ICC ICPCST07BK CAT6 Clear Boot Patch Cord, 7' (2.1m), Black
Image of 1
Key Features
- Consistent high-speed connectivity up to 550 MHz for reliable networking, security and surveillance systems
- Low-profile clear boot and snag-free EZ-release strain relief for neat, high-density patch panel and switch deployments
- 24 AWG stranded copper with 50 µin gold-plated contacts for durable, low-loss RJ45 connections and superior signal integrity
- ETL-verified to ANSI/TIA-568-C.2 to ensure interoperability and performance in commercial IT and monitoring environments
- Backwards compatible with lower category components and CMG/FT4 jacket ratings for flexible, code-compliant installations
Quick Specifications
- Product Model
- ICPCST07BK
- Brand Name
- ICC
- Product Name
- CAT6 Clear Boot Patch Cord
- Product Type
- Network Cable
Explore the details
Product information
ICPCST07BK
Overview
Keep critical networks and security systems running cleanly and reliably with the ICC CAT6 Clear Boot Patch Cord. This Category 6 patch cord is engineered to deliver stable Gigabit-class performance (up to 550 MHz) in crowded racks and wall outlets — ideal for networking, surveillance camera feeds, access control and remote monitoring. The ICPCST07BK 7' (2.1m) length fits typical patch-panel-to-switch runs while the ultra-slim, snag-free clear boot preserves port density and reduces accidental disconnects. Constructed with stranded 24 AWG bare copper conductors and 50 microinch gold-plated phosphor bronze contacts, the cord offers low insertion loss and long-lasting connection integrity. ETL-verified to ANSI/TIA-568-C.2 and UL/CSA rated for building installations, it supports PoE devices and is backwards compatible with lower-category components for flexible upgrades. Choose this ICC Category 6 Clear Boot Patch Cord for dependable links in CCTV, NVR, access control and enterprise LANs. Add to your configuration for a tidy, reliable cabling backbone — perfect for patch panels, switches and surveillance deployments.
Features
- Consistent high-speed connectivity up to 550 MHz for reliable networking, security and surveillance systems
- Low-profile clear boot and snag-free EZ-release strain relief for neat, high-density patch panel and switch deployments
- 24 AWG stranded copper with 50 µin gold-plated contacts for durable, low-loss RJ45 connections and superior signal integrity
- ETL-verified to ANSI/TIA-568-C.2 to ensure interoperability and performance in commercial IT and monitoring environments
- Backwards compatible with lower category components and CMG/FT4 jacket ratings for flexible, code-compliant installations
| General Information | |
|---|---|
| Brand Name | ICC |
| Manufacturer | ICC |
| Product Name | CAT6 Clear Boot Patch Cord |
| Product Type | Network Cable |
| Country of Origin | CN |
| Packaged Quantity | 1 |
| Manufacturer Part Number | ICPCST07BK |
| Technical Information | |
| Shielding | No |
| Cable Type | Category 6 |
| Cable Style | Slim Cables |
| Jacket Type | CMG, CSA FT4 |
| Contact Plating | Gold |
| Device Supported | Network Device |
| Solid or Stranded | Stranded |
| American Wire Gauge | 24AWG |
| Connector on First End | RJ45 |
| Connector on Second End | RJ45 |
| Physical Characteristics | |
| Color | Black |
| Material | Bare Copper - Wire, HDPE - Insulation, PC - Housing, Phosphor Bronze - Contact, PVC - Jacket |
| Cable Length | 7.00' |
| Jacket Material | Bare Copper - Wire, HDPE - Insulation, PC - Housing, Phosphor Bronze - Contact, PVC |
| Insulation Material | High-density Polyethylene (HDPE) |
| Product Replacements & Other Alternatives | |
| Model Number Replaces | ICPCSK07BK |
| Warranty | |
| Limited Warranty | 3 Year |
| Miscellaneous | |
| Features | Equal Level Far End Crosstalk (ELFEXT), Minimized Near-End Crosstalk (NEXT), Power-sum Equal Level Far-End Crosstalk (PSELFEXT), Power-sum Near End Crosstalk (PSNEXT), Strain Relief, Stranded, Ultra Flexible |
