VIVOTEK FD9380-H C-Series 5MP Outdoor IR Dome Camera, 2.8mm Fixed Lens, White
Key Features
- High-resolution 5MP imaging for actionable surveillance: capture clear details at 2560 x 1920 to improve identification and evidence quality
- Efficient H.265 + Smart Stream III reduces bandwidth and storage up to 90%, lowering recurring network and storage costs
- Superior day/night performance with built-in IR (≈30 m / 98 ft) and WDR Pro for reliable monitoring in low-light and high-contrast scenes
- Rugged outdoor reliability with IP66 weatherproofing and IK10 vandal resistance to minimize maintenance and downtime
- Wide 2.8 mm fixed lens for broad area coverage and flexible mounting (ceiling or wall) for quick deployment in a variety of sites
Quick Specifications
- Product Model
- FD9380-HF2
- Brand Name
- VIVOTEK
- Product Name
- FD9380-HF2 Network Camera
- Product Type
- Network Camera
Frequently Bought Together
VIVOTEK FD9380-H C-Series 5MP Outdoor IR Dome Camera, 2.8mm Fixed Lens, White
9 items selected
Total: $1,581.57
Product Information Tabs
Overview
Built for dependable outdoor security and remote monitoring, the VIVOTEK FD9380-H C-Series 5MP outdoor IR dome camera delivers high-quality surveillance where it matters most. This VIVOTEK network camera provides 5MP resolution (2560 x 1920 at 20 fps) for sharper identification, combined with WDR Pro and SNV technology to preserve detail in both bright and low-light conditions. Nighttime visibility is extended by IR illumination effective to about 30 meters (98 ft), ensuring continuous coverage around the clock. Built-in H.265 support and Smart Stream III dramatically reduce bandwidth and storage requirements—an ideal benefit for multi-site deployments and centralized security operations. Encased in IP66- and IK10-rated housing, the FD9380-H resists harsh weather and vandalism for lower total cost of ownership. The fixed 2.8 mm lens provides wide-area coverage for parking lots, building perimeters, and campus environments, while the VIVOTEK Application Development Platform (VADP) enables custom analytics and integrations. For reliable networked surveillance that balances image quality, efficiency, and durability, specify the FD9380-H for your next security monitoring project.
Features
- High-resolution 5MP imaging for actionable surveillance: capture clear details at 2560 x 1920 to improve identification and evidence quality
- Efficient H.265 + Smart Stream III reduces bandwidth and storage up to 90%, lowering recurring network and storage costs
- Superior day/night performance with built-in IR (≈30 m / 98 ft) and WDR Pro for reliable monitoring in low-light and high-contrast scenes
- Rugged outdoor reliability with IP66 weatherproofing and IK10 vandal resistance to minimize maintenance and downtime
- Wide 2.8 mm fixed lens for broad area coverage and flexible mounting (ceiling or wall) for quick deployment in a variety of sites
| General Information | |
|---|---|
| Brand Name | VIVOTEK |
| Manufacturer | Vivotek, Inc |
| Product Name | FD9380-HF2 Network Camera |
| Product Type | Network Camera |
| Product Model | FD9380-HF2 |
| Manufacturer Part Number | FD9380-HF2 |
| Technical Information | |
| Lens Type | Fixed |
| Night Vision | Yes |
| Video Formats | H.264, H.265, MJPEG |
| Maximum Frame Rate | 20fps |
| Minimum Focal Length | 2.8mm |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 5MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 98.43 ft |
| Certifications | |
| TAA Compliant | Yes |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP66 |
| Display & Graphics | |
| Maximum Video Resolution | 1600 x 1200 |
| Environmental Conditions | |
| Operating Humidity | 0.9 |
| Maximum Operating Temperature | 140°F (60°C) |
| Exposure | |
| Longest Shutter Speed | 1/5 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 2.8 mm |
| Lens Included | Yes |
| Maximum Focal Length | 2.8 mm |
| Network & Communication | |
| Remote Management | Yes |
| Others | |
| Model Number Replaces | FD9380-HF3, FD9389-HTV |
| Physical Characteristics | |
| Color | White |
| Depth | 3.5" |
| Width | 4.6" |
| Height | 4.6" |
| Weight | 1.19 lb |
| Durability | Dustproof, Impact Resistant, Waterproof |
| Form Factor | Dome |
| Product Information | |
| Mount Type | Ceiling Mount, Wall Mount |
| Storage | |
| Recording Formats | HD |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Warranty | |
| Limited Warranty | 2-Year |
| Miscellaneous | |
| Indoor/Outdoor | Outdoor |
| Impact Protection Rating | IK10 |
