Digital Watchdog DWC-XSDE08MI MEGApix Ai 4K Low-Profile Vandal Dome Camera, 2.7-13.5mm Varifocal Lens

SKU: DWC-XSDE08MI Digital Watchdog
Image of 6K-XSDE08MI
Product images for Digital Watchdog DWC-XSDE08MI MEGApix Ai 4K Low-Profile Vandal Dome Camera, 2.7-13.5mm Varifocal Lens. 10 image(s) available. Click on image to view full size.
TAA Compliant

Key Features

  • AI-powered object and people detection reduces false alarms and improves incident verification for confident security decisions
  • Star-Light Plus low-light color imaging and IR up to 100' for reliable 24/7 surveillance in near-total darkness
  • Motorized 2.7–13.5mm varifocal lens with 5x optical zoom for flexible coverage and remote framing without site visits
  • Rugged IP67 weatherproof and IK10 vandal-resistant housing for dependable outdoor and indoor monitoring
  • ONVIF compliance and GigE networking for seamless integration with DW Spectrum and third-party VMS solutions
  • Smart recording with up to 40 configurable detection zones to cut storage needs and focus monitoring on critical areas

Quick Specifications

Product Model
DWC-XSDE08MI
Brand Name
Digital Watchdog
Product Line
MEGApix Ai
Product Name
MEGApix DWC-XSDE08MI Network Camera
View Full Technical Specifications

Frequently Bought Together

Product Information Tabs

Overview

Designed for mission-critical security and perimeter monitoring, the Digital Watchdog DWC-XSDE08MI MEGApix Ai 4K vandal dome delivers clear, actionable video to reduce response times and false alerts. This MEGApix Ai dome camera combines 4K (8MP) resolution at 30 fps with Star-Light Plus low-light color and IR illumination, giving operators crisp detail day or night. AI deep-learning object and people detection with up to 40 programmable zones filters out nuisances and prioritizes real threats, saving storage and operator time.

The motorized 2.7–13.5mm varifocal lens with autofocus and 5x optical zoom lets you remotely adjust field of view for retail, campus, or transportation deployments. Built to perform in harsh environments, the camera features IP67 weatherproofing and IK10 impact resistance for reliable outdoor use. ONVIF compatibility, H.265 compression and GigE networking ensure smooth integration with DW Spectrum and other VMS platforms. Ideal for security, surveillance, and monitoring applications—add this MEGApix 4K vandal dome to your next project or contact sales for deployment guidance.

Features

  • AI-powered object and people detection reduces false alarms and improves incident verification for confident security decisions
  • Star-Light Plus low-light color imaging and IR up to 100' for reliable 24/7 surveillance in near-total darkness
  • Motorized 2.7–13.5mm varifocal lens with 5x optical zoom for flexible coverage and remote framing without site visits
  • Rugged IP67 weatherproof and IK10 vandal-resistant housing for dependable outdoor and indoor monitoring
  • ONVIF compliance and GigE networking for seamless integration with DW Spectrum and third-party VMS solutions
  • Smart recording with up to 40 configurable detection zones to cut storage needs and focus monitoring on critical areas
General Information
Brand Name Digital Watchdog
Manufacturer Digital Watchdog
Product Line MEGApix Ai
Product Name MEGApix DWC-XSDE08MI Network Camera
Product Type Network Camera
Product Model DWC-XSDE08MI
Manufacturer Part Number DWCXSDE08MI
Supported Network Protocols IPv4
Technical Information
Material Aluminum Die-cast
Lens Type Varifocal, Zoom
Protocols DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP)
Night Vision Yes
Optical Zoom 5x
Programmable Yes
Field of View Horizontal, Vertical
Video Formats H.264, H.265
Output Voltage 12V DC
Maximum Aperture f/1.4
Motion Detection Yes
Night Vision Type Infrared
Maximum Frame Rate 30fps
American Wire Gauge 18AWG
Built-in Microphone Yes
Minimum Focal Length 2.7mm
Illumination Distance 100'
Connectivity Technology Wired
Effective Camera Resolution 8MP
Audio
Audio Encoding G.711
Memory Card Slot Yes
Camera
Image Sensor Type CMOS
Wide Dynamic Range Yes
Night Vision Distance 100 ft
Certifications
TAA Compliant Yes
Ingress Protection Rating IP67
Display & Graphics
Image Sensor Size 1/2.8"
Maximum Video Resolution 2592 x 1944
Environmental Conditions
Operating Humidity 10-90% (Non-condensing)
Operating Temperature (T-T) -4-122°F
Maximum Operating Temperature 122°F (50°C)
Minimum Operating Temperature -4°F (-20°C)
Exposure
Minimum Illumination 0.0 lux (B/W), 0.09 lux (color)
Longest Shutter Speed 1/15 Second
Shortest Shutter Speed Off, x10, x2, x3, x5, x6, x7.5
Aspect Ratio 4:3
Interfaces/Ports
Network (RJ-45) Yes
Lens
Focus Modes Auto, Manual
Focal Length 2.7-13.5mm
Lens Included Yes
Maximum Focal Length 13.5mm
Media & Performance
Network Technology 1000 Base-T Ethernet
Network & Communication
Remote Management Yes
Physical Characteristics
Color White
Weight 1.14lb
Durability Weather Resistant
Form Factor Dome
Power Description
Frequency 50 Hz
Input Voltage 12V DC
Product Information
Mount Type Ceiling Mount, Corner Mount, Flush Mount, Junction Box Mount, Pendant Mount, Pole Mount, Wall Mount
Storage
Storage Type Memory Card
Recording Formats 4K
TBD
Amperage 850mA
Video
Maximum Resolution 1280 x 720
Analog Video Signal Format CVBS
Warranty
Limited Warranty 5-Year
Miscellaneous
Features 3D Digital Noise Reduction, Audio Compression, Auto Gain Control, Automatic White Balance, Cross Line Detection, Day/Night, Mirror, Motion Detection, SD Card Local Storage, Wide Dynamic Range
Certifications CE, FCC, NDAA, ONVIF, TAA, UL Listing
Country of Origin VN
Environmentally Friendly Yes
Impact Protection Rating IK10
Environmental Certification RoHS
