Edwards Signaling G4LFWF-HVM Genesis G4LF Series Low Frequency 520 Hz Horn Strobe, "FIRE" Marking, White
Image of 1
Key Features
- Delivers clear, low-frequency 520 Hz audible alerts tailored for sleeping areas and noise-sensitive environments to improve occupant response.
- Combination horn and xenon strobe provides synchronized audible/visual notification with field-configurable candela and dB settings for flexible installation.
- Genesis design keeps strobes synchronized to within 10 ms on compatible NACs, eliminating visual confusion across large coverage areas.
- Slim, low-profile white housing blends with commercial and hospitality interiors while offering easy, tool-free configuration and installation.
- 24V DC power and UL-compliant light distribution ensure dependable performance when integrated into fire, security, and monitoring systems.
Quick Specifications
- Product Model
- G4LFWF-HVM
- Brand Name
- Edwards Signaling
- Product Line
- Genesis
- Product Name
- Low Frequency 520 Hz Horn Strobe, White, FIRE Markings
Frequently Bought Together
Edwards Signaling G4LFWF-HVM Genesis G4LF Series Low Frequency 520 Hz Horn Strobe, "FIRE" Marking, White
$112.86
3 items selected
Total: $294.96
Explore the details
Product information
G4LFWF-HVM
Overview
Designed for reliable life-safety signaling in sleeping areas and other noise-sensitive settings, the Edwards Signaling Genesis G4LF horn strobe (G4LFWF-HVM) delivers clear, compliant alerts that help speed occupant response and improve building safety. This horn strobe produces a crisp low-frequency 520 Hz tone in the standard temporal pattern and offers field-configurable high/low dB output and candela settings so integrators can optimize alerts for healthcare, hospitality and multifamily applications. With 24V DC operation and xenon strobe technology, the Genesis G4LF provides smooth, UL-1971-compliant light distribution while minimizing profile and visual artifacts common with specular reflectors. When connected to compatible Edwards control equipment, audible and visual outputs synchronize across the Notification Appliance Circuit—reducing false starts and confusion during an event. Built for easy installation and reliable operation in fire alarm, security and monitoring systems, this white, “FIRE”-marked device combines professional appearance with high performance. Ideal for fire alarm, security, and surveillance integrations—add the Genesis G4LF to your next safety upgrade or contact sales for system design assistance.
Features
- Delivers clear, low-frequency 520 Hz audible alerts tailored for sleeping areas and noise-sensitive environments to improve occupant response.
- Combination horn and xenon strobe provides synchronized audible/visual notification with field-configurable candela and dB settings for flexible installation.
- Genesis design keeps strobes synchronized to within 10 ms on compatible NACs, eliminating visual confusion across large coverage areas.
- Slim, low-profile white housing blends with commercial and hospitality interiors while offering easy, tool-free configuration and installation.
- 24V DC power and UL-compliant light distribution ensure dependable performance when integrated into fire, security, and monitoring systems.
| General Information | |
|---|---|
| Brand Name | Edwards Signaling |
| Manufacturer | Carrier |
| Product Line | Genesis |
| Product Name | Low Frequency 520 Hz Horn Strobe, White, FIRE Markings |
| Product Type | Horn Strobe |
| Product Model | G4LFWF-HVM |
| Product Series | G4LF |
| Manufacturer Part Number | G4LFWF-HVM |
| Technical Information | |
| Material | Plastic |
| Alarm Type | Audible, Visual |
| Application/Usage | Indoor |
| Connectivity Technology | Wired |
| Environmental Conditions | |
| Sound Emission | 75 dB |
| Physical Characteristics | |
| Color | White |
| Depth | 1" |
| Width | 5" |
| Height | 6.5" |
| Durability | UV Resistant |
| Lens Color | Clear |
| Form Factor | Ceiling Mount, Flush Mount, Surface Mount, Wall Mount |
| Power Description | |
| Power Source | DC |
| Input Voltage | 24V DC |
| Product Information | |
| Mount Type | Ceiling Mount, Flush Mount, Surface Mount, Wall Mount |
| Bulb/Tube Type | Xenon |
| Miscellaneous | |
| Features | Candela Switch, Synchronization, Textured |
| Indoor/Outdoor | Indoor |
