ICC ICPCST01BK Patch Cord, CAT6, Clear Boot, 1ft Black Low Profile
Image of 1
Key Features
- Reliable CAT6 performance up to 550 MHz for stable, high-speed networking and surveillance feeds
- Slim, low-profile clear boot conserves space in high-density racks and simplifies patch panel access
- 50 micro-inch gold-plated contacts and ETL verification to ANSI/TIA-568-C.2 for consistent, low-loss connections
- Flexible stranded 24 AWG conductors with EZ-release snag-free strain relief for fast moves, adds and changes
- Backward compatible with lower category components and UL/CSA/FT4 flame rated for safe commercial installations
- 3-year limited warranty protects your investment and reduces lifecycle risk
Quick Specifications
- Product Model
- ICPCST01BK
- Brand Name
- ICC
- Product Name
- CAT6 Clear Boot Patch Cord
- Product Type
- Network Cable
Explore the details
Product information
ICPCST01BK
Overview
Get dependable, short-run Ethernet connections for tight racks and high-density patch panels with the ICC ICPCST01BK CAT6 clear-boot patch cord. Designed for IT, security and surveillance environments, this Category 6 patch cord delivers consistent performance up to 550 MHz and is ETL verified to ANSI/TIA-568-C.2 and UL listed for peace of mind. The ultra-slim low-profile boot minimizes plug width so you can maximize port density in patch panels and switches, while the stranded 24 AWG conductors and flexible PVC jacket make routing and reconfiguration simple. Corrosion-resistant 50 micro-inch gold-plated contacts ensure reliable signal transfer and long-term uptime — critical for monitoring, security camera systems, and enterprise networking where dropouts aren’t acceptable. Backward compatibility with lower-category components and CMG/FT4 flame ratings support safe, standards-compliant installations in commercial and security-focused projects. Ideal for short patch runs, surveillance deployments, and high-density wiring closets — add the ICC 1 ft CAT6 patch cord to your next install to streamline connectivity and reduce maintenance. Order now for fast, reliable networking and surveillance connectivity.
Features
- Reliable CAT6 performance up to 550 MHz for stable, high-speed networking and surveillance feeds
- Slim, low-profile clear boot conserves space in high-density racks and simplifies patch panel access
- 50 micro-inch gold-plated contacts and ETL verification to ANSI/TIA-568-C.2 for consistent, low-loss connections
- Flexible stranded 24 AWG conductors with EZ-release snag-free strain relief for fast moves, adds and changes
- Backward compatible with lower category components and UL/CSA/FT4 flame rated for safe commercial installations
- 3-year limited warranty protects your investment and reduces lifecycle risk
| General Information | |
|---|---|
| Brand Name | ICC |
| Manufacturer | ICC |
| Product Name | CAT6 Clear Boot Patch Cord |
| Product Type | Network Cable |
| Country of Origin | CN |
| Packaged Quantity | 1 |
| Manufacturer Part Number | ICPCST01BK |
| Technical Information | |
| Shielding | No |
| Cable Type | Category 6 |
| Cable Style | Slim Cables |
| Jacket Type | CMG, CSA FT4 |
| Contact Plating | Gold |
| Device Supported | Network Device |
| Solid or Stranded | Stranded |
| American Wire Gauge | 24AWG |
| Connector on First End | RJ45 |
| Connector on Second End | RJ45 |
| Physical Characteristics | |
| Color | Black |
| Material | Bare Copper - Wire, HDPE - Insulation, PC - Housing, Phosphor Bronze - Contact, PVC - Jacket |
| Cable Length | 1.00' |
| Jacket Material | Bare Copper - Wire, HDPE - Insulation, PC - Housing, Phosphor Bronze - Contact, PVC |
| Insulation Material | High-density Polyethylene (HDPE) |
| Product Replacements & Other Alternatives | |
| Model Number Replaces | ICPCSK01BK |
| Warranty | |
| Limited Warranty | 3-Year |
| Miscellaneous | |
| Features | Equal Level Far End Crosstalk (ELFEXT), Minimized Near-End Crosstalk (NEXT), Power-sum Equal Level Far-End Crosstalk (PSELFEXT), Power-sum Near End Crosstalk (PSNEXT), Strain Relief, Stranded, Ultra Flexible |
No matching specifications
Try a different term, such as a connector type or resolution.
Plan your purchase
Is this right for your project?
Confirm the model, required accessories and delivery needs before ordering.
- SKU:
- ICPCST01BK
- Manufacturer part:
- ICPCST01BK
How do I confirm compatibility?
Check the specifications and manufacturer documents for your existing system. Send us your model numbers and project requirements if you need help selecting equipment or accessories.
Ask a product specialistWhen will this item ship?
Availability is shown above. Special-order items and project quantities may need additional lead time. Contact us to confirm a delivery date before scheduling installation.
Shipping, freight and delivery detailsWhat should I know about returns?
Returns require an approved RMA. Consult the linked return policy for deadlines and eligibility. For standard non-defective returns, eligible factory-sealed items carry a 15% restocking fee and customer-paid return shipping; open-box and used items are refused. Defective and DOA claims follow the policy's separate terms. Special orders and other exclusions are final sale.
