VIVOTEK IT9380-HF3 C-Series 5MP Pro Smart IR Turret IP Camera, 3.6mm Fixed Lens, WDR, White
Key Features
- Capture crisp, actionable video with 5MP resolution and a 3.6mm fixed lens for reliable identification and incident review.
- Maintain clear images in challenging light using WDR Pro and SNV technology, reducing false alarms and improving detection accuracy.
- Extend low-light coverage with built-in IR up to 30 m (98 ft), ensuring 24/7 monitoring for perimeters, entrances, and parking areas.
- Reduce bandwidth and storage costs with H.265 compression and Smart Stream III while preserving critical detail.
- Depend on rugged outdoor performance with IP66 weatherproofing and IK10 vandal resistance for long-term installations.
- Protect data and simplify deployment with Trend Micro IoT security, onboard microSD recording, built-in microphone and standard RJ-45 network connectivity.
Quick Specifications
- Product Model
- IT9380-HF3
- Brand Name
- VIVOTEK
- Product Name
- IT9380-HF3 Network Camera
- Product Type
- Network Camera
Product Information Tabs
Overview
For dependable outdoor surveillance and continuous monitoring, the VIVOTEK IT9380-HF3 C-Series 5MP Pro Smart IR turret IP camera delivers high-quality imaging and resilient operation. Designed for commercial and institutional environments, this turret camera pairs a 5MP sensor with a 3.6mm fixed lens to capture detailed footage for identification and evidence. WDR Pro and SNV technologies enhance visibility across bright and dark scenes, while built-in IR illumination extends reliable night vision to approximately 30 meters.
Bandwidth-conscious deployments benefit from H.265 compression and Smart Stream III, which conserve network resources without sacrificing image fidelity. The camera’s IP66 weatherproof and IK10 vandal-resistant housing provides rugged protection in exposed outdoor locations, and onboard microSD storage plus Trend Micro IoT security help safeguard recordings and reduce single-point failures. With integrated audio and standard RJ-45 networking, the IT9380-HF3 is easy to integrate into existing surveillance systems.
Ideal for perimeter security, retail, transportation hubs and facility monitoring, this VIVOTEK turret camera offers a balanced mix of image quality, durability and cyber protection — contact sales to specify it for your next security project.
Features
- Capture crisp, actionable video with 5MP resolution and a 3.6mm fixed lens for reliable identification and incident review.
- Maintain clear images in challenging light using WDR Pro and SNV technology, reducing false alarms and improving detection accuracy.
- Extend low-light coverage with built-in IR up to 30 m (98 ft), ensuring 24/7 monitoring for perimeters, entrances, and parking areas.
- Reduce bandwidth and storage costs with H.265 compression and Smart Stream III while preserving critical detail.
- Depend on rugged outdoor performance with IP66 weatherproofing and IK10 vandal resistance for long-term installations.
- Protect data and simplify deployment with Trend Micro IoT security, onboard microSD recording, built-in microphone and standard RJ-45 network connectivity.
| General Information | |
|---|---|
| Brand Name | VIVOTEK |
| Manufacturer | Vivotek, Inc |
| Product Name | IT9380-HF3 Network Camera |
| Product Type | Network Camera |
| Product Model | IT9380-HF3 |
| Product Series | C |
| Manufacturer Part Number | IT9380-HF3 |
| Technical Information | |
| Lens Type | Fixed |
| Night Vision | Yes |
| Field of View | Diagonal, Horizontal, Vertical |
| Video Formats | H.264, H.265, MJPEG |
| Maximum Aperture | f/2 |
| Number of IR LEDs | 2 |
| Maximum Frame Rate | 20fps |
| Minimum Focal Length | 3.6mm |
| Connectivity Technology | Wired |
| Effective Camera Resolution | 5MP |
| Camera | |
| Image Sensor Type | CMOS |
| Wide Dynamic Range | Yes |
| Night Vision Distance | 98.43 ft |
| Certifications | |
| TAA Compliant | Yes |
| NDAA Compliant | Yes |
| Ingress Protection Rating | IP66 |
| Display & Graphics | |
| Maximum Video Resolution | 1600 x 1200 |
| Environmental Conditions | |
| Operating Humidity | 0.9 |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Operating Temperature | -4°F (-20°C) |
| Exposure | |
| Longest Shutter Speed | 1/5 Second |
| Shortest Shutter Speed | 1/32000 Second |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Lens | |
| Focal Length | 3.6mm |
| Lens Included | Yes |
| Maximum Focal Length | 3.6mm |
| Network & Communication | |
| Remote Management | Yes |
| Others | |
| Model Number Replaces | IT9380-HF2 |
| Physical Characteristics | |
| Color | White |
| Weight | 1047.20 lb |
| Durability | Dustproof, Impact Resistant, Vandalproof, Waterproof, Weatherproof |
| Form Factor | Dome |
| Product Information | |
| Diameter | 4.1" |
| Mount Type | Junction Box Mount |
| Storage | |
| Storage Type | Memory Card |
| Recording Formats | HD |
| Video | |
| Maximum Resolution | 1280 x 720 |
| Miscellaneous | |
| Features | 3D Digital Noise Reduction, Alarm Triggering, Audio Compression, Audio Detection, Auto Gain Control, Automatic White Balance, Back Light Compensation (BLC), Built-in Card Reader, Built-in IR LED, Built-in Memory, Built-in Microphone, Day/Night, Defog, Highlight Compensation (HLC), Motion Detection, Password Protection, Privacy Masking, Removable IR Cut-off Filter, SD Card Local Storage, Tamper Detection, Wide Dynamic Range |
| Indoor/Outdoor | Outdoor |
| Impact Protection Rating | IK10 |
