Pelco ES6230-15-RW Esprit Enhanced Series IP Positioning System, Enclosure with Wiper, IR + White Light
Image of 2
Key Features
- Long-range identification with 30x optical zoom and 2MP Full HD imaging for clear evidence-grade surveillance
- Day/night detection and deterrence via integrated IR and white-light LEDs, plus a wiper for clear optics in harsh weather
- Rugged IP66-rated enclosure and wide operating temperature (-50°F to 140°F) for reliable outdoor monitoring
- Intelligent on-board analytics (AutoTracker, adaptive motion detection) reduce false alarms and streamline operator workflows
- 360° continuous pan and fast 140°/s slew speed for rapid area coverage and efficient perimeter security
- Dual-stream H.264 and ONVIF compliance for easy integration and reduced bandwidth/storage costs
Quick Specifications
- Product Model
- ES6230-15-RW
- Brand Name
- Pelco by Motorola Solutions
- Manufacturer Part Number
- ES6230-15-RW
Frequently Bought Together
Pelco ES6230-15-RW Esprit Enhanced Series IP Positioning System, Enclosure with Wiper, IR + White Light
$4,959.22
4 items selected
Total: $6,719.38
Explore the details
Product information
ES6230-15-RW
Overview
Designed for demanding outdoor security and perimeter monitoring, the Pelco by Motorola Solutions ES6230-15-RW Esprit Enhanced Series IP positioning system delivers dependable, evidence-ready video and responsive PTZ control. This Esprit PTZ camera combines 2MP Full HD resolution with a 30x optical zoom and 360° continuous pan to identify subjects at long range and track motion across large sites. Integrated IR and white-light illumination, plus a built-in wiper, ensure usable imagery in low light and adverse weather. Built-in analytics including AutoTracker and adaptive motion detection reduce false alarms and automate follow-up, improving operator efficiency for security teams. The IP66-rated enclosure and wide operating temperature range make this unit ideal for critical infrastructure, transportation hubs, and industrial yards. Dual-stream H.264 and ONVIF Profile support simplify network integration and lower storage and bandwidth requirements. For reliable 24/7 surveillance and proactive monitoring, choose the ES6230-15-RW—contact your Pelco representative to specify this PTZ camera for perimeter, port, or campus security deployments.
Features
- Long-range identification with 30x optical zoom and 2MP Full HD imaging for clear evidence-grade surveillance
- Day/night detection and deterrence via integrated IR and white-light LEDs, plus a wiper for clear optics in harsh weather
- Rugged IP66-rated enclosure and wide operating temperature (-50°F to 140°F) for reliable outdoor monitoring
- Intelligent on-board analytics (AutoTracker, adaptive motion detection) reduce false alarms and streamline operator workflows
- 360° continuous pan and fast 140°/s slew speed for rapid area coverage and efficient perimeter security
- Dual-stream H.264 and ONVIF compliance for easy integration and reduced bandwidth/storage costs
| General Information | |
|---|---|
| Brand Name | Pelco by Motorola Solutions |
| Manufacturer Part Number | ES6230-15-RW |
| Technical Information | |
| Night Vision | Yes |
| Optical Zoom | 30x |
| Minimum Focal Length | 4.3mm |
| Effective Camera Resolution | 2MP |
| Camera | |
| Image Sensor Type | CMOS |
| Certifications | |
| Ingress Protection Rating | IP66 |
| Display & Graphics | |
| Maximum Video Resolution | 1920 x 1080 |
| Environmental Conditions | |
| Maximum Operating Temperature | 140°F |
| Minimum Operating Temperature | -50°F |
| Exposure | |
| Minimum Illumination | 0.001 lux, 0.008 lux |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 4.3-129mm |
| Maximum Focal Length | 129mm |
| Physical Characteristics | |
| Depth | 13.9" |
| Width | 20.9" |
| Height | 22.1" |
| Durability | Dust Resistant, Water Resistant |
| Miscellaneous | |
| Features | 360° Pan, 130° Tilt and 30x Optical Zoom, Built-In Heater, Defroster and Wiper, Complies with ONVIF Profiles G, Q and S, IP66 Rated for Outdoor Use, IR Illumination up to 656', Supports SDXC Cards up to 2TB |
| Indoor/Outdoor | Outdoor |
