EtherWAN EX41922-T Hardened Unmanaged 2-port 10/100/1000BASE PoE+2-port 100/1000 SFP Ethernet Switch

SKU: EX41922-T EtherWAN

Special Order: typically 2–6 weeks

Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.

Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.

A member of our team will check with the manufacturer and personally reply by email.

EtherWAN EX41922-T Hardened Unmanaged 2-port 10/100/1000BASE PoE+2-port 100/1000 SFP Ethernet Switch
Product images for EtherWAN EX41922-T Hardened Unmanaged 2-port 10/100/1000BASE PoE+2-port 100/1000 SFP Ethernet Switch. 4 image(s) available. Click on image to view full size.

Key Features

  • Rugged, deploy-anywhere reliability: hardened metal enclosure, -40 to 75°C operation and DIN-rail/terminal-block power for continuous surveillance and security deployments
  • Simplified PoE power at the edge: two Gigabit PoE+ ports delivering up to 30W per port (60W total) to power cameras, access controllers and wireless radios without extra power cabling
  • Fiber-ready uplinks for long-distance links: two SFP slots (100/1000) provide secure, low-latency connections between remote sites or DVR/NVR racks
  • Plug-and-play simplicity with industrial performance: unmanaged operation with Gigabit throughput, 10K jumbo frame support and QoS to keep video and monitoring traffic smooth
  • Energy-efficient, low-maintenance design: IEEE 802.3az EEE compliance and terminal-block redundant power support reduce operational costs and downtime

Quick Specifications

Product Model
EX41922-T
Brand Name
EtherWAN
Product Name
EX41922 Ethernet Switch
Product Type
Ethernet Switch
View Full Technical Specifications

Explore the details

Product information

EX41922-T

Overview

Deliver reliable, hardened network connectivity where it matters most — at the edge of your security and surveillance system. The EtherWAN EX41922-T hardened unmanaged PoE+ Gigabit Ethernet switch is built for outdoor cabinets, remote monitoring sites and industrial installations that require resilient, low-maintenance networking. It provides two 10/100/1000Base-T PoE+ RJ-45 ports (up to 30W per port, 60W total budget) to power IP cameras and access control devices, plus two 100/1000 SFP slots for long-distance fiber uplinks or daisy-chained links. Although unmanaged, the EX41922-T delivers enterprise-grade behavior with full wire-speed Gigabit throughput, 10K jumbo frame support and QoS to prioritize video and monitoring traffic. Hardened specs, redundant terminal-block power and DIN-rail mounting make installation fast and dependable in extreme climates (-40 to 75°C). Ideal for security, surveillance, traffic monitoring and perimeter control applications, the EX41922-T minimizes cabling, lowers operational cost and keeps critical feeds online. Add industrial-grade PoE and fiber resiliency to your next security deployment — order the EtherWAN EX41922-T today.

Features

  • Rugged, deploy-anywhere reliability: hardened metal enclosure, -40 to 75°C operation and DIN-rail/terminal-block power for continuous surveillance and security deployments
  • Simplified PoE power at the edge: two Gigabit PoE+ ports delivering up to 30W per port (60W total) to power cameras, access controllers and wireless radios without extra power cabling
  • Fiber-ready uplinks for long-distance links: two SFP slots (100/1000) provide secure, low-latency connections between remote sites or DVR/NVR racks
  • Plug-and-play simplicity with industrial performance: unmanaged operation with Gigabit throughput, 10K jumbo frame support and QoS to keep video and monitoring traffic smooth
  • Energy-efficient, low-maintenance design: IEEE 802.3az EEE compliance and terminal-block redundant power support reduce operational costs and downtime
34 of 34 specifications
Technical specifications for EtherWAN EX41922-T Hardened Unmanaged 2-port 10/100/1000BASE PoE+2-port 100/1000 SFP Ethernet Switch
General Information
Brand Name EtherWAN
Manufacturer EtherWAN Systems, Inc
Product Name EX41922 Ethernet Switch
Product Type Ethernet Switch
Product Series EX41922
Manufacturer Part Number EX41922-T
Technical Information
Material Metal
Power Consumption 63.80W
Network Switch Type Unmanaged
Media Type Supported Optical Fiber, Twisted Pair
Certifications
TAA Compliant No
I/O Expansions
Expansion Slot Type SFP (mini-GBIC)
Number of SFP Slots 2
Number of Total Expansion Slots 2
Interfaces/Ports
Modular Yes
Uplink Port Yes
Network (RJ-45) Yes
Total Number of Network Ports 2
Management & Protocols
Manageable No
Media & Performance
Network Technology 10/100/1000Base-T, 100/1000Base-X
Network & Communication
Layer Supported 2
Ethernet Technology Gigabit Ethernet
Networking Standards IEEE 802.1az, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Physical Characteristics
Depth 3.5"
Width 1.7"
Height 3.9"
Weight 13.05oz
Power Description
PoE Budget 60W
Power Source DC, PoE
Input Voltage 52V, 57V
PoE (RJ-45) Port Yes
Plug/Connector Type Terminal Block
Product Information
Mount Type Desktop Mount
Miscellaneous
Country of Origin TW
