TP-Link EAP772 Omada BE11000 Tri-Band Wi-Fi 7 Access Point, Ceiling Mount
Image of 4
Key Features
- Future-proof tri-band Wi‑Fi 7 (BE11000) delivers the capacity and low latency needed for high-density deployments, ensuring smooth video surveillance, VoIP and cloud apps
- Clean 6 GHz band and 320 MHz channel support reduce interference and increase concurrent client throughput for monitoring and security systems
- 2.5G Ethernet uplink unlocks full Wi‑Fi 7 performance so heavy surveillance streams and aggregated traffic move without bottlenecks
- Centralized Omada management, mesh and AI roaming simplify deployment, monitoring and maintenance across campuses and multi-site networks
- Discreet ceiling/wall form factor with included mounting kit makes installation fast and unobtrusive in retail, hospitality, education and security-critical environments
Quick Specifications
- Product Model
- EAP772
- Brand Name
- TP-Link
- Product Line
- Omada
- Product Name
- BE11000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point
Explore the details
Product information
EAP772
Overview
Deliver reliable, high-capacity wireless where it matters most: security, surveillance and mission-critical monitoring. The TP-Link Omada EAP772 is a ceiling-mount tri-band Wi‑Fi 7 access point engineered for dense enterprise and campus environments. With BE11000-class performance and a dedicated clean 6 GHz band, it reduces congestion for multi-camera surveillance, real-time monitoring and high-definition video streaming. A 2.5G Ethernet uplink ensures backhaul won’t throttle aggregated camera or client traffic, while 320 MHz channel support and Multi-Link Operation boost simultaneous transmissions. Managed through Omada’s centralized controller, the EAP772 supports mesh networking and AI-driven roaming to keep devices connected without manual tuning—ideal for large retail stores, hotels, hospitals and corporate offices. The slim circular design mounts easily to ceilings or walls and blends into any installation environment. Certified to CE, FCC and RoHS standards, it pairs enterprise-grade wireless with practical deployment features. Upgrade your network for next-generation surveillance and monitoring—deploy the TP-Link EAP772 Omada Wi‑Fi 7 access point for secure, high-performance connectivity.
Features
- Future-proof tri-band Wi‑Fi 7 (BE11000) delivers the capacity and low latency needed for high-density deployments, ensuring smooth video surveillance, VoIP and cloud apps
- Clean 6 GHz band and 320 MHz channel support reduce interference and increase concurrent client throughput for monitoring and security systems
- 2.5G Ethernet uplink unlocks full Wi‑Fi 7 performance so heavy surveillance streams and aggregated traffic move without bottlenecks
- Centralized Omada management, mesh and AI roaming simplify deployment, monitoring and maintenance across campuses and multi-site networks
- Discreet ceiling/wall form factor with included mounting kit makes installation fast and unobtrusive in retail, hospitality, education and security-critical environments
| General Information | |
|---|---|
| Brand Name | TP-Link |
| Product Line | Omada |
| Product Name | BE11000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point |
| Product Type | Wireless Access Point |
| Manufacturer Part Number | EAP772 |
| Technical Information | |
| Frequency Band | 6.00GHz |
| Wi-Fi Generation | Wi-Fi 7 |
| Power Consumption | 25W |
| Wireless Transmission Speed | 5760.00Mbps |
| Physical Characteristics | |
| Color | White |
| Depth | 8.7" |
| Width | 8.7" |
| Height | 1.3" |
| Weight | 1.54lb |
| Form Factor | Ceiling Mount, Wall Mount |
| Product Information | |
| Mount Type | Ceiling Mount, Wall Mount |
| Miscellaneous | |
| Indoor/Outdoor | Indoor |
| Package Contents | Ceiling/Wall Mounting Kit, EAP772, Installation Guide |
| Environmentally Friendly | Yes |
| Environmental Certification | CE, FCC, IC, RoHS |
