ICC ICPCST10WH CAT6 Clear Boot Patch Cord, 10' (3m), White

SKU: ICPCST10WH ICC
ICC CAT6 Clear Boot Patch Cord
Product images for ICC ICPCST10WH CAT6 Clear Boot Patch Cord, 10' (3m), White. 1 image(s) available. Click on image to view full size.

Key Features

  • Guaranteed gigabit performance and ETL-verified reliability up to 550 MHz for secure network and surveillance connectivity
  • Slim, snag-free clear boot and 24 AWG stranded cable for easy routing in high-density racks and camera mounts
  • 50 µin gold-plated contacts and UL/CSA listings for corrosion resistance and long-term signal integrity
  • Flexible stranded construction supports PoE devices and simplifies runs to IP cameras, NVRs, switches and patch panels
  • White color offers quick visual identification for security, monitoring and dedicated network runs; backed by a 3-year limited warranty

Quick Specifications

Product Model
ICPCST10WH
Brand Name
ICC
Product Name
CAT6 Clear Boot Patch Cord
Product Type
Network Cable
View Full Technical Specifications

Explore the details

Product information

ICPCST10WH

Overview

Deliver dependable Gigabit connectivity where it matters most — ICC's CAT6 Clear Boot Patch Cord is designed for security, surveillance and critical network monitoring applications. This Category 6 UTP patch cord (10' / 3 m) combines ETL verification to ANSI/TIA-568-C.2 and 50 µin gold-plated RJ45 contacts to ensure consistent, low-loss links for IP cameras, PoE devices, NVRs and switches. The ultra-slim, snag-free clear boot and flexible 24 AWG stranded conductors make routing through dense patch panels, racks and conduit fast and damage-free, while backward compatibility with lower category components simplifies upgrades. Rated for CMG/FT4 and UL 1863 compliant, the ICC CAT6 patch cord gives installers peace of mind on safety and performance. Available in white for easy circuit identification, it’s an ideal choice for professional security integrators and IT teams deploying surveillance and monitoring systems. Order the ICPCST10WH to streamline your cabling runs and secure reliable network performance.

Features

  • Guaranteed gigabit performance and ETL-verified reliability up to 550 MHz for secure network and surveillance connectivity
  • Slim, snag-free clear boot and 24 AWG stranded cable for easy routing in high-density racks and camera mounts
  • 50 µin gold-plated contacts and UL/CSA listings for corrosion resistance and long-term signal integrity
  • Flexible stranded construction supports PoE devices and simplifies runs to IP cameras, NVRs, switches and patch panels
  • White color offers quick visual identification for security, monitoring and dedicated network runs; backed by a 3-year limited warranty
25 of 25 specifications
Technical specifications for ICC ICPCST10WH CAT6 Clear Boot Patch Cord, 10' (3m), White
General Information
Brand Name ICC
Manufacturer ICC
Product Name CAT6 Clear Boot Patch Cord
Product Type Network Cable
Packaged Quantity 1
Manufacturer Part Number ICPCST10WH
Technical Information
Material Bare Copper - Wire, HDPE - Insulation, PC - Housing, Phosphor Bronze - Contact, PVC - Jacket
Shielding No
Cable Type Category 6
Cable Style Slim Cables
Jacket Type CMG, CSA FT4
Contact Plating Gold
Jacket Material Bare Copper - Wire, HDPE - Insulation, PC - Housing, Phosphor Bronze - Contact, PVC
Device Supported Network Device
Solid or Stranded Stranded
American Wire Gauge 24AWG
Connector on First End RJ45
Connector on Second End RJ45
Others
Model Number Replaces ICPCSK10WH
Physical Characteristics
Color White
Cable Length 10'
Insulation Material High-density Polyethylene (HDPE)
Warranty
Limited Warranty 3-Year
Miscellaneous
Features Equal Level Far End Crosstalk (ELFEXT), Minimized Near-End Crosstalk (NEXT), Power-sum Equal Level Far-End Crosstalk (PSELFEXT), Power-sum Near End Crosstalk (PSNEXT), Strain Relief, Stranded, Ultra Flexible
Country of Origin CN
