LifeSafety Power FPO150/250-2C82D8PE4M1 Unified Power System Networked 12/24VDC, 16-Door
Image of 1
Key Features
- Centralize power and control for up to 16 doors with a single networked 12/24V DC system, reducing rack space and installation time
- Remote monitoring and software-controlled I/O enable troubleshooting, reconfiguration and alarm reporting without site visits to maximize uptime
- Flexible outputs: 16 controlled fused outputs plus 16 auxiliary class II outputs, each configurable for 12V or 24V to support locks, readers and peripherals
- Integrated Mercury Security access modules (M8/D8P) simplify wiring and accelerate deployments for access control and security projects
- Robust UL-listed steel enclosure with tamper switch, lock, removable backplate and lifetime warranty to protect critical surveillance and monitoring equipment
Quick Specifications
- Product Model
- FPO150/250-2C82D8PE4M1
- Brand Name
- LifeSafety Power
- Product Line
- FlexPower
- Product Name
- FlexPower FPO Power Supply
Frequently Bought Together
LifeSafety Power FPO150/250-2C82D8PE4M1 Unified Power System Networked 12/24VDC, 16-Door
$1,183.86
7 items selected
Total: $10,657.16
Explore the details
Product information
FPO150/250-2C82D8PE4M1
Overview
Optimize and centralize power for networked access control and security deployments with the LifeSafety Power FPO150/250-2C82D8PE4M1 Unified Power System. This LifeSafety Power networked 12/24VDC power supply combines FlexPower modules with Mercury Security access hardware in a compact, UL-listed enclosure to deliver reliable, managed power where it matters most. With up to 400W of output and support for 16 doors, the FPO150/250 simplifies installations by consolidating multiple voltages and distribution points into one system. Software-controlled M8 inputs and programmable outputs let you set failsafe/fail-secure behavior, remotely reset devices, and integrate fire alarm signals — reducing onsite service calls and improving system availability. The D8P auxiliary outputs and per-circuit fusing provide flexible distribution for locks, readers and peripherals used in access control, surveillance and monitoring environments. Built for installers and IT/security teams, the enclosure includes tamper protection, lock/key access and a removable backplate for neat cable management. Ideal for enterprise, campus and multi-tenant applications — add the FPO150/250 to your next security or surveillance project to simplify power management and speed deployment.
Features
- Centralize power and control for up to 16 doors with a single networked 12/24V DC system, reducing rack space and installation time
- Remote monitoring and software-controlled I/O enable troubleshooting, reconfiguration and alarm reporting without site visits to maximize uptime
- Flexible outputs: 16 controlled fused outputs plus 16 auxiliary class II outputs, each configurable for 12V or 24V to support locks, readers and peripherals
- Integrated Mercury Security access modules (M8/D8P) simplify wiring and accelerate deployments for access control and security projects
- Robust UL-listed steel enclosure with tamper switch, lock, removable backplate and lifetime warranty to protect critical surveillance and monitoring equipment
| General Information | |
|---|---|
| Brand Name | LifeSafety Power |
| Manufacturer | LifeSafety Power, Inc |
| Product Line | FlexPower |
| Product Name | FlexPower FPO Power Supply |
| Product Type | Power Supply, Power System |
| Product Series | FPO |
| Country of Origin | US |
| Manufacturer Part Number | FPO150/250-2C82D8PE4M1 |
| Technical Information | |
| Output Voltage | 12V DC, 24V DC |
| Physical Characteristics | |
| Depth | 4.50" |
| Width | 20.00" |
| Height | 24.00" |
| Weight | 25.00lb |
| Form Factor | Enclosure |
| Power Description | |
| Output Power | 400.00W |
| Input Voltage | 120V AC, 230V AC |
| Output Current | 6.0000A |
| Warranty | |
| Limited Warranty | Lifetime |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
