Gefen EXT-VGAKA-LANS-RX Gen 2.0 VGA KVM Over IP Receiver, USB, RS-232, Audio, IR, PoE, Video Wall Support
Special Order Item
This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.
Image of 3
Key Features
- Simplify AV distribution and control across a standard Gigabit LAN with PoE for flexible, low‑voltage installations
- Preserve and optimize legacy VGA sources using the built‑in scaler with WUXGA (1920 x 1200@60Hz) and 1080p support
- Build dynamic 16x16 video walls for control rooms, surveillance and monitoring centers without extra processors
- Route USB, RS-232, IR and analog audio independently to enable interactive kiosks, touch panels and remote device control
- Scale deployments easily with backward compatibility, centralized firmware updates and enhanced API support for third‑party control systems
Quick Specifications
- Product Model
- EXT-VGAKA-LANS-RX
- Brand Name
- Gefen
- Manufacturer Part Number
- EXT-VGAKA-LANS-RX
Product Information Tabs
Overview
Deliver reliable, secure AV and control to command centers, monitoring rooms, and security installations with the Gefen EXT-VGAKA-LANS-RX VGA KVM Over IP Receiver. Designed for systems integrators and IT teams, this KVM Over IP receiver extends VGA video, USB, RS-232, IR and analog audio over a standard Gigabit LAN with PoE, minimizing cabling and simplifying installation. The integrated scaler ensures legacy VGA sources display cleanly on modern panels, supporting VESA WUXGA (1920 x 1200 at 60 Hz) and 1080p Full HD outputs, while the powerful 16x16 video wall engine lets you tile and manage live and signage content across large video walls for security and surveillance applications. An integrated USB hub (including USB 2.0 and USB 1.1 ports) plus independent routing of control signals provide seamless keyboard/mouse emulation, touch interactivity and device control. Backward compatibility, mass firmware update capability and an enhanced API enable fast deployment and centralized management. Ideal for control rooms, retail monitoring, and enterprise AV, the EXT-VGAKA-LANS-RX combines scalability, security and performance. Contact our sales team or order today to integrate this Gefen receiver into your networked AV and surveillance workflow.
Features
- Simplify AV distribution and control across a standard Gigabit LAN with PoE for flexible, low‑voltage installations
- Preserve and optimize legacy VGA sources using the built‑in scaler with WUXGA (1920 x 1200@60Hz) and 1080p support
- Build dynamic 16x16 video walls for control rooms, surveillance and monitoring centers without extra processors
- Route USB, RS-232, IR and analog audio independently to enable interactive kiosks, touch panels and remote device control
- Scale deployments easily with backward compatibility, centralized firmware updates and enhanced API support for third‑party control systems
| General Information | |
|---|---|
| Brand Name | Gefen |
| Manufacturer Part Number | EXT-VGAKA-LANS-RX |
| Interfaces/Ports | |
| Number of USB Ports | 5 |
| Physical Characteristics | |
| Depth | 5.9" |
| Width | 8.4" |
| Height | 1"|1.7" |
| Power Description | |
| Input Voltage | 5V DC |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | Backward-compatible with first generation Gefen AV over IP products, Extends VGA, USB, RS-232, 2-way analog audio, and IR, using a Gigabit Local Area Network, Independent video, USB, RS-232, IR, and audio routing, Integrated scaler ensures maximum compatibility and best possible viewing experience with different contents and displays, KM Emulation feature facilitates real-time, simultaneous Keyboard and Mouse control of each source from all connected workstations, Supports VESA and CEA input and output resolutions up to WUXGA (1920 x 1200 at 60 Hz) and 1080p Full HD (1920 x 1080 at 60 Hz), VGA output on Sender unit for local monitoring of the source |
