Hanwha HCD-6080R 2MP Analog HD IR Indoor Dome Camera, 3.2-10mm Motorized Varifocal Lens, Plastic, Ivory
Image of 1
Key Features
- Reliable 24/7 monitoring with infrared night vision up to 65 ft for continuous security in low-light environments
- Clear evidence-grade images at 2MP resolution and 30fps to improve incident review and reduce false alarms
- Motorized 3.2–10mm varifocal lens lets installers remotely adjust field of view for flexible coverage and fewer re-visits
- Robust IP66 and IK10-rated housing protects against weather and vandalism for outdoor and indoor installations
- Plug-and-play analog HD compatibility (AHD/CVI/TVI) simplifies upgrades from legacy systems and lowers integration cost
Quick Specifications
- Product Model
- HCD-6080R
- Brand Name
- Hanwha Vision
- Product Name
- 2MP Analog HD IR Indoor Dome
- Product Type
- Dome Camera
Frequently Bought Together
Hanwha HCD-6080R 2MP Analog HD IR Indoor Dome Camera, 3.2-10mm Motorized Varifocal Lens, Plastic, Ivory
$195.84
12 items selected
Total: $2,073.04
Product Information Tabs
Overview
Designed for reliable, day-and-night surveillance, the Hanwha Vision HCD-6080R 2MP analog HD IR indoor dome camera delivers crisp imagery and flexible installation for commercial security and monitoring projects. The camera produces full HD 2MP video at up to 30fps and features a motorized 3.2–10mm varifocal lens so integrators can fine-tune coverage remotely — reducing installation time and site visits. Built-in IR provides up to 65 feet of night visibility while 120dB WDR preserves detail in mixed lighting, helping security teams capture usable evidence in challenging scenes. This durable dome supports IP66 weather resistance and IK10 vandal protection, making it suitable for retail, office, school and transit applications that demand resilient, high-quality surveillance. Backward-compatible AHD/CVI/TVI analog formats and dual power options simplify upgrades from legacy systems and cut deployment costs. Specify the Hanwha HCD-6080R for dependable perimeter and indoor monitoring—contact your distributor to request a quote or sample for your next security project.
Features
- Reliable 24/7 monitoring with infrared night vision up to 65 ft for continuous security in low-light environments
- Clear evidence-grade images at 2MP resolution and 30fps to improve incident review and reduce false alarms
- Motorized 3.2–10mm varifocal lens lets installers remotely adjust field of view for flexible coverage and fewer re-visits
- Robust IP66 and IK10-rated housing protects against weather and vandalism for outdoor and indoor installations
- Plug-and-play analog HD compatibility (AHD/CVI/TVI) simplifies upgrades from legacy systems and lowers integration cost
| General Information | |
|---|---|
| Brand Name | Hanwha Vision |
| Manufacturer | Hanwha Vision |
| Product Name | 2MP Analog HD IR Indoor Dome |
| Product Type | Dome Camera |
| Product Model | HCD-6080R |
| Manufacturer Part Number | HCD-6080R |
| Technical Information | |
| Lens Type | Varifocal |
| Night Vision | Yes |
| Optical Zoom | 3.1x |
| Field of View | Diagonal, Horizontal, Vertical |
| Maximum Aperture | f/1.6 |
| Night Vision Type | Infrared |
| Maximum Frame Rate | 30fps |
| Minimum Focal Length | 3.2mm |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 2MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 65 ft |
| Certifications | |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP66 |
| Display & Graphics | |
| Maximum Video Resolution | 1920 x 1080 |
| Environmental Conditions | |
| Operating Humidity | 0.9 |
| Maximum Operating Temperature | 131°F |
| Minimum Operating Temperature | 14°F |
| Exposure | |
| Longest Shutter Speed | 1 Second |
| Shortest Shutter Speed | 1/12,000 Second |
| Lens | |
| Focal Length | 3.2-10mm |
| Lens Included | Yes |
| Maximum Focal Length | 10mm |
| Network & Communication | |
| Remote Management | No |
| Physical Characteristics | |
| Color | Ivory |
| Height | 3.8" |
| Weight | 0.73lb |
| Durability | Dustproof, Impact Resistant, Vandal Resistant, Waterproof, Weather Resistant |
| Form Factor | Dome |
| Power Description | |
| Input Voltage | 12V DC, 24V AC |
| Product Information | |
| Diameter | 4.72" |
| Mount Type | Box Mount, Ceiling Mount, Pole Mount, Wall Mount |
| Storage | |
| Recording Formats | Full HD |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Analog Video Signal Format | AHD, CVBS, CVI, TVI |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | ,, , Dual power, 0.11Lux at F1.4(Color), 0Lux(B/W - IR LED on), 3.2-10mm(3.2x) Motorized V/F lens, Day and Night(ICR), WDR(120dB), Easy installation (Plug and play), Dual power, RS-485, Full HD resolution, IR viewable length - 65 feet,, SSNR, Motion detection, Transmission distance maximum 1640ft |
| Indoor/Outdoor | Indoor, Outdoor |
| Country of Origin | CN|KR |
| Impact Protection Rating | IK10 |
