Bogen LB8TW 8" 2-way Weatherproof Loudspeaker with Built-in 70V Transformer, Pair, Black

SKU: LB8TB Bogen

Special Order Item

This item is available by special order. Lead times may vary. Please contact us for availability and estimated delivery.

Image of BO-LB8TB
Product images for Bogen LB8TW 8" 2-way Weatherproof Loudspeaker with Built-in 70V Transformer, Pair, Black. 4 image(s) available. Click on image to view full size.

Key Features

  • Reliable outdoor audio with life-like 2-way sound for clear paging, monitoring and background music
  • Built-in 70V transformer with multiple power taps (32–2 W) plus 8 Ω bypass for flexible system integration
  • IP68 waterproof connector and mineral-filled polypropylene cabinet for long-term weather, salt and UV resistance
  • Quick lever-bracket mounting reduces ladder time and installation costs on perimeter, stadium or campus security projects
  • High-sensitivity 90 dB and 8" MDT woofer with 1" titanium tweeter for wide coverage and intelligible voice reproduction

Quick Specifications

Product Model
LB8TB
Brand Name
Bogen
Product Name
LB8TW Speaker
Product Type
Speaker
View Full Technical Specifications

Product Information Tabs

Overview

Deliver dependable, intelligible audio across outdoor and all-environment installations with the Bogen LB8TW 8" 2-way weatherproof loudspeaker pair. Purpose-built for security, surveillance and facility monitoring, this pro speaker combines an 8-inch anodized MDT woofer and a 1-inch titanium tweeter to produce clear voice paging and consistent background music across wide areas. The LB8TW includes a built-in 70V transformer with selectable taps (32, 16, 8, 4, 2 W) plus an 8-ohm bypass, simplifying integration with existing commercial paging and public-address systems.

Durability-focused features—an IP68 waterproof input connector, fluid-sealed magnet gap, and mineral-filled polypropylene cabinet—minimize maintenance and ensure reliable performance in harsh outdoor environments like campuses, parking structures, transit hubs and industrial facilities. A quick lever-bracket mount reduces installation time and improves technician safety. Backed by a 12-year limited warranty and 90 dB sensitivity, the LB8TW gives security and AV integrators a low-maintenance, high-performance option for perimeter paging, surveillance audio feeds and distributed monitoring applications. Contact sales to configure pairs for your next project or add them to your security and PA systems today.

Features

  • Reliable outdoor audio with life-like 2-way sound for clear paging, monitoring and background music
  • Built-in 70V transformer with multiple power taps (32–2 W) plus 8 Ω bypass for flexible system integration
  • IP68 waterproof connector and mineral-filled polypropylene cabinet for long-term weather, salt and UV resistance
  • Quick lever-bracket mounting reduces ladder time and installation costs on perimeter, stadium or campus security projects
  • High-sensitivity 90 dB and 8" MDT woofer with 1" titanium tweeter for wide coverage and intelligible voice reproduction
General Information
Brand Name Bogen
Manufacturer Bogen Communications International, Inc
Product Name LB8TW Speaker
Product Type Speaker
Product Model LB8TB
Product Series NEAR
Manufacturer Part Number LB8TB
Technical Information
Material Titanium Dome
Impedance 8 ohms
Sensitivity 90dB
Speaker Size 8"
Crossover Type 2-way
Wireless Speaker Yes
Application/Usage Outdoor
Audio
RMS Output Power 4W
Number of Speakers 2
Maximum Frequency Response 19 kHz
Minimum Frequency Response 45Hz
Certifications
TAA Compliant No
Physical Characteristics
Size 8"
Color Black
Depth 11.75"
Width 10.3"
Height 17.9"
Weight 18 lb
Durability Durable, Waterproof, Weather Resistant
Product Information
Mount Type Bracket Mount
Warranty
Limited Warranty 12-Year
Miscellaneous
Features Anodized metal-alloy speaker, Dual-layer voice coil, Fluid-sealed gap, Heavy-gauge, Mineral-filled polypropylene cabinet, Powder-coated stainless steel mounting bracket
Indoor/Outdoor Indoor
