Digital Watchdog DWC-VSBD04MI MEGApix 4MP WDR Bullet IP Camera with Smart IR, 2.8-12mm Varifocal Lens, NDAA Compliant, White
Key Features
- Reliable outdoor monitoring with NDAA-compliant Digital Watchdog MEGApix technology—designed for continuous 24/7 surveillance in demanding environments.
- Crystal-clear identification at 4MP and real-time 30 fps, plus True WDR for balanced images in high-contrast lighting.
- Flexible coverage with a 2.8–12mm varifocal lens and motorized zoom/autofocus for remote framing and precise scene adjustment.
- Long-range 164' Smart IR and low-light sensitivity ensure clear night monitoring without external lighting.
- Rugged IP67 weatherproof and IK10 impact-resistant housing for secure perimeter protection at industrial, retail, and campus sites.
Quick Specifications
- Brand Name
- Digital Watchdog
- Manufacturer
- Digital Watchdog
- Product Line
- MEGApix
- Product Name
- MEGApix 4MP bullet IP camera with vari-focal lens and IR
Frequently Bought Together
Digital Watchdog DWC-VSBD04MI MEGApix 4MP WDR Bullet IP Camera with Smart IR, 2.8-12mm Varifocal Lens, NDAA Compliant, White
$231.23
5 items selected
Total: $2,253.22
Product Information Tabs
Overview
Built for dependable perimeter protection and continuous site monitoring, the Digital Watchdog MEGApix 4MP bullet IP camera delivers actionable video you can trust. As a professional-grade bullet camera, it captures sharp 4MP imagery at real-time 30 fps and uses True Wide Dynamic Range to preserve detail in both bright and shadowed areas—ideal for entrances, parking lots, and building perimeters. The 2.8–12mm motorized varifocal lens with autofocus lets integrators remotely zoom and fine-tune views without onsite adjustments, reducing installation time and maintenance costs.
Equipped with 164' Smart IR and low-light performance, this camera maintains recognition-level video after dark. Rugged aluminum construction with IP67 weatherproofing and IK10 impact resistance protects hardware in harsh outdoor conditions. Advanced analytics—line crossing, perimeter intrusion and tamper detection—help cut false alerts and streamline security operations. ONVIF compatibility and NDAA compliance ensure seamless integration into modern IP video systems.
For reliable, scalable surveillance across commercial, municipal, and enterprise applications, choose the Digital Watchdog MEGApix DWC-VSBD04MI—contact sales or add it to your system design today.
Features
- Reliable outdoor monitoring with NDAA-compliant Digital Watchdog MEGApix technology—designed for continuous 24/7 surveillance in demanding environments.
- Crystal-clear identification at 4MP and real-time 30 fps, plus True WDR for balanced images in high-contrast lighting.
- Flexible coverage with a 2.8–12mm varifocal lens and motorized zoom/autofocus for remote framing and precise scene adjustment.
- Long-range 164' Smart IR and low-light sensitivity ensure clear night monitoring without external lighting.
- Rugged IP67 weatherproof and IK10 impact-resistant housing for secure perimeter protection at industrial, retail, and campus sites.
| General Information | |
|---|---|
| Brand Name | Digital Watchdog |
| Manufacturer | Digital Watchdog |
| Product Line | MEGApix |
| Product Name | MEGApix 4MP bullet IP camera with vari-focal lens and IR |
| Product Type | Network Camera |
| Product Model | DWC-VSBD04MI |
| Product Series | V-Class |
| Manufacturer Part Number | DWC-VSBD04MI |
| Supported Network Protocols | IPv4, IPv6 |
| Technical Information | |
| Material | Aluminum Die-cast |
| Lens Type | Varifocal, Zoom |
| Protocols | 802.1x, DDNS, DHCP, FTP, HTTP, HTTPs, ICMP, IGMP, NTP, ONVIF, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, SNMP, UDP, uPNP |
| Night Vision | Yes |
| Programmable | Yes |
| Field of View | Horizontal, Vertical |
| Video Formats | H.264, MJPEG |
| Output Voltage | 12V DC |
| Maximum Aperture | f/1.4 |
| Motion Detection | Yes |
| Night Vision Type | Infrared |
| Maximum Frame Rate | 30fps |
| Built-in Microphone | Yes |
| Minimum Focal Length | 2.8mm |
| Illumination Distance | 164' |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 4MP |
| Audio | |
| Audio Encoding | G.711 |
| Memory Card Slot | Yes |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 164 ft |
| Certifications | |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP67 |
| Display & Graphics | |
| Image Sensor Size | 1/3" |
| Maximum Video Resolution | 1920 x 1080 |
| Environmental Conditions | |
| Operating Humidity | 0-95% RH (Non-condensing) |
| Operating Temperature (T-T) | -22-140°F |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Operating Temperature | -22°F (-30°C) |
| Exposure | |
| Minimum Illumination | 0.0 lux (B/W), 0.005 lux (color) |
| Longest Shutter Speed | 1/2 Second |
| Shortest Shutter Speed | 1/100000 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focus Modes | Auto, Manual |
| Focal Length | 2.8-12mm |
| Lens Included | Yes |
| Maximum Focal Length | 12mm |
| Media & Performance | |
| Network Technology | 10 Base, 100 Base |
| Network & Communication | |
| Remote Management | Yes |
| Physical Characteristics | |
| Color | White |
| Depth | 2.8" |
| Width | 3.2" |
| Height | 8.7" |
| Weight | 1.52 lb |
| Durability | Weather Resistant |
| Form Factor | Bullet |
| Power Description | |
| Input Voltage | 12V DC |
| Product Information | |
| Mount Type | Ceiling Mount, Wall Mount |
| Storage | |
| Storage Type | Memory Card |
| Recording Formats | 2K |
| TBD | |
| Amperage | 666.6mA |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Features | 3D Digital Noise Reduction, Auto Flip, Back Light Compensation (BLC), Defog, Dual Stream, Mirror, Motion Detection, Multi-view Stream, Noise Detection, Privacy Masking, Tamper Detection, Video Management System |
| Certifications | CE, FCC, NDAA, ONVIF |
| Country of Origin | TW |
| Environmentally Friendly | Yes |
| Impact Protection Rating | IK10 |
| Environmental Certification | RoHS |
