Digital Watchdog DWC-V6863WTIRW Star-Light Plus 8MP Outdoor Universal HDoC IR Vandal Dome Camera, 3.6-10mm Varifocal Lens, NDAA/TAA Compliant, White
Image of 1
Key Features
- Capture usable color images in near-total darkness with Star‑Light Plus technology, improving identification and reducing false alarms.
- Save installation time and cost by reusing existing coax cabling with Universal HD over Coax (HD‑TVI / HD‑CVI / HD‑Analog) compatibility.
- Flexible 3.6–10mm varifocal lens lets integrators precisely frame critical areas for entrances, parking lots or perimeters.
- Rugged, weather- and impact-resistant housing (IP66, IK10) protects the camera outdoors and lowers maintenance in harsh environments.
- 100 ft Smart IR with intelligent sync and 8MP (4K) resolution provides long-range night coverage and crisp detail for surveillance and monitoring.
- NDAA/TAA compliant for government and enterprise procurement, backed by a 5-year limited warranty for long-term reliability.
Quick Specifications
- Product Model
- DWC-V6863WTIRW
- Brand Name
- Digital Watchdog
- Product Line
- Star-Light Plus
- Product Name
- 4K Universal HD over Coax Vandal Dome Camera
Frequently Bought Together
Digital Watchdog DWC-V6863WTIRW Star-Light Plus 8MP Outdoor Universal HDoC IR Vandal Dome Camera, 3.6-10mm Varifocal Lens, NDAA/TAA Compliant, White
$431.38
12 items selected
Total: $2,518.28
Explore the details
Product information
DWC-V6863WTIRW
Overview
Designed for mission-critical security and perimeter monitoring, the Digital Watchdog DWC-V6863WTIRW Star‑Light Plus vandal dome camera delivers clear, actionable video around the clock. This 8MP (4K) Universal HD over Coax surveillance camera captures high-resolution detail and preserves color in near-total darkness using Star‑Light Plus technology, while 100 ft Smart IR extends reliable night coverage. The 3.6–10mm varifocal lens and UTC control over coax make on-site framing and adjustments fast—reducing installation time and site visits. Built for outdoor use, the die-cast aluminum housing meets IP66 and IK10 ratings to resist weather and tampering, and NDAA/TAA compliance simplifies procurement for government and enterprise projects. Compatible with HD‑TVI, HD‑CVI and legacy analog systems, this vandal dome provides a cost-effective upgrade path to 4K monitoring without rewiring. Ideal for retail, transportation hubs, campus security and critical infrastructure, the DWC-V6863WTIRW pairs high-resolution imaging with robust durability. Contact sales to specify this camera for your next security deployment or add it to your surveillance system to improve detection, evidence quality and operational uptime.
Features
- Capture usable color images in near-total darkness with Star‑Light Plus technology, improving identification and reducing false alarms.
- Save installation time and cost by reusing existing coax cabling with Universal HD over Coax (HD‑TVI / HD‑CVI / HD‑Analog) compatibility.
- Flexible 3.6–10mm varifocal lens lets integrators precisely frame critical areas for entrances, parking lots or perimeters.
- Rugged, weather- and impact-resistant housing (IP66, IK10) protects the camera outdoors and lowers maintenance in harsh environments.
- 100 ft Smart IR with intelligent sync and 8MP (4K) resolution provides long-range night coverage and crisp detail for surveillance and monitoring.
- NDAA/TAA compliant for government and enterprise procurement, backed by a 5-year limited warranty for long-term reliability.
| General Information | |
|---|---|
| Brand Name | Digital Watchdog |
| Manufacturer | Digital Watchdog |
| Product Line | Star-Light Plus |
| Product Name | 4K Universal HD over Coax Vandal Dome Camera |
| Product Type | Surveillance Camera |
| Product Model | DWC-V6863WTIRW |
| Product Series | V6 |
| Country of Origin | VN |
| Manufacturer Part Number | DWC-V6863WTIRW |
| Technical Information | |
| Amperage | 582.00mA |
| Lens Type | Varifocal |
| Aspect Ratio | 16:9 |
| Night Vision | Yes |
| Programmable | Yes |
| Field of View | Horizontal, Vertical |
| Video Formats | H.264 / AVC, MJPEG |
| Output Voltage | 24V AC |
| Motion Detection | Yes |
| Maximum Frame Rate | 30fps |
| Wide Dynamic Range | Yes |
| American Wire Gauge | 18AWG |
| Minimum Focal Length | 3.60mm |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 8MP |
| Camera | |
| Image Sensor Type | CMOS |
| Night Vision Distance | 100.00' |
| Certifications | |
| TAA Compliant | Yes |
| Certifications | CE, FCC, NDAA |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP66 |
| Display & Graphics | |
| Image Sensor Size | 1/1.8" |
| Maximum Video Resolution | 3840 x 2160 |
| Environmental Conditions | |
| Operating Humidity | 10-90% (Non-condensing) |
| Operating Temperature (T-T) | -4-122°F |
| Maximum Operating Temperature | 122°F |
| Minimum Operating Temperature | -4°F |
| Exposure | |
| Minimum Illumination | 0.0000lux |
| Longest Shutter Speed | 1/30 Second |
| Shortest Shutter Speed | 1/30000 Second |
| Lens | |
| Focus Modes | Auto Focus, Manual Focus |
| Focal Length | 3.6-10mm |
| Lens Included | Yes |
| Maximum Focal Length | 10.00mm |
| Network & Communication | |
| Remote Management | No |
| Physical Characteristics | |
| Color | White |
| Weight | 1.98lb |
| Material | Aluminum Die-cast |
| Durability | Dust Resistant, Impact Resistant, Waterproof, Weather Resistant |
| Form Factor | Dome |
| Power Description | |
| Frequency | 50Hz |
| Input Voltage | 12V DC |
| Product Information | |
| Mount Type | Bracket Mount |
| Storage | |
| Recording Formats | H.264 |
| Video | |
| Graphics Mode | 4K UHD |
| Maximum Resolution | 1280 x 720 |
| Analog Video Signal Format | CVBS, HDCVI |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Features | 2D Digital Noise Reduction (2DNR), 3D Digital Noise Reduction, Auto Gain Control, Automatic White Balance, Back Light Compensation (BLC), Day/Night, Defog, Motion Detection, Wide Dynamic Range |
| Indoor/Outdoor | Outdoor |
| Environmentally Friendly | Yes |
| Impact Protection Rating | IK10 |
| Environmental Certification | RoHS |
