AtlasIED Strategy II FAP8CXT 2-way Ceiling Mountable Speaker 60 RMS
Key Features
- Focused 90° dispersion for consistent coverage in high-ceiling spaces, minimizing SPL variance and improving speech intelligibility.
- 60W RMS power and 8" coaxial driver deliver clear voice paging and full-range background music for commercial PA and monitoring needs.
- 70.7V / 100V tapped transformer and 8Ω compatibility simplify integration into distributed audio, security paging and alarm systems.
- Compression driver with conical waveguide provides high-frequency clarity for surveillance, monitoring announcements and emergency notifications.
- Ceiling-mount design with durable steel construction and a paintable white finish streamlines installation and blends into professional interiors (5-year limited warranty).
Quick Specifications
- Product Model
- FAP8CXT
- Brand Name
- AtlasIED
- Product Line
- Strategy II
- Product Name
- Strategy II FAP8CXT Speaker
Explore the details
Product information
FAP8CXT
Overview
For facilities that require reliable, intelligible paging and music in high-ceiling environments, the AtlasIED Strategy II FAP8CXT ceiling speaker delivers focused, professional audio where it matters most. This AtlasIED pro speaker combines an 8" coaxial woofer and a 1" exit compression driver with a conical waveguide to produce clear voice and extended high-frequency response, making it ideal for public address, background music, security paging and monitoring systems. With 60W RMS power handling and selectable 70.7V/100V taps (plus 8Ω bypass), the FAP8CXT integrates easily into distributed audio networks and emergency notification architectures. The 90° dispersion pattern controls coverage in tall spaces to reduce SPL variance and comb filtering, ensuring consistent message delivery across lobbies, warehouses, schools and retail environments. Built for installers and AV integrators, its ceiling-mount design, steel construction and paintable grille provide a professional finish while simplifying deployment. Specify the AtlasIED Strategy II FAP8CXT for projects that require dependable PA, surveillance-linked paging or integrated monitoring audio—contact your sales rep or add to cart to engineer it into your next installation.
Features
- Focused 90° dispersion for consistent coverage in high-ceiling spaces, minimizing SPL variance and improving speech intelligibility.
- 60W RMS power and 8" coaxial driver deliver clear voice paging and full-range background music for commercial PA and monitoring needs.
- 70.7V / 100V tapped transformer and 8Ω compatibility simplify integration into distributed audio, security paging and alarm systems.
- Compression driver with conical waveguide provides high-frequency clarity for surveillance, monitoring announcements and emergency notifications.
- Ceiling-mount design with durable steel construction and a paintable white finish streamlines installation and blends into professional interiors (5-year limited warranty).
| General Information | |
|---|---|
| Brand Name | AtlasIED |
| Manufacturer | AtlasIED |
| Product Line | Strategy II |
| Product Name | Strategy II FAP8CXT Speaker |
| Product Type | Speaker |
| Product Model | FAP8CXT |
| Product Series | FAP |
| Manufacturer Part Number | FAP8CXT |
| Technical Information | |
| Impedance | 8.00O |
| Sensitivity | 92.0dB |
| Speaker Size | 8.00" |
| Crossover Type | 2-Way |
| Audio | |
| Maximum Frequency Response | 15.0kHz |
| Minimum Frequency Response | 60.0000Hz |
| Certifications | |
| TAA Compliant | No |
| NDAA Compliant | Yes |
| Environmental Conditions | |
| Sound Emission | 6.0dB |
| Physical Characteristics | |
| Size | 1" |
| Color | White |
| Depth | 12.75" |
| Material | Steel |
| Product Information | |
| Diameter | 15.70" |
| Mount Type | Ceiling Mount |
| Warranty | |
| Limited Warranty | 5-Year |
| Miscellaneous | |
| Features | 1" Exit Compression High Frequency Driver Coupled to a Specially Designed Conical Wave-Guide Horn Provides Exceptional Output & Accurate High Frequency Reproduction |
| Indoor/Outdoor | Indoor |
