Kidde FX-10RD 10 Zone Fire Alarm Control Panel, Red
Image of 1
Key Features
- Reduces false alarms and maintenance calls using automatic drift compensation and CleanMe remote annunciation
- Simplifies installation and service with front-panel programming and integrated upload/download DACT for PC configuration
- Reliable 24VDC notification output and 120VAC primary power for continuous monitoring and code compliance
- Flexible zone and NAC configuration: 10 standard zones, convertible Class A circuits, and programmable notification outputs
- One-person walk-test, LCD annunciation, and optional remote annunciators streamline testing and daily operations
Quick Specifications
- Product Model
- FX-10RD
- Brand Name
- Kidde Commercial
- Product Name
- 10 Zone Panel with Dialer Red 120VAC Power Source, 24VDC Output
- Product Type
- Fire Alarm Control Panel
Frequently Bought Together
Kidde FX-10RD 10 Zone Fire Alarm Control Panel, Red
$1,041.84
8 items selected
Total: $3,292.36
Product Information Tabs
Overview
Built to deliver dependable, low-maintenance fire monitoring for small to mid-size installations, the Kidde Commercial FX-10RD fire alarm control panel combines ease-of-use with code-grade reliability. As a conventional 10-zone FACP with an LCD annunciator, the FX-10RD gives facilities clear on-site status and one-person walk-test capability to speed commissioning and routine checks. Integrated upload/download DACT support lets technicians program and back up configurations from a PC, reducing on-site time and service visits. Automatic drift compensation and the CleanMe feature help prevent nuisance alarms and extend detector life, lowering operational costs and false-alarm impacts on security and surveillance systems. The panel runs on 120VAC with a 24VDC notification output and offers flexible NAC/zone programming — including Class A conversion and selectable temporal or coded outputs — so you can tailor notification and supervision to building and AHJ requirements. UL 864 listing and optional remote annunciators and relay modules make the FX-10RD a practical choice for campuses, retail, and multi-tenant commercial sites. Upgrade your fire protection and monitoring — order the FX-10RD or contact sales to specify it for your next project.
Features
- Reduces false alarms and maintenance calls using automatic drift compensation and CleanMe remote annunciation
- Simplifies installation and service with front-panel programming and integrated upload/download DACT for PC configuration
- Reliable 24VDC notification output and 120VAC primary power for continuous monitoring and code compliance
- Flexible zone and NAC configuration: 10 standard zones, convertible Class A circuits, and programmable notification outputs
- One-person walk-test, LCD annunciation, and optional remote annunciators streamline testing and daily operations
| General Information | |
|---|---|
| Brand Name | Kidde Commercial |
| Manufacturer | Carrier |
| Product Name | 10 Zone Panel with Dialer Red 120VAC Power Source, 24VDC Output |
| Product Type | Fire Alarm Control Panel |
| Product Model | FX-10RD |
| Product Series | FX |
| Manufacturer Part Number | FX-10RD |
| Technical Information | |
| Panel Control Type | Conventional |
| Connectivity Technology | Wired |
| Number of Standard Zones | 10 |
| Number of Zones Supported | 63 |
| Number of Relays Supported | 9 |
| Display & Graphics | |
| Display Type | LCD |
| Others | |
| Model Number Replaces | E-FSC1004RD, FSP1004GD, FSP1004RD |
| Physical Characteristics | |
| Color | Red |
| Power Description | |
| Input Voltage | 120V AC, 24V DC |
| Miscellaneous | |
| Features | Automatic drift compensation with select detectors reduces false alarms and extends dust life Listed to ANSI UL 864 9th Edition, Available in 5 and 10 zone (IDC) models, CleanMe feature provides remote annunciation of a dirty detector, Combination Waterflow and Supervisory IDCs NACs programmable by zone and individually selectable for notification appliances, continuous, temporal outputs, or coded, Front panel programming simplifies installation and servicing Precision synchronization with compatible notification appliances and optional audible silence over two wires, Models with fully integrated upload/download DAT enables PC programming, On-board relays for Alarm, Supervisory and Trouble, One-Person walk-test (audible or silent), Optional City Tie and Reverse Polarity Modules, Optional serial bus relay modules are programmable for Common, Zone, or Matrix activation, Optional serial bus remote annunciator family, Trim ring available for semi-flush mounting, Zone or NAC pairs convertible to single Class A Circuits |
| Country of Origin | CN |
