AMX FG1901-12 AMX NCITE-813A 8x1:3 4K60 4:4:4 Digital Video Presentation Switcher
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Image of 2
Key Features
- Deliver flawless multi-source presentations with an 8-input, 3-output 8x1:3 design that mirrors scaled video to local and remote displays.
- Preserve image fidelity for critical displays with 4K60 4:4:4 scaling and HDCP 2.2 compatibility for legacy and modern sources.
- Extend 4K signals up to 70 m with DXLite visually lossless transport, reducing on-site cable complexity for large rooms and campuses.
- Built-in audio DSP, balanced pre-amp outputs and optional DriveCore amplification give clearer speech intelligibility and simplified system audio management.
- Fast integration and control via NetLinx, web GUI and front panel reduce deployment time for boardrooms, lecture halls, security and monitoring centers.
Quick Specifications
- Product Model
- NCITE-813A
- Brand Name
- AMX by Harman
- Product Name
- NCITE-813A Audio/Video Switchbox
- Product Type
- Audio/Video Switchbox
Explore the details
Product information
FG1901-12
Overview
Optimize presentation performance and system reliability with the AMX by Harman NCITE-813A professional AV presentation switcher. Engineered for high-use environments, this 8x1:3 switcher simplifies multi-source workflows—mixing HDMI, DXLite and VGA/RGBHV inputs while delivering a scaled, mirrored 4K60 4:4:4 feed to two local HDMI outputs and one DXLite output. Support for HDCP 2.2 and visually lossless DXLite transport (up to 70 m) ensures visiting devices display consistently and remote projectors or displays remain pixel-perfect.
Beyond video, the NCITE-813A integrates advanced audio DSP including parametric EQ, feedback suppression and configurable balanced pre-amp outputs. Optional DriveCore amplification and flexible audio routing reduce the need for external amps, making it ideal for boardrooms, lecture halls, control rooms and surveillance/monitoring centers that require dependable AV distribution and clear speech. Intuitive control via NetLinx, web GUI and front panel speeds commissioning and daily operation.
Choose the NCITE-813A to streamline AV signal distribution, preserve video integrity and centralize audio management—perfect for corporate, education and security installations. Contact your AMX reseller to spec and deploy.
Features
- Deliver flawless multi-source presentations with an 8-input, 3-output 8x1:3 design that mirrors scaled video to local and remote displays.
- Preserve image fidelity for critical displays with 4K60 4:4:4 scaling and HDCP 2.2 compatibility for legacy and modern sources.
- Extend 4K signals up to 70 m with DXLite visually lossless transport, reducing on-site cable complexity for large rooms and campuses.
- Built-in audio DSP, balanced pre-amp outputs and optional DriveCore amplification give clearer speech intelligibility and simplified system audio management.
- Fast integration and control via NetLinx, web GUI and front panel reduce deployment time for boardrooms, lecture halls, security and monitoring centers.
| General Information | |
|---|---|
| Brand Name | AMX by Harman |
| Manufacturer | Harman International Industries, Inc |
| Product Name | NCITE-813A Audio/Video Switchbox |
| Product Type | Audio/Video Switchbox |
| Product Model | NCITE-813A |
| Country of Origin | MX |
| Manufacturer Part Number | FG1901-12 |
| Technical Information | |
| Device Supported | Display, Projector |
| Media Type Supported | Twisted Pair |
| Connectivity Technology | Wired |
| Maximum Operating Distance | 229' |
| Number of Input Devices Supported | 8 |
| Certifications | |
| TAA Compliant | No |
| Display & Graphics | |
| Maximum Video Resolution | 4096 x 2160 |
| Interfaces/Ports | |
| VGA In | Yes |
| Number of USB Ports | 1 |
| Number of HDMI Inputs | 4 |
| Number of HDMI Outputs | 2 |
| Number of Connectivity (RJ-45) Ports | 4 |
| Physical Characteristics | |
| Depth | 14.00" |
| Width | 19.00" |
| Height | 1.70" |
| Form Factor | Rack Mount |
| Power Description | |
| Input Voltage | 110V AC, 220V AC |
| Product Information | |
| Mount Type | Rack Mount |
| Number of Displays Supported | 3 |
| Video | |
| Graphics Mode | 4K UHD |
| Maximum Resolution | 3840 x 2160 |
| Miscellaneous | |
| Environmentally Friendly | No |
