Honeywell HC60W35R2 60 Series 5MP Indoor WDR IR IP Dome Camera, 2.7-13.5mm Lens, Lyric White
Special Order: typically 2–6 weeks
Ships directly from the manufacturer. This is an estimated lead time, not a guaranteed delivery date.
Availability can change and lead times may be longer. If your project has a deadline, check with us before ordering.
A member of our team will check with the manufacturer and personally reply by email.
Key Features
- Deliver sharp, actionable video for security and surveillance with true 5MP resolution, improving identification and evidence capture.
- Wide Dynamic Range up to 120 dB balances bright and dark scenes for reliable monitoring in challenging lighting conditions.
- Up to 98 ft infrared and 0.04 lux low-light performance maintain continuous 24/7 coverage in dim environments.
- Varifocal 2.7–13.5mm lens and ceiling/wall/flush mounting provide flexible installation and precise scene coverage for retail, campus, or commercial sites.
- H.265 Smart Codec and SD card local storage reduce bandwidth and storage costs while enabling remote management and long-term recording.
Quick Specifications
- Product Model
- HC60W35R2
- Brand Name
- Honeywell Commercial Security
- Product Name
- 5MP Network TDN WDR IR Indoor Dome Camera
- Product Type
- Network Camera
Frequently Bought Together
Honeywell HC60W35R2 60 Series 5MP Indoor WDR IR IP Dome Camera, 2.7-13.5mm Lens, Lyric White
7 items selected
Total: $1,567.11
Explore the details
Product information
HC60W35R2
Overview
Built for reliable, compliant surveillance in enterprise and critical environments, the Honeywell Commercial Security HC60W35R2 5MP indoor dome camera delivers high-quality monitoring where detail and uptime matter. This network camera combines 5MP resolution with Wide Dynamic Range (up to 120 dB) to capture clear images across high-contrast scenes, and a 2.7–13.5mm varifocal lens for precise field-of-view adjustment. Low-light performance (0.04 lux) plus up to 30 m (98 ft) IR illumination ensures continuous coverage after dark, while H.265 Smart Codec minimizes network bandwidth and storage demands—ideal for large-scale security deployments. The IK10 impact resistance, TAA compliance, and indoor mounting versatility make the HC60W35R2 a strong choice for government, retail, utilities, campus, and commercial surveillance projects. Integrate it with your network video system for remote management, SD card local backup, and advanced monitoring features like motion detection and privacy masking. Contact your Honeywell Commercial Security distributor to specify HC60W35R2 for your next secure monitoring installation or add it to your solution design.
Features
- Deliver sharp, actionable video for security and surveillance with true 5MP resolution, improving identification and evidence capture.
- Wide Dynamic Range up to 120 dB balances bright and dark scenes for reliable monitoring in challenging lighting conditions.
- Up to 98 ft infrared and 0.04 lux low-light performance maintain continuous 24/7 coverage in dim environments.
- Varifocal 2.7–13.5mm lens and ceiling/wall/flush mounting provide flexible installation and precise scene coverage for retail, campus, or commercial sites.
- H.265 Smart Codec and SD card local storage reduce bandwidth and storage costs while enabling remote management and long-term recording.
| General Information | |
|---|---|
| Brand Name | Honeywell Commercial Security |
| Manufacturer | Honeywell International, Inc |
| Product Name | 5MP Network TDN WDR IR Indoor Dome Camera |
| Product Type | Network Camera |
| Product Model | HC60W35R2 |
| Product Series | 60 |
| Manufacturer Part Number | HC60W35R2 |
| Technical Information | |
| Lens Type | Varifocal |
| Night Vision | Yes |
| Optical Zoom | 5x |
| Field of View | Horizontal, Vertical |
| Video Formats | H.264, H.265, MJPEG |
| Maximum Aperture | f/1.4 |
| Night Vision Type | Infrared |
| Number of IR LEDs | 4 |
| Maximum Frame Rate | 60fps |
| Video Signal Format | NTSC, PAL |
| Minimum Focal Length | 2.7mm |
| Connectivity Technology | Wired |
| Field of View (Vertical) | 72° |
| Field of View (Horizontal) | 100° |
| Effective Camera Resolution | 5MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 98.43 ft |
| Certifications | |
| TAA Compliant | Yes |
| Ingress Protection Rating | IP52 |
| Display & Graphics | |
| Maximum Video Resolution | 2560 x 1920 |
| Environmental Conditions | |
| Operating Humidity | 0.9 |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Operating Temperature | 14°F (-10°C) |
| Exposure | |
| Longest Shutter Speed | 1/30 Second |
| Shortest Shutter Speed | 1/32000 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 2.7-13.5mm |
| Lens Included | Yes |
| Minimum Aperture | f/2.8 |
| Maximum Focal Length | 13.5mm |
| Network & Communication | |
| Remote Management | Yes |
| Physical Characteristics | |
| Color | White |
| Height | 4.8" |
| Weight | 1.28 lb |
| Durability | Dust Resistant, Impact Resistant |
| Form Factor | Dome |
| Power Description | |
| Input Voltage | 12V DC, 24V AC |
| Product Information | |
| Diameter | 5" |
| Mount Type | Ceiling Mount, Flush Mount, Wall Mount |
| Storage | |
| Storage Type | Memory Card |
| Recording Formats | HD |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Miscellaneous | |
| Features | 3D Digital Noise Reduction, Automatic White Balance, Back Light Compensation (BLC), Built-in Microphone, Cross Line Detection, Day/Night, Gain Control, Highlight Compensation (HLC), Motion Detection, Password Protection, Privacy Masking, Region of Interest, SD Card Local Storage, Wide Dynamic Range |
| Indoor/Outdoor | Indoor |
| Country of Origin | TW |
| Environmentally Friendly | Yes |
| Impact Protection Rating | IK10 |
| Environmental Certification | RoHS |
