Netgear GSM4328-100NES 24-Port Gigabit PoE+ Compliant Managed AV IP Switch
Key Features
- Simplifies AV-over-IP and multicast deployments with NETGEAR IGMP Plus™, pre-configured AV profiles and Engage Controller for faster, low-latency installs
- Powers large edge deployments — 24 Gigabit PoE+ ports with a 648W PoE budget to support cameras, access points and audio endpoints without separate power bricks
- High-capacity uplinks and routing — 4 × 10G SFP+ uplinks plus Layer 3 routing keep surveillance, monitoring and core networking traffic flowing smoothly
- Enterprise reliability and uptime — modular/redundant power options, Virtual Chassis stacking and non-stop forwarding (NSF) for hitless failover in critical security systems
- Rack-friendly, quiet operation — compact 1U depth and configurable fan modes balance acoustics for AV racks or equipment rooms
- Industry-grade warranty and support — NETGEAR ProSAFE lifetime hardware warranty and next-business-day replacement for peace of mind on mission-critical installs
Quick Specifications
- Product Model
- M4350-24G4XF
- Brand Name
- Netgear
- Product Line
- AV Line
- Product Name
- AV Line M4350-24G4XF Ethernet Switch
Product Information Tabs
Overview
Deploy a single, purpose-built switch that simplifies Pro AV and security networking. The Netgear M4350 24-port Gigabit PoE+ managed network switch is engineered for AV-over-IP, surveillance and monitoring deployments — delivering reliable power, predictable multicast behavior and enterprise routing in a compact 1U platform. With 24 Gigabit PoE+ ports and a 648W PoE budget, the switch powers cameras, VoIP/PA endpoints and wireless access points without added injectors. Four 10G SFP+ uplinks and Layer 3 features provide the bandwidth and routing needed to aggregate video streams and connect to core data center switches. NETGEAR’s AV-focused features like IGMP Plus™, the AV user interface and Engage™ Controller speed up configuration for Dante, SDVoE, NDI and other AV protocols while avoiding multicast flooding that can disrupt security and monitoring networks. Redundant/modular power options, Virtual Chassis stacking and non-stop forwarding ensure continuous operation for mission-critical environments. Choose the M4350 to consolidate AV, security and IT traffic on a single managed switch — ideal for control rooms, surveillance hubs and enterprise AV systems. Contact sales or order now to streamline your next security or AV deployment.
Features
- Simplifies AV-over-IP and multicast deployments with NETGEAR IGMP Plus™, pre-configured AV profiles and Engage Controller for faster, low-latency installs
- Powers large edge deployments — 24 Gigabit PoE+ ports with a 648W PoE budget to support cameras, access points and audio endpoints without separate power bricks
- High-capacity uplinks and routing — 4 × 10G SFP+ uplinks plus Layer 3 routing keep surveillance, monitoring and core networking traffic flowing smoothly
- Enterprise reliability and uptime — modular/redundant power options, Virtual Chassis stacking and non-stop forwarding (NSF) for hitless failover in critical security systems
- Rack-friendly, quiet operation — compact 1U depth and configurable fan modes balance acoustics for AV racks or equipment rooms
- Industry-grade warranty and support — NETGEAR ProSAFE lifetime hardware warranty and next-business-day replacement for peace of mind on mission-critical installs
| General Information | |
|---|---|
| Brand Name | Netgear |
| Manufacturer | Netgear, Inc |
| Product Line | AV Line |
| Product Name | AV Line M4350-24G4XF Ethernet Switch |
| Product Type | Ethernet Switch |
| Product Model | M4350-24G4XF |
| Product Series | M4350 |
| Manufacturer Part Number | GSM4328100NES |
| Technical Information | |
| Power Consumption | 240W |
| Network Switch Type | Managed |
| Media Type Supported | Optical Fiber, Twisted Pair |
| I/O Expansions | |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 4 |
| Number of Total Expansion Slots | 4 |
| Interfaces/Ports | |
| Modular | Yes |
| Uplink Port | Yes |
| Network (RJ-45) | Yes |
| Total Number of Network Ports | 24 |
| Management & Protocols | |
| Manageable | Yes |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T, 10GBase-X |
| Network & Communication | |
| Layer Supported | 3 |
| Ethernet Technology | 10 Gigabit Ethernet |
| Networking Standards | IEEE 802.1ak, IEEE 802.1as, IEEE 802.1AX, IEEE 802.1BA, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qat, IEEE 802.1Qav, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt |
| Physical Characteristics | |
| Depth | 15.7" |
| Width | 14.4' |
| Height | 17" |
| Weight | 14.13lb |
| Compatible Rack Unit | 1U |
| Power Description | |
| Frequency | 50 Hz, 60 Hz |
| PoE Budget | 648W |
| Power Source | AC, PoE+, Power Supply |
| Input Voltage | 120V AC, 230V AC |
| PoE (RJ-45) Port | Yes |
| Plug/Connector Type | C14 |
| Warranty | |
| Limited Warranty | Lifetime |
| Miscellaneous | |
| Country of Origin | TH |
| Environmentally Friendly | Yes |
| Environmental Certification | ErP, EuP, REACH, RoHS, WEEE |
