Electro-Voice ELX200-12P-W 12" 2-Way Powered Loudspeaker, White
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Key Features
- Effortless wireless control via QuickSmart Mobile app for fast configuration, monitoring and alerts across up to six ELX200 speakers
- Clear, high-output performance with a 12-inch EV-designed woofer and 1200 W Class-D amplifier delivering up to 130 dB peak SPL for intelligible speech and music
- Rapid setup and protection using QuickSmartDSP presets, three-band EQ, visual limiter monitoring and five user-programmable scenes
- Durable, lightweight polypropylene enclosure with three M10 rigging points, integrated pole-mount and ergonomic handles for portable or installed use
- EV Signal Synchronized Transducers (SST) waveguide ensures consistent coverage and low distortion—ideal for AV, security paging and monitoring
Quick Specifications
- Product Model
- ELX200-12P
- Brand Name
- Electro-Voice
- Product Name
- ELX200-12P 12" Powered Loudspeaker
- Product Type
- Speaker System
Product Information Tabs
Overview
Dependable, high-output sound for portable and installed AV, paging and security applications. The Electro-Voice ELX200-12P-W 12" 2-way powered loudspeaker combines EV-designed transducers and advanced DSP to deliver clear, intelligible audio for live events, corporate AV, houses of worship and security/surveillance paging. Driven by a high-efficiency 1200 W Class-D amplifier, the ELX200-12P-W reaches up to 130 dB peak SPL while preserving clarity from 51 Hz to 20 kHz. Integrated QuickSmartDSP simplifies setup with four purpose-driven presets (Music, Live, Speech, Club), three-band EQ and five user-programmable scenes, plus visual limiter and level meters to protect the system. Use the QuickSmart Mobile app to configure, monitor and receive alerts from up to six ELX200 loudspeakers via Bluetooth Low Energy, enabling on-site adjustments without crawling behind cabinets. The rugged, lightweight polypropylene enclosure, M10 mounting points and pole-mount make this model a flexible choice for both touring and fixed installs. For dependable, ready-to-deploy sound reinforcement and security paging, choose the Electro-Voice ELX200-12P-W — contact us to specify for your next AV or monitoring project.
Features
- Effortless wireless control via QuickSmart Mobile app for fast configuration, monitoring and alerts across up to six ELX200 speakers
- Clear, high-output performance with a 12-inch EV-designed woofer and 1200 W Class-D amplifier delivering up to 130 dB peak SPL for intelligible speech and music
- Rapid setup and protection using QuickSmartDSP presets, three-band EQ, visual limiter monitoring and five user-programmable scenes
- Durable, lightweight polypropylene enclosure with three M10 rigging points, integrated pole-mount and ergonomic handles for portable or installed use
- EV Signal Synchronized Transducers (SST) waveguide ensures consistent coverage and low distortion—ideal for AV, security paging and monitoring
| General Information | |
|---|---|
| Brand Name | Electro-Voice |
| Manufacturer | The Bosch Group |
| Product Name | ELX200-12P 12" Powered Loudspeaker |
| Product Type | Speaker System |
| Product Model | ELX200-12P |
| Manufacturer Part Number | ELX200-12P-W |
| Audio | |
| Maximum Frequency Response | 20 kHz |
| Minimum Frequency Response | 51Hz |
| Environmental Conditions | |
| Sound Emission | 130 dB |
| Physical Characteristics | |
| Color | White |
| Depth | 13.5" |
| Width | 14.3" |
| Height | 24.8" |
| Weight | 34.39lb |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | Built-in Amplifier, Built-in Subwoofer, Digital Signal Processing (DSP), Equalizer |
| Country of Origin | CN |
