compliant

Key Features

  • Deliver crisp, actionable surveillance with 5MP resolution at 30fps for reliable identification and wide-area coverage
  • Star-Light Plus low-light color imaging keeps scenes usable at night, improving monitoring and reducing missed events
  • Built to withstand abuse and weather with IK10 impact resistance and IP67 rating for long-term outdoor reliability
  • Built-in Intelligent Video Analytics (IVA+) reduces false alarms and automates detection for smarter security workflows
  • Ultra low-profile vandal dome design supports discreet ceiling, wall, pole or junction-box mounting for flexible installations
  • H.265/H.264/MJPEG support and smart recording rules conserve bandwidth and increase storage efficiency

Quick Specifications

Product Model
DWC-MV75WI28TW
Brand Name
Digital Watchdog
Product Line
MEGApix
Product Name
MEGApix 5MP Ultra Low-Profile Vandal Dome IP Camera
View Full Technical Specifications

Frequently Bought Together

Product Information Tabs

Overview

For mission-critical security and continuous monitoring, the Digital Watchdog MEGApix DWC-MV75WI28TW delivers high-definition video and intelligent analytics in a compact vandal dome. This MEGApix 5MP IP camera captures fine detail at real-time 30fps with a 2.8mm fixed lens for broad coverage, making it ideal for perimeter surveillance, retail loss prevention, and facility monitoring. Star-Light Plus low-light technology preserves color and clarity in near-total darkness, while True WDR balances scenes with challenging lighting. Ruggedized with IK10 impact resistance and an IP67 weather rating, the aluminum die-cast housing ensures dependable outdoor performance. Advanced IVA+ analytics and seamless integration with DW Spectrum reduce false alarms and enable automated event-driven recording, saving bandwidth and storage. ONVIF compatibility and dual-stream codec support (H.265/H.264/MJPEG) simplify integration into open platform VMS and networked security systems. Backed by a 5-year limited warranty, this ultra low-profile dome is a professional choice for commercial and enterprise surveillance. Upgrade your security deployment—specify the MEGApix 5MP vandal dome for robust, low-light-ready monitoring and smarter incident detection.

Features

  • Deliver crisp, actionable surveillance with 5MP resolution at 30fps for reliable identification and wide-area coverage
  • Star-Light Plus low-light color imaging keeps scenes usable at night, improving monitoring and reducing missed events
  • Built to withstand abuse and weather with IK10 impact resistance and IP67 rating for long-term outdoor reliability
  • Built-in Intelligent Video Analytics (IVA+) reduces false alarms and automates detection for smarter security workflows
  • Ultra low-profile vandal dome design supports discreet ceiling, wall, pole or junction-box mounting for flexible installations
  • H.265/H.264/MJPEG support and smart recording rules conserve bandwidth and increase storage efficiency
General Information
Brand Name Digital Watchdog
Manufacturer Digital Watchdog
Product Line MEGApix
Product Name MEGApix 5MP Ultra Low-Profile Vandal Dome IP Camera
Product Type Network Camera
Product Model DWC-MV75WI28TW
Product Series MV75
Manufacturer Part Number DWC-MV75WI28TW
Technical Information
Material Aluminum Die-cast
Lens Type Fixed
Night Vision Yes
Field of View Horizontal, Vertical
Video Formats H.264, MJPEG
Maximum Aperture f/1.8
Maximum Frame Rate 30fps
Minimum Focal Length 2.8mm
Connectivity Technology Wired
Effective Camera Resolution 5MP
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Night Vision Distance 80 ft
Certifications
NDAA Compliant Yes
Ingress Protection Rating IP67
Display & Graphics
Maximum Video Resolution 2592 x 1944
Environmental Conditions
Operating Humidity 10-90% (Non-condensing)
Maximum Operating Temperature 122°F (50°C)
Minimum Operating Temperature -4°F (-20°C)
Exposure
Minimum Illumination 0.0 lux (B/W), 0.13 lux (color), 0.16 lux (color)
Shortest Shutter Speed Off, x15, x2, x3, x4, x5, x6, x7.5
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focal Length 2.8mm
Maximum Focal Length 2.8mm
Network & Communication
Remote Management Yes
Others
Model Number Replaces DWC-MV74WI28
Physical Characteristics
Color White
Weight 12.64 oz
Durability Weather Resistant
Form Factor Dome
Product Information
Mount Type Ceiling Mount, Junction Box Mount, Pole Mount, Wall Mount
Storage
Recording Formats HD
Video
Maximum Resolution 1280 x 720
Warranty
Limited Warranty 5-Year
Miscellaneous
Indoor/Outdoor Outdoor
Environmentally Friendly Yes
Impact Protection Rating IK10
Environmental Certification RoHS
